H O M E R T O N
I N T E R N E T R A D I O & M U S I C S Y S T E M
HOM-ALL-WAL
Instructions Guide

Advertisement

Table of Contents
loading

Related Manuals for MAJORITY HOMERTON

Summary of Contents for MAJORITY HOMERTON

  • Page 1 H O M E R T O N I N T E R N E T R A D I O & M U S I C S Y S T E M HOM-ALL-WAL Instructions Guide...

  • Page 2: Table Of Contents

    Contents What’s in the Box? Controls And Functions  Support  Instructions Guide  Basic Operation �������������������������������������������������������� Internet Radio ����������������������������������������������������������� Media Centre ����������������������������������������������������������� FM Radio ������������������������������������������������������������������ DAB/DAB+ Radio ����������������������������������������������������� CD Player ����������������������������������������������������������������� Information Centre ������������������������������������������������� Connections ������������������������������������������������������������� Bluetooth ����������������������������������������������������������������� Spotify Connect ������������������������������������������������������� Configuration Settings ���������������������������������������������...

  • Page 3: What's In The Box

    What’s in the Box? Box Contents 1. Majority Homerton 2. Remote Control 3. Power Adapter 4. Instructions Guide...

  • Page 4: Controls And Functions

    Controls And Functions Top View (Control Panel) Navigation Menu Power/Standby MENU CD eject/load Alarm 10. Stop - CD mode Sleep 11. Pause/Play - CD mode Previous 12. Rewind - CD mode Next 13. Fastforward - CD mode Navigation/Volume/OK dial...
  • Page 5 Controls And Functions Front View 14. Display screen 15. CD port Back View 16. DC power input 19. USB Port 17. Aux In 20. Antenna 18. Headphone port...
  • Page 6 Controls And Functions Remote Control Dimmer Sleep Program HOME VOL+ VOL- PQRS PQRS WXYZ WXYZ FAV+...
  • Page 7 Controls and Functions Power On/Off 12. Sleep button Switch the unit between on and Select repeatedly until desired Standby mode sleep timer set on top right of Dimmer display 13. Program button Switch between two dimmer 14. Stop button settings Equaliser 15.

  • Page 8: Support

    Support Support Thank you for your purchase of the Majority Homerton internet radio. Please follow the guidance of the manual to set up your new purchase and begin enjoying its features. If you require further assistance with your new radio, please contact our support team on the Majority website: https://www.majorityradios.co.uk/support...

  • Page 9: Instructions Guide

    Instructions Guide Navigation Settings Standby button: This should be used to turn your radio on and off. The Standby screen will display the time, date and any settings set such as alarms. To turn off standby, press the Standby button to be taken to the home screen, or last function that you were using before putting into standby.

  • Page 10: Basic Operation

    DAB and FM modes and beginning the scan. After the Majority screen, you will be able to select your chosen language by scrolling with the Navigation dial (Ref.7). Select your language by pressing down the dial.
  • Page 11 Instructions Guide Manual WiFi Set-up If you select YES, you will be able to select your chosen WiFi network and enter the WiFi password in the next display screen. Type letters/numbers by scrolling with the Navigation dial (Ref.7) until the correct digit is displayed and click ‘>’ to go to the next digit (Ref.6).
  • Page 12 Instructions Guide WiFi Connection Complete! Once your WiFi is connected by manually entering your WiFi password or via WPS, you will be taken to the main menu screen and the WiFi signal will appear in white at the top left. Your internet radio is now set up!

  • Page 13: Internet Radio

    Instructions Guide Internet Radio Go to the main menu screen by selecting ‘Menu’ (Ref.2) and select ‘Internet Radio’ on the display screen by turning the Navgiation dial (Ref.7) and pressing down the dial. When in the ‘Internet Radio’ screen there will be multiple options: My Favourite: Your favourite stations will be saved here for easy listening.
  • Page 14 Instructions Guide Service: Search for an internet radio station or add a new station. To search a new station, select ‘Search Radio Station’ to go to the search tool. Turn the Navigation dial (Ref.7) to highlight the chosen character and click ‘>’ (Ref.6) to move to the next character.

  • Page 15: Media Centre

    Both your device and the Homerton radio will need to be connected to the same WiFi network. Select the device with the Navigation dial you want to play music or media from on the radio display screen in UPnP settings.
  • Page 16 Instructions Guide My Playlist: You can create a playlist of favourite music or media from UPnP. When you are playing the media, press and hold the Navigation dial on the unit or the ‘OK’ button on the remote control (Ref.18) to save it into My Playlist.

  • Page 17: Fm Radio

    Instructions Guide FM Radio Select ‘FM mode’ on the main display screen with the Navigation dial (Ref.7). Once selected, the FM mode will start on 87.50MHz. Press down the Navigation dial (Ref.7) and the screen will display “Auto Scan?”. Select YES to begin an autoscan and receive the stations with the best signal.

  • Page 18: Dab/Dab+ Radio

    Navigation dial (Ref.7) and selecting the mode by pressing down the dial. On first use of DAB on the Homerton, it will begin scanning for DAB stations and will show ‘Scanning’ on the display screen. It will display how many stations have been found as the search continues.
  • Page 19 Instructions Guide Pre-setting your favourite DAB/DAB+ stations When you have found your desired station, press and hold the ‘FAV’ button on the radio (Ref.8) or press the ‘FAV+’ button on the remote (Ref.22) to go to the ‘Add to my Favourites’ screen. Turn the Navigation dial (Ref.7) to choose the preset number and select your option by pressing down the dial.

  • Page 20: Cd Player

    Instructions Guide CD Player Select ‘CD’ on the main display screen by turning the Navigation dial and pressing down the dial (Ref.7) or select with the remote navigation buttons. The display screen for the CD function will now show “Reading... ” followed by “No Disc”.
  • Page 21 Instructions Guide Arrange a CD song program 1. When the CD is put into ‘Stop’ on the machine (Ref.10) or on the remote (Rem.14), you can program the CD player to play songs in a particular order. Simply follow by pressing the “Program”...

  • Page 22: Information Centre

    Instructions Guide Information Centre Select ‘Information Centre’ on the main display screen by turning the Navigation dial and pressing down the dial (Ref.7) Weather Information: To select the weather information for a desired place, first select the continent by using the Navigation dial to scroll and select.

  • Page 23: Connections

    Instructions Guide Connections AUX-In Select ‘AUX’ on the main display screen by turning the Navigation dial and pressing the dial to select (Ref.7) Plug an AUX cable into your device and connect the cable via AUX-in port (Ref.17) at the back of the radio. Begin playing audio from your device and this should play on the radio when in AUX mode.

  • Page 24: Bluetooth

    Go to your device settings to connect your device to the radio via Bluetooth. The internet radio’s device will display as ‘Majority Homerton’ . Select this radio to connect and your radio should sound “Connected”. Select your chosen audio on your device and play.

  • Page 25: Spotify Connect

    Instructions Guide Spotify Connect Listen out loud with Spotify Connect 1. Connect your Majority Homerton to your WiFi network. 2. Open up the Spotify app on your phone, tablet or laptop using the same WiFi network. 3. Play a song and select Devices Available.

  • Page 26: Configuration Settings

    Instructions Guide Configuration Settings Select ‘Configuration’ on the main display screen to browse through a range of display, performance and audio settings. Network Select this for WiFi and network options Wireless Network Configuration On the Network settings, you can set up a Wi-Fi connection by selecting Wireless Network Configuration.
  • Page 27 Instructions Guide Settings: Date & Time Manually setting date and time There is the option to manually set the time and date instead of using auto-detect to set this up. Go to ‘Configuration’ settings and select ‘Date&Time’ by scrolling and selecting with the Navigation dial (Ref.7). Set Date and Time Select ‘Set Date and Time’...
  • Page 28 Instructions Guide Settings: Alarm Clock Setting Alarm 1/Alarm 2 To set an alarm on your radio, go to ‘Configuration’ settings and scroll through to select ‘Alarm’ or click the ‘Alarm’ button (Ref.3) After selecting ‘Alarm’ on ‘Configuration’ settings, or the ‘Alarm’ button (Ref.3) on the front of the radio, select Alarm 1 or Alarm 2 and highlight ‘Turn On’...
  • Page 29 Instructions Guide Settings: Alarm Features 00:00 Everyday Once 00:00 00:00 00:00 00:00 Alarm 1 (Turn O ) Turn On Repeat: Everyday Time Turn O Alarm 2 (turn O ) Time: 00:00 NAP Alarm (Turn O ) Sound: Melody 00 : 00 HH : MM Alarm Volume Input...
  • Page 30 Instructions Guide How to put your alarm on snooze When your alarm is sounding, press the Navigation dial (Ref.7) or any other button except ‘Standby’ or ‘Alarm’ to stop the sound and put into Snooze mode. The Snooze function will make the radio sound again in 5 minutes.

  • Page 31: Settings: Additional Features

    Instructions Guide Settings: Additional Features The following options are available in Configuration settings: Timer In ‘Configuration’ settings, select the option for ‘Timer’ and a screen with 00:00 will display. To go up in seconds, click the ‘>’ button (Ref.6). To go down in seconds, click the ‘<’...
  • Page 32 Instructions Guide Software Update Will show here if a software update is available for the radio. If one is available, please select for the update to initiate. Reset to default Select this option to reset your radio and revert all of the settings and presets made.

  • Page 33: Remote Control App

    Once the app is downloaded, open the app and ensure that your radio is switched on and out of standby mode. The app should then automatically connect to your Majority internet radio. You can now begin adjusting settings and navigating around your...
  • Page 34 Instructions Guide Additional Setting Options Time display - Select Analog or Digital Language - Select your chosen language within the list Display - Choose the display to be Colour or Monochrome Power management - Select this to configure the radio to go into standby mode automatically after a set time of inactivity or if there is no WiFi signal.

  • Page 35: Troubleshooting

    Ensure that you are on Bluetooth mode on the radio and the Bluetooth on your device is switched on. Select the Bluetooth device ‘Majority Homerton’ and you should now be able to play audio. CD player not working When on CD mode, simply press the eject button.

  • Page 36: Specifications

    Specifications Specifications DC 12V 2A (output) Power Supply FM: 87.5MHz - 108 MHz DAB: 174 - 240 MHz Mode: Bluetooth 3.5mm AUX-in Network 802.11b / g / n (WLAN) Encryption: WEP, WPA, WPA 2 (PSK), WPS Dimensions 21 x 14.7 x 24 cm Weight 2.18kg Warranty...

  • Page 37: Safety Information

    Safety Information ADDITIONAL WARNINGS 1. Read these instructions. 2. Keep these instructions. Instructions are also The apparatus shall not be exposed to dripping or available for download at www.majorityradios.co.uk splashing and no objects filled with liquid, such as 3. Heed all Warnings vases, shall be places on the apparatus.
  • Page 39 www.majorityradios.co.uk...
