7.3

Disassembly and Repair

All steps that involve opening the Form Wash and/or investigating internal
components should be done by skilled persons under the guidance of Formlabs or a
WARNING
certified service provider.
Contact Formlabs or a certified service provider to receive repair instructions and authorization.
The following tools, equipment, and materials are needed for reparation tasks:
task
Replacing the Display
Assembly
Reseating the Magnetic
Clutch
Replacing the Outer Lid
Hinge
Reseating the Ribbon Cable
required supplies
2.5 mm hex wrench,
replacement part(s)
2.0 mm hex wrench, 2.5 mm
hex wrench, calipers
2.0 mm hex wrench,
replacement part(s)
2.5 mm hex wrench
cause
The Form Wash display or knob has
stopped functioning.
Unusual noises during wash cycle
Erratic impeller movement
Outer lid does not close fully or move
smoothly
The Form Wash display or knob has
stopped functioning.
Troubleshooting and Repair | 31
