XHub for Notebooks User's Guide

Daisy-Chaining XHubs

If you want to add more USB 2.0 ports to your system, Adaptec
XHubs can be daisy-chained (linked in series). You can connect up
to five XHub for Notebooks hubs. (This is a USB limitation.)
To daisy-chain XHubs:
1 Connect a power adapter to each XHub. (See
XHub on page
2 Plug the first XHub's USB cable into the USB port on your
computer.
3 Plug the next XHub's USB cable into a USB port on the first
XHub. You can use any available USB port.
1
2
3
4
Last XHub in chain
4 Repeat until all your XHubs are daisy-chained together.
10
4.)
1
2
3
4
Plugging in Your
First XHub in chain:
cable to USB port on computer
1
2
3
4
