Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
·
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
·
These instructions contain important care, cleaning, and
warranty information -
consumer
.
ORDERING INFORMATION
GABRIELLE CLASS FIVE Toilet
TM
Includes French Curve Toilet Seat
GABRIELLE
CLASS FIVE Toilet
TM
Includes CACHET Quiet-Close Toilet Seat
TM
GABRIELLE
CLASS FIVE Toilet
TM
Includes French Curve Quiet-Close Toilet Seat
NOTES
·
Observe all local plumbing and building codes.
·
Shut off the water supply.
·
Seat post holes are on 140mm (5-1/2") centers.
·
51mm (2") passageway.
·
Water depth from the rim is 127mm (6-5/8").
·
Ensure that the new drain has the correct roughing-in
dimension. This toilet has a 305mm (12") roughing-in
dimension.
See Fig. #1
·
Closet flange must be 305mm (12") on-center from wall.
·
Carefully inspect the new fixture for any sign of damage.
·
For new construction, refer to the dimensions in
and Fig. #4
for locating the shut-off valve.
·
Fixture dimensions are nominal and conform to tolerances
established by ASME Standards (A112.19.2-2008).
1176009-T01-A
please leave instructions for the
K-3322T-W
®
K-3322T-SW
K-4636T-U
K-3322T-CW
®
.
GABRIELLE CLASS FIVE
·
·
·
K-4653T
K-4713T
·
·
·
·
51mm
·
·
1
·
·
·
Fig. #1
·
2008.
-1-
TM
INSTALLATION INSTRUCTIONS
VITREOUS CHINA SIPHON JET TOILET
S-EB K-3322T-W/K-3322T-SW/K-3322T-CW
140mm
127mm
305mm
1
4
ASME
528137
Copyright Kohler China Ltd., 2011
-
K-3322T-W
K-4653T
K-3322T-SW
K-4636T-U
K-3322T-CW
K-4713T
305mm
A112.19.2-
