- Page 1 IB-700 Smartphone Binocular Adapter FITS 40mm - 44mm EYEPIECES Instructions for use Visit www.carson.com/hookupz700 to view our IB-700 tutorial video. HookUpz...
-
Page 2: Table Of Contents
Attaching to Optic......8-9 Frequently Asked Questions..10-13 Tips and Tricks........14 Storage/Cleaning Information..15 Thin Optic Customer Service......15 Adapter Ring* Carson Optical 2070 5th Avenue Optic Side Ronkonkoma, NY 11779 www.carson.com info@carson.com * For larger eyepieces Tel: 631-963-5000 Fax: 631-427-6749... -
Page 3: Phone Side Diagram
Camera Clamp Cutout Top Clamp Lock Alignment Screw Right Clamp Left Clamp Phone Side... -
Page 4: Inserting Phone
Inserting Phone Fig.3 Fig.2 Fig.1 UNLOCK Insert phone into left clamp. Slide top clamp into Rotate to unlock top clamp. uppermost position. - Page 5 Inserting Phone (cont.) Fig.6 Fig.5 Fig.4 Ensure phone is flat as possible Squeeze and pull right Release right clamp to to adapter. clamp past edge of phone. secure phone.
-
Page 6: Align & Lock
For Apple dual camera phones, the primary camera is the one closest to the corner. Use photo or video mode only. For Android, the primary camera can be determined by which does not show an image in your app while blocking the individual camera. For the latest instructions on multiple camera phones, please visit www.carson.com/hookupz700. - Page 7 Align & Lock (cont.) Fig.11 Fig.12 Fig.10 LOCK While holding top clamp Figure 11 shows a properly Before attaching binocular, make sure your binocular is tight to phone, rotate to aligned camera. If needed, use alignment screw and top lock. focused.
-
Page 8: Attaching To Optic
Attaching to Optic Fig.13 Fig.14 Fig.15 Select the optic adapter ring that best fits your Phone can be positioned Align optic adapter over binocular eyepiece and in either portrait or eyepiece and press down insert it into the optic firmly. Be careful not to landscape mode. - Page 9 Attaching to Optic (cont.) Fig.16 Fig.17 Fig.18 To maximize your image, Ensure that optic adapter Turn on camera. If image is not centered, repeat pinch to enlarge image. is flush to the eyepiece of alignment steps. your binocular. For best results, use in video mode.
-
Page 10: Frequently Asked Questions
TO REMOVE PHONE FROM ADAPTER: To save your alignment, make no further adjustments to the top clamp and alignment knob. Simply remove phone using right clamp only as shown in Fig. 4. USING ADAPTER AGAIN: The alignment of your phone to the adapter should be saved from the initial setup, so many steps can be skipped (FIG 1-2, 7-10) and only a quick fine adjustment of the alignment may be needed. - Page 11 Q3: I can’t align my phone vertically with the top clamp, it won’t fit. What do I do? A3: If you go through the alignment process, and there is no way to achieve vertical alignment because it’s restricted by the top clamp, try removing your phone case. Alternatively, you can remove top clamp assembly using screw as shown below in left figure.
- Page 12 Q5: My phone doesn’t seem to work with adapter, how do I know which ones will work? A5: Please see the smartphone sizing guide below. S MA R T P H O N E S I Z I N G G U I D E If your phone (in it's case) fits in "portrait"...
- Page 13 Q7: My image is not centered or is not a complete round image, what is wrong? A7: Adjust phone alignment in vertical direction using top clamp (FIG 10), and in horizontal direction by using alignment screw (FIG 8). Check that phone is flat on adapter (FIG 6), and adapter is flush with optic (FIG 16).
-
Page 14: Tips And Tricks
Tips & Tricks: PHOTOGRAPHY • Tap object of interest on your phone screen to autofocus. • For videos, tap and hold object of interest on phone screen for a second to lock focus. Tap again to release the focus lock. •... -
Page 15: Storage/Cleaning Information
• Adapter should be cleaned with soft, damp cloth only. Do not use any chemicals or abrasives. Customer Service: We will be happy to help you with any problems you may experience with your HookUpz Smartphone Binocular Adapter. Email us at info@carson.com or call toll-free at 1-800-967-8427. - Page 16 100 Lauman Lane, Suite A, Hicksville, NY 11801 Tel: (877) 877-7274 | Fax: (516) 801-2046 Email: Info@nyscopes.com www.microscopeinternational.com...
