RFGate
2.2.W2.F.A
Wireless signal transmission system for safety edges, two channels
Translation of the original operating instructions
General
Transmitter 1
50.8
10.8
1
Safety instructions
Warning: Switch off the operating voltage before working on the
system. Only trained, qualified personnel may perform installation
and startup. The unit may only be repaired by the manufacturer. The
switching unit may only be used to protect against dangers on
crushing and shearing points and on automatic industrial doors and
gates (intended use). National and international regulations on
industrial door and gate safety must be complied with. Always
2
Common application
2.1
Industrial door with wicket door
Receiver
ON
1
2
3
4
5
DIP switch 5 ON
Transmitter 1
Safety edges
8.2 kΩ
Transmitter 2
23
Drilling template enclosed
Transmitter 1 input 1 corresponds to receiver output 1
i
Transmitter 2 corresponds to receiver output 2
65.7
15.5
consider the safety functions of your application as a whole, never just in
relation to one individual section of the system. The installer is responsible
for carrying out a risk assessment and installing the industrial door system
correctly.
It is recommended to change the batteries every year.
i
Receiver
80
14
Transmitter 2
Magnet
349284E
01/19
45
1
