- Page 1 All Restoration Hardware cribs are designed to meet the highest safety standards and comply with all U.S. and Canadian cribs and cradles regulations. Page 1 of 13...
-
Page 2: Customer Service
Assembly Instructions For Crib Model No: 5783−0612 Restoration Hardware Baby & Child ˆRowan Collection˜ 2900 North Macarthur Drive Model No: 5983−0612 Tracy, California 95376 ˆRowan Collection˜ restorationhardware.com Made in China Distributed in the U.S.A. by: Restoration Hardware Baby & Child... - Page 3 Check this product for damaged hardware, loose joints, missing parts or sharp edges before and after assembly and frequently during use. DO NOT use crib if any parts are missing, damaged or broken. Contact Restoration Hardware for replacement parts and instructional literature if needed. DO NOT substitute parts.
- Page 4 IMPORTANT SAFETY INFORMATION FOR CRIBS WARNING Do not use this crib if the enclosed or attached instructions cannot be strictly adhered to. Do not use this crib if the child is able to climb out unaided or is taller than 90 cm. Do not place cords, straps or similar items that could become wound around the child’s neck in or near this crib.
- Page 5 Item Identification For ease of identification, all parts are labeled to correspond to the Step number in which the part is used. Step #5 Stationary side assembly (Page 10 of 13) Step #8 Toddler rail assembly (Page 13 of 13) Step #3 Mattress support height adjustment (Page 8 of 13)
- Page 6 STEP #1 TURNED FEET & SIDE FRAME ASSEMBLY Turned Feet (x 4) Insert threaded bolt in turned foot into Side Frame (x 2) bottom of side frame and tighten until snug. Do not over tighten. Side frames Threaded bolt Turned foot Turned foot Turned foot Bottom of...
- Page 7 Hardware needed for Step #2: STEP #2 (AA) K.D. Barrel Nuts (x 4 pieces) SIDE FRAME & (BB) 3-1/8 in. Bolts (x 4 pieces) STRETCHER BAR ASSEMBLY (CC) Dowel Pin (x 4 pieces) (DD) Allen Wrench (1 piece) Side Frame (x 2) Stretcher Bar (x 2) Detail A Insert barrel nuts into...
- Page 8 Hardware needed for Step #3: STEP #3 (EE) Mattress nut (x 4 pieces) MATTRESS SUPPORT (FF) 1-3/8 in. Mattress bolt (x 4 pieces) HEIGHT ADJUSTMENT (GG) Mattress washer (x 4 pieces) (HH) 3/8 in. lock washer (x 4 pieces) Mattress support (x 1) (DD) Allen Wrench (1 piece) Note: Do not fully tighten at this time.
- Page 9 Hardware needed for Step #4: STEP #4 (EE) Mattress nut (x 4 pieces) MATTRESS SUPPORT (FF) 1-3/8 in. Mattress bolt (x 4 pieces) ATTACHMENT TO (GG) Mattress washer (x 4 pieces) STRETCHER BARS (HH) 3/8 in. lock washer (x 4 pieces) (DD) Allen Wrench (1 piece) Mattress support (x 1) Note: Do not fully...
- Page 10 Hardware needed for Step #5: STEP #5 (II) 2-5/8 in. Bolt (x 4 pieces) STATIONARY SIDE (DD) Allen Wrench (1 piece) ASSEMBLY Stationary Side (x 1) Note: Do not fully tighten at this time. Stationary Side (II) Detail A (DD) Hardware Step #5 (II) 2-5/8 inch bolt (x 4 pieces) (DD) Allen Wrench (1 piece)
- Page 11 Hardware needed for Step #6: STEP #6 (KK) Upper bushing (x 2 pieces) DROP SIDE ASSEMBLY (LL) Lower guide stud (x 2 pieces) (MM) Upper bushing screw (x 2 pieces) Drop side (x 1) To attach drop side, insert top of upper track on to upper bushing on both ends. Then align lower guide stud with slot in lower track of drop side.
- Page 12 STEP #7 DROP SIDE OPERATION Stand at the middle of the drop side and hold the top rail with one hand. Raise the drop side slightly to enable you to release the latch by pushing on the drop side with your knee. The drop side will now lower.
- Page 13 Hardware needed for Step #8: STEP #8 (JJ) 1/2 in. Bolt (x 2 pieces) TODDLER RAIL ASSEMBLY (DD) Allen Wrench (1 piece) (MM) Upper bushing screw (x 2 pieces) Toddler Rail (x 2) Note: Remove (KK) top bushings & (LL) bottom Detail A studs.
