Thank you for purchasing a WIKE CARGO TRIKE!
Contents
Safety..............................................................3
Connecting the frame...................................4
Wheel Assembly............................................5
Box & Handle Bar..........................................6
Seat post and Saddle....................................7
Final pre-ride check.......................................8
Tools needed to assemble Bike:
-High table or Stand
-Set of Allen/Hex wrenches
-Cable cutters
-12mm & 15mm wrenches
-Grease
-Presta compatible pump
Advertisement
Related Manuals for WIKE CARGO TRIKE
Summary of Contents for WIKE CARGO TRIKE
- Page 1 Thank you for purchasing a WIKE CARGO TRIKE! Contents Safety……………………..…………………………..….3 Connecting the frame…….……………………….4 Wheel Assembly……………………………………..5 Box & Handle Bar……………………………………6 Seat post and Saddle………………………………7 Final pre-ride check…………………………………8 Tools needed to assemble Bike: -High table or Stand -Set of Allen/Hex wrenches -Cable cutters -12mm &...
- Page 2 1. Handle bar & brake 12. Rear frame lever 13. Chain cover and chain 2. Gear shift 14. Chain wheel and crank 3. Brake lever 15. Pedal 4. Box 16. Rear wheel 5. Corner iron 17. Rear fender 6. Front reflector 18.
- Page 3 Remember to comply with all bicycle safety laws and use common sense especially in adverse weather condition Wike takes no responsibility for accidents resulting from failure to comply with all bicycle safety laws, careless driving or improper maintenance of your box bicycle...
- Page 4 Connecting front frame and rear frame (Figure 1 & 2) 1. Pack grease into both bearings (grease not included) 2. After greasing bearings place them on either side of front frame main pivot. Then insert pivot pin through bearing and front frame.
- Page 5 Assemble the wheel sets 1. Assemble the fenders on the sides of the front frame as shown in in Figure 3. 2. After screwing the disc rotor to the wheels. Place the front wheels in the drop-outs (frame slots) and tighten axle bolts on the two sides of front frame and tighten lock nut.
- Page 6 Assemble the box 1. Attach loosely with bolts the 4 corner irons to front frame 2. Assemble sides to corners 3. Tighten all bolts at completion of assembly of four sides 4. Place floor in box and bolt to front frame Assemble handlebar (U-Type) 1.
- Page 7 Saddle and Pedal Assembly (Figure 8.) 1. Insert seat post into the seat and lock it with nut as shown in figure 8. 2. Put other end of post into the frame seat tube with seat post clamp and tighten to desired height 3.
- Page 8 11. Lights and bell function properly Contact Us US and Canada Toll Free: 866- FACTORY SHOWROOM 584-9452 79 Regal Road, Unit 14 Worldwide: 1-519-824-3869 Guelph, Ontario Fax: 519-822-6152 N1K 1B6 8.00am to 3.00pm M-F 7 days a week 8.00am to 8.00pm EST wike.ca...
