- Page 1 Installation and operating instruction Room device WEM-RG2 83307102 2/2017-11...
-
Page 2: Table Of Contents
Installation and operating instruction Room device WEM-RG2 User instructions ...................... 3 1.1 Target group ........................ 3 1.2 Symbols .......................... 3 1.3 Guarantee and Liability .................... 4 Safety ............................. 5 2.1 Designated application .................... 5 2.2 Safety measures ...................... 5 2.3 Disposal ......................... 5 Product description ... -
Page 3: User Instructions
Installation and operating instruction Room device WEM-RG2 1 User instructions 1 User instructions This manual forms part of the equipment and must be kept on site. Translation of original Carefully read the manual prior to working on the unit. operating instructions It is supplemented by the installation and operating instructions for the condensing unit. -
Page 4: Guarantee And Liability
Weishaupt parts, force majeure, the installation of additional components, which have not been tested with the unit. -
Page 5: Safety
Room device WEM-RG2 2 Safety 2 Safety 2.1 Designated application The room device in conjunction with the Weishaupt Energy Management WEM is suitable for: the operation of up to 3 heating circuits, the operation of a DHW circuit. The unit should only be used in enclosed rooms. -
Page 6: Product Description
Installation and operating instruction Room device WEM-RG2 3 Product description 3 Product description 3.1 Type key WEM-RG2 … Type: Weishaupt Energy Management Type: room device comfort version … Version 3.2 Technical data 3.2.1 Electrical data Voltage supply DC 15 … 26 V Consumption max 0.7 W... -
Page 7: Installation
Installation and operating instruction Room device WEM-RG2 4 Installation 4 Installation Remove room device from wall bracket Place a suitable screwdriver into the recess 1 and disengage the room device in the direction of the arrow. Remove room device. Pull off protective foil Pull off protective foil. - Page 8 Installation and operating instruction Room device WEM-RG2 4 Installation Fit wall bracket and connect Risk of electric shock Working on the device when voltage is applied can lead to electric shock. Isolate the device from the power supply prior to starting any work.
-
Page 9: Operation
Installation and operating instruction Room device WEM-RG2 5 Operation 5 Operation 5.1 Display and operating unit 1 Dial knob turn navigation through parameter structure; changing values press briefly: confirm or save values approx. 3 seconds: exit value without saving approx. 5 seconds: return to the start screen... -
Page 10: Display
Installation and operating instruction Room device WEM-RG2 5 Operation 5.2 Display Start screen Thursday 2016-06-23 16:55 Heating circuit 1 Room temperature 7 °C °C 23.5 50 °C Time program 1 Normal 1 Current heating circuit being accessed (heating circuit assigned to HC operating access 1 ). - Page 11 Warning 1 No flame formation at burner start Humidity in room too high Note down display and inform your heating engineer or Weishaupt's customer service. Service If the service interval of the condensing unit is exceeded, a message appears in the display.
-
Page 12: Favourites Level
Installation and operating instruction Room device WEM-RG2 5 Operation 5.3 Favourites level Frequently used user level parameters can be assigned as favourites. It is possible to assign a maximum of 6 favourites. Factory pre-assigned favourites can be replaced by parameters from the user level. -
Page 13: User Level
Installation and operating instruction Room device WEM-RG2 5 Operation 5.4 User level Select User level using dial knob and confirm. Display changes to the User level. Thursday 2016-06-23 16:55 Heating circuit 1 User Room temperature 7 °C °C 23.5 Domestic hot... -
Page 14: Info
Installation and operating instruction Room device WEM-RG2 5 Operation 5.4.1 Info Info In menu Info, the information is read only. Information Description Current temperature at the external sensor. External temperat- Current temperature at the DHW sensor. temperature Current temperature at the DHW outlet sensor (version C). - Page 15 Installation and operating instruction Room device WEM-RG2 5 Operation The following information can be displayed on the start screen [ch. 5.2]. Select information required and confirm. Select and confirm Info on start screen?. Select information, which is to be replaced and confirm.
-
Page 16: Heating Circuit
Installation and operating instruction Room device WEM-RG2 5 Operation 5.4.2 Heating circuit Heating circuit If operating access was assigned to multiple heating circuits, a separate menu ap- pears for each heating circuit. Parameters Setting determines the type of operation of the heating circuit. - Page 17 Installation and operating instruction Room device WEM-RG2 5 Operation Parameters Setting Room setpoint temperature for the temperature level selected. Comfort (factory setting: 22.0 °C) Room setpoint Normal (factory setting: 21.0 °C) temperature Setback (factory setting: 16.0 °C) The levels can be assigned to specific times of the day using parameter Heating program .
-
Page 18: Domestic Hot Water
Installation and operating instruction Room device WEM-RG2 5 Operation 5.4.3 Domestic hot water Domestic hot water Parameters Setting DHW temperature for normal and setback operation. Normal (factory setting: 50 °C) DHW setpoint Setback (factory setting: 40 °C) temperature Normal and setback operation can be assigned to specific times of the day using the DHW program. -
Page 19: Statistic
Installation and operating instruction Room device WEM-RG2 5 Operation 5.4.4 Statistic Statistic In the Statistic menu, daily, monthly and annual values relating to the energy generated are displayed. Information Description Total amount of heat generated by the condensing unit. Energy WTC Total Solar system yield. -
Page 20: Settings
Installation and operating instruction Room device WEM-RG2 5 Operation 5.4.5 Settings Settings Parameters Setting Set language. Language Adjust the brightness of the display. Automatic (factory setting): The brightness of the display is regulated depending on the brightness of the room. -
Page 21: Operating Mode
Installation and operating instruction Room device WEM-RG2 5 Operation 5.5 Operating mode Determines the operating mode of the heating circuit. The heating circuit assigned is shown in the display above with the corresponding number. The assignment can be changed on the system device in menu Commis- sioning →... -
Page 22: Room Setpoint Temperature
Installation and operating instruction Room device WEM-RG2 5 Operation 5.6 Room setpoint temperature Stipulates the room setpoint temperature for the temperature level selected. Comfort (factory setting: 22.0 °C) Normal (factory setting: 21.0 °C) Setback (factory setting: 16.0 °C) Select the room setpoint temperature with the knob and confirm. -
Page 23: Technical Documentation
Installation and operating instruction Room device WEM-RG2 6 Technical documentation 6 Technical documentation 6.1 Control options 6.1.1 Constant flow temperature No additional sensors or thermostats are required for this control. The flow temperature from the heating circuit is controlled to the flow setpoint tem- perature set in the user level, see [ch. 5.4.2]. -
Page 24: Room Temperature Dependent Control
Installation and operating instruction Room device WEM-RG2 6 Technical documentation 6.1.3 Room temperature dependent control The flow temperature is controlled depending on the room temperature. A room device or room sensor are required for room temperature dependent con- trol. Avoid direct solar radiation and heat up by external heat sources at the room sensor. -
Page 25: Notes
Installation and operating instruction Room device WEM-RG2 7 Notes 7 Notes 25-28 83307102 2/2017-11 La... -
Page 26: Key Word Index
Installation and operating instruction Room device WEM-RG2 8 Key word index 8 Key word index Heating program .............. 16 Holiday................... 17 Ambient conditions............... 6 Humidity .................. 6 Assignment................ 14 Illumination................ 20 Brightness ................ 20 Info.................. 14 Buffer storage temperature .......... 14 Installation location ............... 5 Capacity ................ 14 Language ................ 20... - Page 27 Installation and operating instruction Room device WEM-RG2 8 Key word index Type of protection.............. 6 User level ................ 13 Version.................. 6 Voltage supply ............... 6 Wall bracket ................ 8 Wall bracket ................ 7 Warning................. 11 Weather compensation ............. 23 27-28 83307102 2/2017-11 La...
- Page 28 Max Weishaupt GmbH · 88475 Schwendi Weishaupt close by? Addresses, telephone numbers etc. can be found at www.weishaupt.de We reserve the right to make changes. All rights reserved. The complete program: Reliable technology and prompt, professional service W Burners up to 570 kW...
