Summary of Contents for Clarke CHC90
- Page 1 (Hose not included) HOSE REEL TROLLEY Model No CHC90 Part No 7956025 ASSEMBLY INSTRUCTIONS GC0410...
-
Page 2: Technical Specifications
I l n I " 4 Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. - Page 3 UNPACKING & ASSEMBLY Before assembling, please check contents against the following list and advise your dealer immediately if any parts are missing. TOOLS REQUIRED Screwdriver, 10mm spanner, 19mm socket spanner l n I...
-
Page 4: Safety Precautions
, t l , t l SAFETY PRECAUTIONS 1. NEVER carry out any alterations or modifications to this product. 2. NEVER leave the trolley on a gradient without first chocking the wheels. 3. NEVER allow children to play with or ride on the trolley. 4. - Page 5 ASSEMBLY INSTRUCTIONS 1. Stand the frame assembly (A) upright and slide each axle (B) through both sides of the frame as shown in Fig 1. 2. Slide the wheels (C) onto the ends of the axles (B), The valve stems of the wheels should be facing outward.
- Page 6 5. Position the hose reel (D) within the frame assembly (A) and insert the end of the crank stem on the hose reel (D) onto the crank handle (E) as shown in Fig 4. Align the fixing holes of the crank handle (E) with those of the crank stem.
- Page 7 14. Attach your garden hose to the threaded garden hose connector and wind the garden hose around hose reel (D). NOTE: The hose reel will hold up to 300’ of 5/8” garden hose. (Hose not included). A range of hoses is available from your Clarke dealer.
