EXTREME SWITCHING 4450GTX-HTPWR+ Installation Job Aid

Vsp
Hide thumbs Also See for 4450GTX-HTPWR+:

Advertisement

Quick Links

Download this manual
Installation Job Aid for VSP 4450GTX-HT-
PWR+
Notices
Notice paragraphs alert you about issues that require your attention. The following paragraphs
describe the types of notices used in this guide.
Note:
Notes provide tips and useful information regarding the installation and operation of products.
Electrostatic alert:
ESD
ESD notices provide information about how to avoid discharge of static electricity and
subsequent damage to products.
Caution:
Caution notices provide information about how to avoid possible service disruption or damage to
products.
Warning:
Warning notices provide information about how to avoid personal injury when working with
products.
Voltage:
Danger — High Voltage notices provide information about how to avoid a situation or condition
that can cause serious personal injury or death from high voltage or electric shock.
©
2017, Extreme Networks, Inc.
All Rights Reserved.
Release 6.1.0.0
NN46251-305
Issue 02.01
November 2017
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 4450GTX-HTPWR+ and is the answer not in the manual?

Questions and answers

Related Manuals for EXTREME SWITCHING 4450GTX-HTPWR+

Summary of Contents for EXTREME SWITCHING 4450GTX-HTPWR+

  • Page 1 Installation Job Aid for VSP 4450GTX-HT- PWR+ Release 6.1.0.0 NN46251-305 Issue 02.01 November 2017 Notices Notice paragraphs alert you about issues that require your attention. The following paragraphs describe the types of notices used in this guide. Note: Notes provide tips and useful information regarding the installation and operation of products. Electrostatic alert: ESD notices provide information about how to avoid discharge of static electricity and subsequent damage to products.

  • Page 2: Safety Messages

    Danger: Danger notices provide information about how to avoid a situation or condition that can cause serious personal injury or death. Safety messages Warning: Installation must be performed by qualified service personnel only. Read and follow all warning notices and instructions marked on the product or included in the documentation. Voltage: This equipment relies on the building's installation for overcurrent protection.

  • Page 3: Before You Begin

    Caution: Risk of high current and board burn out if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Warning: The lithium battery is not field replaceable. It must only be removed and replaced by authorized personnel.
  • Page 4 Installing the Virtual Services Platform 4000 on a table or shelf You can install a single VSP 4000 switch on any flat surface. The surface must support the combined weight of the switch and attached cables (from 15 and 20 pounds [7 to 9 kilograms]). Note: A factory-supplied 4450GTX-HT-PWR+ switch has a USB slot but no USB device or cover.
  • Page 5 Installing the Virtual Services Platform 4000 in an equipment rack To install a VSP 4000 switch in an equipment rack, perform this procedure. Note: A factory-supplied 4450GTX-HT-PWR+ switch has a USB slot but no USB device or cover. Prerequisites for installing the VSP 4000 switch in an equipment rack: •...

  • Page 6: Installing Sfp Transceivers

    3. Insert and tighten the rack-mount screws. Installing SFP transceivers Install SFP transceivers by performing this procedure. 1. Remove the transceiver from the protective packaging. 2. Verify that the transceiver is the correct model for the network configuration. 3. Grasp the transceiver between your thumb and forefinger. 4.
  • Page 7 3. Slide the transceiver from the module slot. 4. If the transceiver does not slide easily from the module slot, use a gentle side-to-side rocking motion while firmly pulling the transceiver from the slot. 5. Attach a dust cover over the fiber-optic bores and store the transceiver in a safe place until you need it.
  • Page 8 4450GTX-HT-PWR+ 860W between 0°C to 50°C 400W between 50°C to 70°C • With two operating PSUs, the maximum power consumption is: 1660W between 0°C to 50°C 832W between 50°C to 70°C Thermal Rating: 341.2 BTU/Hr typical and 494.8 BTU/Hr maximum Inrush Current: 70A maximum Turn on Condition:...
