Clas Ohlson USB 3.0 PCI Express Quick Start Manual

USB 3.0 PCI Express
Art.no 38-4115 Model PU3020N2
Please read the entire instruction manual before use and save
it for future reference. We reserve the right for any errors in text
or images and for making any necessary technical changes to
this document. If you should have any questions concerning
technical problems please contact our Customer Services.
Safety
Note! When the PCI card is installed in a vacant PCI port it is
very important that the computer is shut off and the cable
that leads to the PSU is pulled out.
• Computer components are very sensitive to static electricity,
use an antistatic wristband when installing or handling the card.
• If you do not have a wristband you should divert your static
electricity by touching the computer chassis just before and
while you insert the card.
• The PCI card should be pushed in equally far along the
entire row when properly installed.
• Lock the card in place using a screw or another type of fastener.
Product description
• USB 3.0 card for PCI Express connection
• Transfer speed up to 5 Gbps
• Plug and Play
Installation
1. Switch off your
computer and any
connected devices.
Pull out the plug from
the wall socket.
2. Insert the card into
the PCI Express slot.
USB 3.0
3. Connect the computer
to a wall socket.
4. Start your computer.
GREAT BRITAIN • customer service tel: 08545 300 9799 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk
Installing drivers
Windows 8/7/Vista (32/64-bit) and XP.
1. Insert the supplied
CD into your computer
CD drive.
2. Press Next to start
the installation.
3. Accept the term and
conditions by clicking
on I accept the
terms of the license
agreement and then
on Next.
4. Click on Browse to
select a folder. Click
on Next to proceed.
Power
connector
PCI Express
5. Click on Install to
install NEC Electronics
USB 3.0 Host
Controller Driver.
6. Driver installation will
now commence.
7. Click on Finish to
end the installation.
8. The installation can
now be verified by
checking in Device
Manager.
Disposal
Follow local ordinances when disposing of this product. If you
are unsure of how to dispose of this product, please contact
your local authority.
Specifications
Connection PCI Express
2 x
USB 3.0 ports
Data transfer rate Up to 5 Gbps (USB 3.0) and
up to 480 Mbps (USB 2.0)
USB 3.0 and 2.0
Compatibility:
Supports Windows 8/7/Vista (32/64-bit) / XP
