Terra S3C32VB User Manual

32 channels dvb-s/s2 to 16/32 dvb-c transmodulators
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
32 channels
DVB-S/S2 to 16/32 DVB-C transmodulators
S3C32VB, S3C32WB
User's manual
EN
Vers. 1.02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S3C32VB and is the answer not in the manual?

Questions and answers

Related Manuals for Terra S3C32VB

Summary of Contents for Terra S3C32VB

  • Page 1 32 channels DVB-S/S2 to 16/32 DVB-C transmodulators S3C32VB, S3C32WB User's manual Vers. 1.02...

  • Page 2: Product Description

    The transmodulator can be used as a stand alone unit - headend with redundant power supply (PS) to increase reliability of supply voltages. S3C32VB – headend with 32 DVB-S/S2 input channels and 16 agile DVB-C output channels. S3C32WB – headend with 32 DVB-S/S2 input channels and 32 agile DVB-C output channels.

  • Page 3: External View

    External view Front view STATUS STATUS 10 11 12 13 14 15 16 DC OUT 1 POWER SUPPLY 1 DC OUT 2 POWER SUPPLY 2 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 RESET HEADEND ADDR.

  • Page 4: Installation Instructions

    HEADEND ADDR. - addressing indicator. It blinks on when the device is being accesed via Web interface HEADEND STATUS - error indicator. Red light indicates, that at least one error exists at the moment STATUS DC OUT 1 - indicates LNB1 powering status STATUS DC OUT 2 - indicates LNB2 powering status STATUS POWER SUPPLY 1 - indicates correct DC voltage from power supply PS1 STATUS POWER SUPPLY 2 - indicates correct DC voltage from power supply PS2...

  • Page 5: Initial Configuration

    Initial configuration Devices leave the factory with this control over Ethernet interface IP address: 192.168.1.10. In order to avoid conflicts with other IP addresses, it is necessary to perform an initial configuration in the local mode. Subsequently, it will be possible to access the device via local area network (LAN), either to change the configuration or to check the operating status.

  • Page 6: System Status Table

    Device information table This shows the following data of device: “Device model”: model of the device. “Serial number”: serial number of the device. “Software version”: device software version number. “System time”: current time, synchronized from the TDT table of the input stream or NTP server. Local time offset can be selected in the "IP settings"...
  • Page 7 Figure 7. “Input 1” table “Source types = SCR” “Universal LNB” - power supply voltage of the converter is chosen according to the selected polarization – 18 V Horizontal, 13 V Vertical; the 22 kHz is set depending on given "LNB HI frequency" "LNB LO frequency" and “Input frequency” parameters. For example: LNB Hi=10,600, LNB Lo=9750, then F=(950+10,600+2150+9750)/2=11,725 MHz.
  • Page 8 The Figure 9 “Demodulator settings table” in devices with DVB-S/S2 input consists of the following parameters: „SAT input“ - A parameter that can switch demodulator off or connect to any available RF input. “User band” - parameter used in dSCR/SCR Switches. „Input frequency“...
  • Page 9 5.4. Transport Streams One channel at a time can be configured in this page. Select proper channel from the list at „Choose input channel“ combobox (see Figure 11 “Transport streams page”). Figure 11. Transport streams page A list of services in the selected channel will appear. „List of services“ table shows a list of available services. Icon before the service name indicates service type.
  • Page 10 Service type Description 0x00 reserved for future use 0x01 digital television service (see note 1) 0x02 digital radio sound service (see note 2) 0x03 Teletext service 0x04 NVOD reference service (see note 1) 0x05 NVOD time-shifted service (see note 1) 0x06 mosaic service 0x07...
  • Page 11 SSDP packets (239.255.255.250:1900 and 239.255.255.246:7900). Also make sure that all devices are connected to the same Ethernet network. NOTE: If in the RF network exists transponders that is generated by old TERRA transmodulators/modulators, the frequencies and modulation parameters must be filled manually (Figure 16).
  • Page 12 5.6. TS info This tab Lists all outgoing servises. You can easily filter out needed output channels by selecting needed output in table "TS Info". This lets you quickly view and setup LCN for every channel also check your Output bitrate and ensure that it is not overflowing.
  • Page 13 5.7. RF outputs Headend has 16/32 independent and agile channels. "Output frequency“ parameter can be entered manually or selected as a channel from combobox. Channels that can be selected from the list depend on which region is selected. If you need any other frequency – select “Manual” and type the needed frequency.

  • Page 14: Snmp Settings

    5.8. SNMP settings Figure 18 "SNMP settings" table is located in “IP parameters” tab. The description of the SNMP configuration parameters: "Read Community" - community name acts as a password that is shared by multiple SNMP agents and one or more SNMP managers. "Read Community"...
  • Page 15 5.11 System menu This menu tab contains following submenu items: “Event logs”, “Export parameters”, “Import parameters”, “Firmware upgrade”, “User management”, “Restore defaults“, “Restart the device“, “Auto Restart“, “Time, Date”, “Language”. Mouse over to show the list of this submenu. 5.11.1 Event logs Various important events, errors, warnings will be logged into the system, see Figure 21 "Event logs".

  • Page 16: User Management

    Figure 23. Firmware upgrade 5.11.5 User management User may change a password here. Length of the password is up to 16 symbols. Type current password and double enter new password to change it. If logged in user has admin role, new users can be added (see Figure 24 "User management"). Figure 24.

  • Page 17: Auto Restart

    5.11.8 Auto Restart Enable "Auto restart" to schedule periodical restart. Fill in "Scheduled restart time" to restart device on the particular time. The restart will occure every day on speciefied time. 5.11.9 Date, Time System time can be configured manually or taken from NTP server (only if device can access NTP server). Also there is an option to select the time source from TS as shown in the Figure 25.

  • Page 18: Technical Specifications

    Technical specifications Type S3C32VB S3C32WB Number of input / output channels 32/16 32/32 Number of input ports frequency range 950 - 2150 MHz input level AGC range / impedance 50-94 dBµV/75 Ω* LNB powering and control 0/13 V/18 V, 22 kHz & 1 A per input channel, total 2 A max.
  • Page 19 TERRA UAB Draugystes str. 22, LT-51256 Kaunas, Lithuania Tel.: +370 37 - 31 34 44, fax: +370 37 - 31 35 55 E-mail: sales@terraelectronics.com www.terraelectronics.com...
