Digital Acoustics SPKR-IP-CS-IC Getting Started Manual

Hide thumbs
1
2
3
4

Advertisement

Table of Contents

Introduction

The SPKR-IP-CS-IC is a 2'x2' IP Ceiling Speaker for use with Singlewire
Informacast Software. The internal amplifier delivers a maximum of 8 watts
of audio and is powered by Power over Ethernet (PoE - 802.3af compatible).
The SPKR-IP-CS-IC is DHCP enabled and will be automatically recognized
by InformaCast when connected to a Multicast enabled network. This
Getting Started Guide covers basic hardware installation and software
configuration of the SPKR-IP-CS-IC.

Specifications

•
8" O.D. Speaker
•
8 Watt Amplifier
•
PoE (802.3af)
•
Integrated Back Box
•
Average Sensitivity – 92 dB SPL, 1W/1M
•
Maximum Power rating – 15W @ 8 Ohms
•
Magnet Type & Weight – BeFe Ceramic, 5 oz. Nominal
•
Frequency Response – 65 Hz - 17 kHz EIA 426A Standard
•
Nominal Coverage Angle – 100° Included Angle -6 dB / 2 kHz, Half
space
SPKR-IP-CS-IC
Getting Started Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPKR-IP-CS-IC and is the answer not in the manual?

Questions and answers

Related Manuals for Digital Acoustics SPKR-IP-CS-IC

Summary of Contents for Digital Acoustics SPKR-IP-CS-IC

  • Page 1 Getting Started Guide Introduction The SPKR-IP-CS-IC is a 2’x2’ IP Ceiling Speaker for use with Singlewire InformaCast software. The internal amplifier delivers a maximum of 8 watts of audio and is powered by Power over Ethernet (PoE - 802.3af compatible).
  • Page 2 Installation The controls, connectors and LEDs for the SPKR-IP-CS-IC are located on a faceplate on top of the speaker. There is also a green LED in the speaker grill that matches the state of the Ready LED. • Connect the SPKR-IP-CS-IC ceiling speaker to a PoE (802.3af) network cable.
  • Page 3 Look for the InformaCast has detected new IP Speakers on the network message and click the View button • Match the ID# from the label on the back of the SPKR-IP-CS-IC with the last six digits of the MAC address listed in the Web browser and press the Add button •...
  • Page 4 Internal Web browser The SPKR-IP-CS-IC can be accessed via a Web browser to set options and check the status by entering its IP Address into a web browser. The default User Name and Password is: admin IP7 and Digital Acoustics® are trademarks of Digital Acoustics LLC.
