This manual uses the following symbols for easy understanding safety instructions. Always follow
these instructions carefully.
WARNING
CAUTION
WARNING
Important Notice
Always follow this safety instruction to prevent death or injury.
Follow this safety instruction to avoid possible injury or damage to your
property.
Symbol "△" is a CAUTION or WARNING label indicating the safety
instruction.
This symbol is an Electrical Shock WARNING label.
Symbol is an instruction that you must not violate.
(This symbol instructs NOT to disassemble the system components)
Symbol is an operation instruction that you must follow.
(This symbol shows the main power OFF instruction.)
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart7 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Haiyang Smart7 Series

Summary of Contents for Haiyang Smart7 Series

  • Page 1 Important Notice Pictorials This manual uses the following symbols for easy understanding safety instructions. Always follow these instructions carefully. WARNING Always follow this safety instruction to prevent death or injury. Follow this safety instruction to avoid possible injury or damage to your property.
  • Page 2 WARNING <For System Operators> Always follow this instruction to prevent death or personal injury. If smoke or a small of burning occurs, a fire or an electrical Turn power off short circuit may result. Turn the power switch OFF and shut During down the power supply immediately.
  • Page 3 Installation Cautions <For service Personnel> Follow installation instructions to avoid personal injury and system malfunction. Installation in Mount your Smart7/8/10 series on a rigid frame or base to prevent your rigid location. unit from working loose. Use the installation materials provided in the standard accessory pack Use correct only.

  • Page 4: Maintenance Cautions

    Maintenance Cautions<For Maintenance Personnel> Use the following safety precaution internal inspection. High voltage may be retained in the capacitors if the high-tension Discharge capacitors. circuit several minutes after you has turned the power switch off. To prevent an electrical injury due to erroneous power switching, make Check that power is sure that the main power supply and the system power switch are both in the off position.

  • Page 5: Operation Notes

    Operation Notes <For operators> Observe the following operation notes, otherwise the system failure or deterioration can result. And periodical inspection and maintenance are required for keeping the system in an optimum condition. The waypoint and other registered data may become unreadable by Backup important data.
  • Page 6 - 6 -...
  • Page 7 Smart7/8/10 System Welcome Smart7/8/10 series opens a new chapter of performance and integration in vessel navigation system display and management. Whether you are a Cruiser or Sport fisherman or both, Smart7/8/10 gives you the information you need. CAUTION Smart7/8/10 series is Color LCD Charting Systems employs the latest in proven technology to provide accurate navigation information.
  • Page 8 Smart7/8/10 Series System Welcome The Smart7/8/10 series opens a new chapter of performance and integration in vessel navigation system display and management. Whether you are a Cruiser or Sport fisherman or both, Smart7/8/10 gives you the information you need. CAUTION The Smart7/8/10 series employs the latest in proven technology to provide accurate navigation information.
  • Page 9 Smart7/8/10 Series System DISPLAY BREAKAGE WARNING The LCD display module contains a liquid. If the display is broken and the liquid contacts your skin, wash it off immediately in running water for 15 minutes. If the liquid contacts your eyes, immediately flush your eyes with running water for 15 minutes.
  • Page 10 - 10 -...

  • Page 11: Getting Started

    Getting Started 1. The Keyboard Description use this to select menu items, move the on-screen cursor and Choosing the frequency Rotary: use this to select menu items and Adjustment of gain & STC level with turning. Button: push the end of the everything to confirm a selection or entry Change the chart of scale and Setting up the depth range Open the menu Setting up Fishfinder mode...
  • Page 12 1.1. How to (Fig.1.1) 1.1.1. Turn on Switch on. 1.1.2 Turn off Keep pressing to switch off. 1.1.3. Adjust brightness Pressing (Fig.1.1) and controlling the brightness with [◀] [▶]. 1.1.4. Use day/night mode Pressing (Fig.1.1) and changing the day and night with [▲][▼]. - 12 -...
  • Page 13 2. Specification of the connectors 2.1. Metal connectors - 13 -...
  • Page 14 2.2. Plastic connectors - 14 -...
  • Page 15 3. Screen Overview 3.1. Fishfinder Page ① ② ③ ④ ⑤ ⑥ ⑦ ① Palette Showing the chosen colors. ② Depth bar The current depth. ③ Low Frequency Showing 50KHz. ④ High Frequency Showing 200KHz. ⑤ LF INFO The information of Low Frequency, 50KHz. ⑥...
  • Page 16 3.2. Navigation Data Page 3.2.1. Navigation Data Type1 3.2.2. Navigation Data Type2 - 16 -...
  • Page 17 3.3. Highway Page ⑥ ① ② ③ ④ ⑤ ① WPT name The current WPT name. ② Direction of steer The best direction of the steering. ③ WPT icon The remaining distance of the WPT. ④ Vessel The out of the range from the best. ⑤...
  • Page 18 3.4. Steering Page ④ ① ② ③ ① WPT name Name of the WPT. ② Direction of steer The best direction of the steering. ③ WPT icon Showing the WPT and the bearing ④ Navigation Data Information of the various data. - 18 -...
  • Page 19 4. Databar Showing various data on the top or bottom. 4.1. Position ▶[MENU]->Setup->Customizing->Databar->Position Databar has three meanings as below. 4.2. Edit ▶[MENU]->Setup->Customizing->Databar->Edit When finishing the set up, press to exit. (*Please, refer “Customizing” for further question.) 4.3. Position ▶[MENU]->Advance->Setup->Customizing->Databar->Position Setting the databar position on the top or bottom. - 19 -...
  • Page 20 5. Page ▶[MENU]->Others->[PAGE]Key Choosing the various pages that set up pages or customized. Move the red box to choose the page. Selected (red color) (Fig.1.2) 5.1. Page mode Two ways to choose the page. 5.1.1. Standard With seeing the set up page, choosing the page or modifying. 5.1.2.
  • Page 21 (Fig.1.2.1) Choosing the frame with [◀][▶]. Two frames as (Fig 1.2.2). (Fig.1.2.2) After choosing the box, choose the page as (Fig.1.2.3). (Fig.1.2.3) When finishing, press to exit. - 21 -...
  • Page 22 6. Active ▶[MENU]->Others->[ACTIVE]Key When pressing [ACTIVE], the red box moves to to chartplotter or fishfinder. Selected (red color) - 22 -...

  • Page 23: Navigation Data

    7.Navigation Data Navigation data is available in Navigation data page, Steering page, Highway page as (Fig.1.3). (Fig.1.3) 7.1. Type ▶[MENU]->Advance->Setup->Customizing->Navigation data->Type Two types of Navigation data page. 7.1.1.Type1 Large LAT/LOT as (Fig.1.3.1). (*Editing the LAT/LOT is unavailable) 7.1.2. Type2 Various data as (Fig.1.3.2). (Fig.1.3.1) (Fig.1.3.2) 7.2.
  • Page 24 (Fig.1.3.3) 8. Save WPT ▶[MENU]->Others->WPT->Save WPT WPT is stored in the external Micro SD. So if you want to save the userdata, a micro SD must be inserted in the slot. (*Userdata is in “..\HY\UserData\”) 9. Load WPT ▶[MENU]->Others->WPT->Load WPT WPT loads from the stored micro SD.
  • Page 25 Fishfinder getting started 1. Choosing the frequency In dual frequency mode, choosing the frequency with [▲][▼]. (*The chosen frequency shows in red) Selected 2. Auto/Manual Gain Press [ENTER] to choose” AUTO/Manual” of Gain. 3. Gain/STC Choose “Gain” and “STC” with [◀][▶]. 4.
  • Page 26 1. Choose the frequency. 2. Choose the STC. 3. Adjust the STC using the [+] [-] key. 6. Mode ▶[MENU]->Mode Four kinds in Fishfinder. 6.1. Normal Normal mode (with Auto Range active) displays the sounder image with the surface at the top of the screen and the sea bottom in the lower part of the screen.
  • Page 27 above the sea bottom to aid in determining distances of echoes near the bottom. Use the Sounder Menu to set the magnified Bottom Range from 2.5 to 20m (10 to 60ft.). Default setting is 10m (40ft.). If the depth Range is set manually, the setting must place the sea bottom echo in the lower portion of the screen for Bottom Zoom to be effective.
  • Page 28 6.4. Part Zoom Shows an enlarged fishfinder screen of the set range. You can show the screen of left is normal screen and screen of right is part zoom Set the depth range (it displays green) - 28 -...
  • Page 29 7. VRM ▶ [WPT] The VRM (movable marker) shown by the green line can be moved up and down. It is convenient to measure the depth by aligning with the target such as school of fish. [Fig.2.1] 8. Scroll ▶[MENU]->6. Scroll. This function allows the users to view the screen in the past fishfinder image.
  • Page 30 - 30 -...

  • Page 31: Operation

    Operation 1. Deep Depth Range Smart7/8/10 selects the best condition for measuring the depth automatically in the environment of the sea. ☞ The default setting is Auto.) 2. Shift A user selects this function to see more detailed bottom of the sea. When you turn up the shift, the range of Fish finder shall go up from the shift range.
  • Page 32 3.5.Depth 3.5.1. Display Shown/Hidden the depth range on the screen. ☞ The default setting is shown.) 3.5.2. Font Size Select the depth range font size on the screen. ☞ The default setting is Large.) 3.6. TEMP 3.6.1. Display Shown/Hidden the temperature on the screen. ☞...
  • Page 33 ☞ The default setting is Off.) 3.10. Image filtering This function is reduction of the noise. (☞ The default setting is On.) 4. Rejection 4.1. Interference Rejection When there are another boats around you on sailing, your Fish finder could be disturbed to work. The step of the function is from off to level 2.
  • Page 34 Select the output from the installed transducer. Levels are from off to 3. It should be careful about the depth. If you set high level in a shallow depth, the Fish finder screen turns to red. You see nothing expect red on the screen. ☞...
  • Page 35 8.2.4. Low range It alarms when the set low temperature is out of the range. ☞ The default setting is 0.) 8.3. Fish-School 8.3.1. Alarm It alarms when it detects school of fish. It will detect school of fish depend on set depth, range and level of the Echo sounder. ☞...
  • Page 36 (☞ The default setting is Nm/Kt.) 9.2.2. Depth Select desired unit of measure for depth of water. Choose from: meter(M), foot(ft), fathom(fm), Italian Fathom(Ifm), Japanese fathom(Jfm). cf) 1m = 3.281ft = 0.549fm = 0.609lfm = 0.660jfm ☞ The default setting is Meter.) 9.2.3.
  • Page 37 $GPGGA Global positioning system fix data $GPVTG Course over ground and ground speed $GPRMC Recommended minimum specific GNSS data 9.4.2. Transmit Available to adjust transmit speed of input/output in each ports. 9.5. Correction 9.5.1. Boat Speed The tolerance of boat speed value can be corrected. When the [Speed source] is set to the [Sensor], it is corrected by %.
  • Page 38 It customizes the Navigation data section except activated the echo sounder section. 9.7.3. Page mode It is a select the page mode. - Standard: Choosing Page and customizing is available. - Flip: Showing the chosen pages in order. ☞ The default setting is Standard.) 9.8.
  • Page 39 You can set whether to use the remote control. 9.10.4.2. Remote control register The remote control allows you to register your product. 9.10.4.3. Remote control unregister This is used to unregister the remote control. 10. Others 10.1. Key Setup It is available to set up [FUNK] key and [EVENT] key on the JFC.7050. 10.1.1.
  • Page 40 Shown the WPT list and it is available to set up or edit the WPT on the list. ① ⑤ Selected(blue color) ⑥ ⑧ ⑦ ② ③ ④ ⑨ ① List Showing all of the stored WPT. ② Name Name of the WPT. ③...
  • Page 41 10.2.2.2. Arrival Radius: It is to adjust the range of arrival from your waypoint. If you have a route, it changes to the next waypoint automatically. ☞ The default setting is 0.05nm.) 10.2.2.3. XTE Alarm: If you are out of the course, it gives you a notice with alarm. ☞...
  • Page 42 10.7. [ACTIVE] Key Select the activated section. 10.8. [PAGE] Key Select the configuration you wish. 10.9. Save User Setting Storing the user initialization for the default. The current is storing. 10.10. Pluse Select the pulse of the output from the transducer. Levels are among Low, Medium and High, which depends upon the depth.
  • Page 43 HD-770F GENERAL SPECIFICATION 1. Display Screen: 7inch Color LCD with LED backlight 2. Resolution: WVAG (800 X 480 pixels) 3. Power Supply: DC 12V~36V(+-10%) 9W 4. Operating Temperature: -15°C~+50°C 5. Performance Standard: IMO Resolution MSC.112(73) 6. Option: MicroSD, Transducer FISHFINDER SPECIFICATION 1.
  • Page 44 HD-880F GENERAL SPECIFICATION 1. Display Screen: 8inch Color LCD with LED backlight 2. Resolution: WVAG (800 X 600 pixels) 3. Power Supply: DC 12V~36V(+-10%) 13W 4. Operating Temperature: -15°C~+50°C 5. Performance Standard: IMO Resolution MSC.112(73) 6. Option: MicroSD, Transducer FISHFINDER SPECIFICATION 1.
  • Page 45 HD-1000F GENERAL SPECIFICATION 1. Display Screen: 10.2inch Color LCD with LED backlight 2. Resolution: WVAG (800 X 480 pixels) 3. Power Supply: DC 12V~36V(+-10%) 16W 4. Operating Temperature: -15°C~+50°C 5. Performance Standard: IMO Resolution MSC.112(73) 6. Option: MicroSD, Transducer FISHFINDER SPECIFICATION 1.
  • Page 46 - 46 -...
  • Page 47 Customizing items LAT/LOT of the present position. (Red: out of GPS service/Black: GPS on service/Blue: SBAS or DGPS on service) (Speed Of Ground) Boat speed. (Course Of Ground) Boat direction. DATE Date of today. TIME Present time. HDOP Horizontal Dilution Of Precision. PDOP Position Dilution Of Precision.
  • Page 48 - 48 -...

  • Page 49: Display Unit Installation

    Display Unit Installation Smart7/8/10 series brings expandable display technology to your bridge or navigation station. A careful installation will assure maximum benefit from Smart7/8/10 series integrated features. Display Unit Location Select a location for your Smart7/8/10 series display unit that provides easy viewing from all likely operator’s positions.
  • Page 50 Install the display unit into the mounting bracket. Check alignment and operation of the pivots and security of the mounting. Make any adjustments necessary to prevent binding and assure even meshing of the pivot locking washers. It is advised to remove the display unit and store it in a safe place to prevent damage during the rest of the installation process.
  • Page 51 [Smart10 Flush Mounting] [Smart7/8 Flush Mounting] - 51 -...

  • Page 52: Power Connection

    - Power Connection Power is supplied to the Smart7/8/10 series Charting System through a connector on the rear panel of the display unit. Route the power cable from the Smart7/8/10 series location to the ship’s power distribution panel. Connect the black wire to a battery negative (-) terminal of the power panel. Connect the white wire to a fused battery positive (+) terminal of the power panel ( 12 to 24 Vdc nominal).

  • Page 53: Transducer Installation

    Therefore, installation should be attempted only by qualified individuals. If you have any doubt about your ability to complete the process successfully, we recommend you obtain the services of a HAIYANG dealer or marine service center with knowledge and experience in transducer installation.
  • Page 54 For boats with poor water flow under the transom or on in-boards, consider selecting a through-hull transducer. HAIYANG offers many styles of transducers. Determine the transducer mounting place by referring to the steps mentioned above. For best result, the transducer face should be level.
  • Page 55 Through-hull transducers are recommended for in-boards and other vessels with disturbed water flow under the transom. HAIYANG offers several models of bronze through-hull transducers. To enjoy the full capability of your Sonar, select a dual frequency model with temperature sensor. Sturdy bronze construction assures a secure installation and provides a strong base for fairing blocks, if needed, to compensate for hull shape.
  • Page 56 Best Location Water Line Drifting Water Line Cruising Stem Fixing Nut Hull Marine Sealant Through-hull Transducer Maintenance If your boat is kept in the water, performance of your digital fishfinder will be adversely affected by accumulations of sea growth on the face of the transducer. To prevent sea growth effects, the face of the transducer may be coated with antifouling paint specially formulated for transducers.
  • Page 57 regular antifouling paint on the face of the transducer. The bronze housing may be coated with any antifouling paint. If fairing blocks are used, especially if made of wood, complete sealing prior to painting is important. Stem Marine Sealant Fixing Inner Fairing Block Outer Fairing Block Hull...
  • Page 58 - 58 -...
  • Page 59 - 59 -...
  • Page 60 - 60 -...
  • Page 61 - 61 -...
  • Page 62 - 62 -...
  • Page 63 - 63 -...
  • Page 64 - 64 -...

  • Page 65: Declaration Of Warranty

    Web-site: http://www.haiyang.co.kr Guarantee for One Year Haiyang Electronic Equipment Co., LTD warrants the produced equipment, Equipment for One (1) year for guarantee as bellows. 1. Main Unit: One (1) year guarantee after a user purchases the product within one (1) year 2.
