- Page 1 BACKPACK SPRAYERS Model Nos: KSP16 & KSP20 Part Nos: 3402270 & 3402275 OPERATING & MAINTENANCE INSTRUCTIONS GC10/13...
- Page 2 GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase.
-
Page 3: Specification
SPECIFICATION Container Capacity 16 (KSP16) 20 litres (KSP20) Material Polyethylene Lance Length 550mm Hose Length 1280mm Max Working Pressure 6kgf/cm Pump type Piston (brass construction) Net Weight 4.1(KSP16) 4.2kg (KSP20) GENERAL SAFETY PRECAUTIONS 1. Never use this sprayer to store or spray flammable solvents. -
Page 4: Major Components
2 x Spray Nozzles (Conical and Flat Fan) 2 x Base Connecting Clips 2 x Piston Cups Upon receipt of the sprayer, unpack all components and lay them out to check for any missing parts as listed above. Any deficiencies should be reported to your Clarke dealer. - Page 5 ASSEMBLY 1. Push the lance into the trigger Connect Collet Seal assembly and secure with the screw cap. Lance 2. Attach one of the nozzles provided to the other end of the lance and secure with the screw cap. • A telescopic brass lance is also Trigger available with a choice of Screw Cap...
-
Page 6: Operation
OPERATION 1. Unscrew the filler cap and ensure the filter is in place. 2. Fill the container with the required liquid up to the desired graduation on the side and replace the filler cap. 3. Pump the operating arm a few Trigger Lock times to pressurise the container until the action of the pump... - Page 7 ACCESSORIES The following brass spray attachments are available from your Clarke dealer. Telescopic Brass Lance: Part No 3402280 Jet Spray Brass Nozzle: Part No 3402285...
-
Page 8: Troubleshooting
TROUBLESHOOTING n i l z i r z i r s i r v i l e l l & s i s l i f l z z l z z... -
Page 9: Component Parts
COMPONENT PARTS & t i l t t i " 6 t l i & n i l n i l... - Page 10 COMPONENT PARTS When requesting spare parts, quote Product Reference AH, followed by the model number KSP16 or KSP20 and part numbers 1-64.
