WIKE 9032 User Manual

Cargo trike

Advertisement

Quick Links

Thank you for purchasing a WIKE CARGO TRIKE!
Contents
Safety..............................................................3
Connecting the frame...................................4
Wheel Assembly............................................5
Box & Handle Bar..........................................6
Seat post and Saddle....................................7
Final pre-ride check.......................................8
Tools needed to assemble Bike:
-High table or Stand
-Set of Allen/Hex wrenches
-Cable cutters
-12mm & 15mm wrenches
-Grease

Advertisement

loading
Need help?

Need help?

Do you have a question about the 9032 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for WIKE 9032

  • Page 1 Thank you for purchasing a WIKE CARGO TRIKE! Contents Safety……………………..…………………………..….3 Connecting the frame…….……………………….4 Wheel Assembly……………………………………..5 Box & Handle Bar……………………………………6 Seat post and Saddle………………………………7 Final pre-ride check…………………………………8 Tools needed to assemble Bike: -High table or Stand -Set of Allen/Hex wrenches -Cable cutters -12mm &...
  • Page 2 Cargo Trike (9032) References Fig.1 1. Handle bar 2. Gear shift 12. Chain cover and chain 3. Box 13. Rear Frame 4. Brake lever 14. Chain wheel and crank 5. Corner iron 15. Pedal 6. Saddle 16. Front 20’’ Wheel/Tire 7.
  • Page 3 Remember to comply with all bicycle safety laws and use common sense especially in adverse weather condition Wike takes no responsibility for accidents resulting from failure to comply with all bicycle safety laws, careless driving or improper maintenance of your box bicycle...
  • Page 4 Step 1 You will need a large area (preferably with a table/ workbench) Remove contents from boxes Preparing the #20 FRONT FRAME (Fig 1.) 1. Fix the fenders to each side of the Front Box Frame with the black curved brackets provided. 2.
  • Page 5 Assemble the wheel sets 1. Assemble the fenders on the sides of the front frame as shown in in Figure 3. 2. After screwing the disc rotor to the wheels. Place the front wheels in the drop-outs (frame slots) and tighten axle bolts on the two sides of front frame and tighten lock nut.
  • Page 6 Assemble the box 1. Attach loosely with bolts the 4 corner irons to front frame 2. Assemble sides to corners 3. Tighten all bolts at completion of assembly of four sides 4. Place floor in box and bolt (x2) to front frame Assemble handlebar (U-Type) 1.
  • Page 7 Saddle and Pedal Assembly (Figure 8.) 1. Insert seat post into the seat and lock it with nut as shown in figure 8. 2. Put other end of post into the frame seat tube with seat post clamp and tighten to desired height 1.
  • Page 8 11-Point Pre-Ride Check 1. Tires are inflated to 25-40 psi 2. All Axle bolts are tightened and wheels are secured 3. Dampers are secured and moving smoothly 4. Brakes are properly adjusted and function 5. Safety Straps in riders in box are secured and fastened 6.
  • Page 9 Contact Us FACTORY SHOWROOM 79 Regal Road, Unit 14 Guelph, Ontario N1K 1B6 8.00am to 3.00pm M-F wike.ca US and Canada Toll Free: 866-584-9452 Worldwide: 1-519-824-3869 Fax: 519-822-6152 7 days a week 8.00am to 8.00pm EST...
