TSR (Traffic Sign Recognition)
SYSTEM
(where provided)
158) 159) 160)
48) 49) 50) 51) 52)
The system automatically detects the
recognizable road signs through a
camera located in the central area of the
windscreen:
speed limits;
no overtaking;
signs indicating the end of the
prohibitions indicated above.
If the camera does not detect valid speed
limits, the Connect system navigation
system may suggest unregulated speed
limits.
The system always checks the traffic
signs indicating the current speed limit
and possible no overtaking signs. The
system is able to recognize and show on
the instrument panel display, up to two
different road signs.
Depending on the unit of measurement
("km" or "mph") set through the
"Unit of measurement" menu on the
Connect system, the TSR system will
automatically show on the instrument
panel display the indication of the road
sign in the unit of measurement set.
TSR SYSTEM USE
System activation / deactivation
The system can be
activated/deactivated using the "Driver
Assistance" menu and then selecting
"Comfort" on the Connect system.
The system activation is signalled by
the road signs shown on the instrument
panel display.
Important notes
Selecting "Blinking" it is possible to
activate a warning when the effective car
speed exceeds that indicated by the TSR
system and displayed on the instrument
panel. In this case, the speed road sign on
the instrument panel display will blink
until the effective speed drops below the
displayed limit. Selecting "Offset", it is
possible to set the threshold at which
"Blinking" is activated, up to a maximum
of 10 km/h above the limit detected by
the system.
Indications on the display
The system status can always be
viewed through a dedicated area on the
instrument panel display.
This area contains the following road
sign information, from left to right within
the two dedicated zones:
the new speed limit recognised by the
system (1) fig. 197;
the "road sign not detected" (---)
indication, where applicable;
the no overtaking sign.
If the camera does not detect valid
speed limits, the navigation system may
suggest unregulated speed limits on the
display.
The previously displayed sign is no longer
valid after a certain distance has been
travelled if the system does not detect
other road signs, and the limit given by
the navigation system maps is indicated.
197
If a trailer and its light connector are
connected to the car, the instrument
panel display will show the additional
trailer connected sign.
NOTE The TSR system will always be
active every time the engine is started.
07076V0777EM
181
