Spectrum Industries Inspiration Keyboard Tray Assembly Instructions

Assembly Instructions
Important
Before you begin, read and comply with all safety and operating instructions,
and ensure all parts and correct quantities are included.
Any parts damaged during shipment must be reported within 5 days of receipt. To
report information regarding missing parts or damage, to purchase parts or acces-
sories, or if you have any questions, please contact us.
www.spectrumfurniture.com
800-235-1262, 715-723-6750
Thank you for purchasing Spectrum products!
(6) 026073
#8 x 3/4" PHSM

1. Attach slide assemblies to worksurface

1. Open the lectern instructor-side door (if equipped).
2. Extend the slides.
3. Align and attach each slide assembly to the worksurface using (3)
#8 x 3/4" PHSM screws. Figure 1. (Note left and right orientation).
4. Tighten screws securely.
(1) 0141715
Keyboard Tray
Left and Right slide assemblies
consisting of:
(1pr) 0114747 14" Slide set
(2) 0141718 Keyboard bracket
(2) 0141728 Slide bracket
(4) 021588
8-32 Keps nut
L e f
t s l
i d e
a s s
e m
Inspiration Keyboard Tray
R i g
h t s
l i d e
a s s
b l y
(3) #8 x 3/4"
PHSM screw
95538
"
11
/
32
e m
b l y
0191393 Page 1 of 2
Figure 1
