2D Mouse Buttons
Use these buttons to map the functions of the
three 2D mouse buttons.
Change Sensitivity
These buttons maps the Increase/Decrease
Sensitivity functions, either for collective
(translation or rotation) or individual (X, Y, Z,
A, B or C) degrees of freedom. The dialbox
buttons are used to map the sensitivity control
of the dialbox mode.
Predefined Button Mappings
A list of the predefined mapping codes
available for the current application is
displayed here. Click a mapping code to map
the function to the selected Magellan/SPACE
MOUSE button.
Motion Control Center
Show causes the MCC window to be brought
to the front of the screen. Hide sends the MCC
window to the back and Change toggles
between front and back. Mapping one of the
Panel buttons numbered 1 through 4 switches
the MCC to that panel number.
LPFK
The functions of the 32 buttons correspond to
the default functions that your CAD application
normally assigns the buttons of an LPFK. Use
these buttons to map the corresponding LPFK
functions. Note that some IBM and SGI
systems may require a separate installation
procedure to activate the LPFK simulation
mode. See LPFK and Dialbox Driver
Installation.
