2.5" SATA Mobile Rack for PCI Slot
6. LED Indication
Action
Power on
HDD access
7. Assembly of HDD and into PC
Attention!
a. Please connect the LED cable, which is delivered in the package. Otherwise the LED has no function!
b. When necessary please put on the "HDD-Pin-Protector" as shown in 7.1 to avoid mechanical
damage of the Pins.
7.1
7.3
Power: 15Pins
LED Indication
LED shines blue
LED blinks purple
LED: 4Pins
Data: 7Pins
IB-2207 Series
7.4
