English CONTENTS GENERAL POWER TOOL SAFETY WARNINGS ........22 CORDLESS PLANER SAFETY WARNINGS ..........25 CAUTION ON LITHIUM-ION BATTERY ............25 SYMBOLS ....................27 SPECIFICATIONS ..................27 STANDARD ACCESSORIES ............... 28 OPTIONAL ACCESSORIES (sold separately)..........29 APPLICATIONS .................... 29 BATTERY REMOVAL/INSTALLATION ............29 CHARGING ....................
Page 23
English Electrical safety a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodifi ed plugs and matching outlets will reduce risk of electric shock. b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators.
Page 24
English g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards. Power tool use and care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
English Service a) Have your power tool serviced by a qualifi ed repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. CAUTION Keep children and infi rm persons away. When not in use, tools should be stored out of reach of children and infi rm persons. CORDLESS PLANER SAFETY WARNINGS Wait for the cutter to stop before settling the tool down.
Page 26
English In the cases of 1 to 3 described below, when using this product, even if you are pulling the switch, the motor may stop. This is not the trouble but the result of protection function. When the battery power remaining runs out, the motor stops. In such case, charge it up immediately.
English If you fi nd rust, foul odor, overheating, discolor, deformation, and/or other irregularities when using the battery for the fi rst time, do not use and return it to your supplier or vendor. WARNING If an electrically conductive foreign object enters the Ventilation holes terminals of the lithium ion battery, a short-circuit Terminals...
English STANDARD ACCESSORIES In addition to the main unit (1 unit), the package contains the accessories listed in the below. P14DSL P18DSL P14DSL P18DSL P14DSL P18DSL (2LSRK) (2LSRK) (2LJRK) (2LJRK) (NN) (NN) Box Wrench (for securing cutter blade) Set Gauge (for adjusting cutter height) Guide...
English CHARGING Before using the power tool, charge the battery as follows. Battery Connect the charger’s power cord to the receptacle. When the power cord is connected, the charger’s pilot Pilot lamp lamp will blink in red. (At 1-second intervals) CAUTION Do not use the electrical cord if damaged.
Page 31
English Regarding the temperatures of the battery The temperatures for batteries are as shown in Table 2, and batteries that have become hot should be cooled for a while before being recharged. Table 2 Recharging ranges of batteries Temperatures at which the battery Batteries can be recharged BSL1430, BSL1440, BSL1450,...
Remove the cord from the power and then connect it again after 30 seconds or so. If this does not cause the pilot lamp to blink in red (every second), please take the charger to the HiKOKI Authorized Service Center. PRIOR TO OPERATION Setting up and checking the work environment Check if the work environment is suitable by following the precautions.
Page 33
English CAUTION Do not fi x and secure the switch lock. Besides, keep your fi nger off the switch trigger when the planer is being carried around. Otherwise, the main body switch can be inadvertently turned ON, resulting in unexpected accidents. About remaining battery indicator Remaining battery Remaining battery...
Page 34
English Beginning and ending the cutting operation Beginning of As shown in Fig. 12, place the front base of the planer on cutting operation the material and support the planer horizontally. Turn ON the power switch, and slowly operate the planer toward the leading edge of the material.
English CARBIDE BLADE ASSEMBLY AND DISASSEMBLY AND ADJUSTMENT OF CUTTER BLADE HEIGHT (FOR DOUBLE EDGED BLADE TYPE) Carbide blade disassembly Box wrench Blade holder CAUTION To prevent accidents, ensure that the power ○ tool is switched off and pull out the battery. Be careful not to injure your hands.
Page 36
English Blade holder As shown in Fig. 21, use the box wrench to loosen the Box wrench three bolts used to retain the carbide blade, and remove the blade holder. As shown in Fig. 22, after removing the carbide blade, slide set plate (B) in the direction indicated by the arrow Bolt to disassemble set plate (B).
English BLADE ASSEMBLY AND DISASSEMBLY AND ADJUSTMENT OF BLADE HEIGHT (FOR RESHARPENABLE BLADE TYPE) Blade (Resharpenable Blade disassembly Set plate (A) blade type) CAUTION To prevent accidents, ensure that the power ○ tool is switched off and pull out the battery. Be careful not to injure your hands.
English Blade (Resharpenable Press the turned surface of set plate (A) to the blade type) wall surface b while adjusting the blade edge Set plate (A) to the wall surface a of the set gauge. Then, Wall surface a tighten them with the 2 screws. Set gauge Turned (Fig.
English Attaching the dust adapter Remove the screw D4 × 16 in the chip cover and Screw remove the chip cover as shown in Fig. 36. D4 × 16 Mount the dust adapter and secure with the screw D4 × 16. (Fig. 37) NOTE Chip cover Take care not to break the catch when attaching...
Page 40
English NOTE When replacing the carbon brush with a new one, be sure to use the HiKOKI Carbon Brush Code No. 999017. Replacing carbon brushes After removing the chip cover, take out the carbon Brush cap brush by fi rst removing the brush cap and then Fig.
Page 41
Repair, modifi cation and inspection of HiKOKI Power Tools must be carried out by a HiKOKI Authorized Service Center. This Parts List will be helpful if presented with the tool to the HiKOKI Authorized Service Center when requesting repair or other maintenance.
English SERVICE PARTS LIST 35 36 60-1 60-2 502 503 504 505...
Page 43
English Item Item Part Name Q’TY Part Name Q’TY CUTTER BLOCK ASS’Y BRUSH HOLDER (W/B.B) (W/FERRITE CORE) PLANER BLADES BELT COVER BELT SET PLATE (B) SET PLATE (A) PULLY (B) WASHER M4 END BRACKET ARMATURE DC 14.4V MACHINE SCREW M4 × 5 BLADE HOLDER FAN GUIDE BOLT M6...
