Installation Job Aid for VSP 4850GTS
Notices
Notice paragraphs alert you about issues that require your attention. The following paragraphs
describe the types of notices used in this guide.
Note:
Notes provide tips and useful information regarding the installation and operation of products.
Electrostatic alert:
ESD
ESD notices provide information about how to avoid discharge of static electricity and
subsequent damage to products.
Caution:
Caution notices provide information about how to avoid possible service disruption or damage to
products.
Warning:
Warning notices provide information about how to avoid personal injury when working with
products.
Voltage:
Danger — High Voltage notices provide information about how to avoid a situation or condition
that can cause serious personal injury or death from high voltage or electric shock.
Danger:
Danger notices provide information about how to avoid a situation or condition that can cause
serious personal injury or death.
©
2017, Extreme Networks, Inc.
All Rights Reserved.
Release 6.1.0.0
NN46251-308
Issue 02.01
November 2017
1
Advertisement
Table of Contents
Related Manuals for EXTREME SWITCHING 4850GTS
Summary of Contents for EXTREME SWITCHING 4850GTS
- Page 1 Installation Job Aid for VSP 4850GTS Release 6.1.0.0 NN46251-308 Issue 02.01 November 2017 Notices Notice paragraphs alert you about issues that require your attention. The following paragraphs describe the types of notices used in this guide. Note: Notes provide tips and useful information regarding the installation and operation of products.
-
Page 2: Safety Messages
Fiber optic equipment can emit laser or infrared light that can injure your eyes. Never look into an optical fiber or connector port. Always assume that fiber optic cables are connected to a light source. November 2017 Installation Job Aid for VSP 4850GTS... -
Page 3: Before You Begin
1. Remove the screws that hold the USB cover but do not remove the USB cover. Caution: On a factory-supplied 4850GTS series switch, do not remove the USB device cover or the USB device from the slot. Removing the USB device affects system operation... - Page 4 3. Set the switch on a table or shelf as illustrated below. Allow at least 2 inches (5.1 centimeters) on each side for proper ventilation and at least 5 inches (12.7 centimeters) at the back for power cord clearance. November 2017 Installation Job Aid for VSP 4850GTS...
- Page 5 1. Remove the screws that hold the USB cover but do not remove the USB cover. Caution: On a factory-supplied 4850GTS series switch, do not remove the USB device cover or the USB device from the slot. Removing the USB device affects system operation and may even prevent the system from booting up successfully.
-
Page 6: Installing Sfp Transceivers
4. Insert and tighten the rack-mount screws. Installing SFP transceivers Install SFP transceivers by performing this procedure. 1. Remove the transceiver from the protective packaging. 2. Verify that the transceiver is the correct model for the network configuration. November 2017 Installation Job Aid for VSP 4850GTS... -
Page 7: Ac Power Supply Specifications
The following table describes the regulatory AC power specifications for the Virtual Services Platform 4000 Series 4850GTS and 4850GTS-PWR+ switches. The regulatory power specifications are based on the maximum rated capacity of the power supplies and are not based on typical power consumption which is lower. - Page 8 You can install a secondary power supply to provide redundancy and load sharing, and to add Power over Ethernet Plus (PoE+) power budget on PWR+ models. 300 W AC power supply The VSP 4850GTS supports 300 W AC power supplies. Figure 1: 300 W AC power supply November 2017...
- Page 9 17.8 W (802.3.at) — One power supply 32.4 W (802.3at) — Two power supplies • VSP 4850GTS-PWR+ can support 802.3af 15.4 W on each port with one power supply installed. You can add a second power supply for redundancy. • VSP 4850GTS-PWR+ can support 802.3at 32.4 W on each port with two power supplies installed.
-
Page 10: Connecting To Ac Power
United States of America, Canada, and Japan: • 100 or 120VAC • NEMA5-15P male plug • 50–60 Hz • UL-recognized (UL stamped on cord jacket) • Single phase • CSA-certified (CSA label secured to the cord) Table continues… November 2017 Installation Job Aid for VSP 4850GTS... - Page 11 Use only power cords that have a grounding path. Without a proper ground, a person who touches the switch is in danger of receiving an electrical shock. Lack of a grounding path to the switch can result in excessive emissions. November 2017 Installation Job Aid for VSP 4850GTS...
