- Page 1 User’’s Guide TS 700-MS Series 2 Full Function/Advanced Function Digital Indicator www.trinerscale.com Compatible with DataLog Scale-to-PC Data Logging Software UG Version 2.4_02-15-13...
- Page 2 Triner Scale & Mfg.Co., Inc. 8411 Hacks Cross Road Olive Branch, MS 38654 (800) 238-0152 www.trinerscale.com © 2011 Triner Scale. All rights reserved. Rev 09/04/12...
-
Page 3: Table Of Contents
User’’s Guide | TS-700 MS Table of Contents Specifications........2 Operation .......... 4 Load Cell Connections ...... 7 Serial Port Connections ....8 Parameters and Settings....9 Data Output Formats ...... 15 Using A Receipt Printer....18 Error Codes ........19 Factory Default Settings.... -
Page 4: Specifications
User’’s Guide | TS-700 MS Specifications TECHNICAL PARAMETERS Resolution ...... Display: 30,000 ADC ........ 2,000,000 Zero stability error ... TK < 0.1µV//K Span stability error ..TK < ± 6 ppm//K Sensitivity (internal)..0. 3 µV /d Input voltage ....-30~30mV DC Excitation circuit .... - Page 5 User’’s Guide | TS-700 MS OVERVIEW Digital Readout/Display Enclosure Keypad Weighing Platform Quick Connect Socket AC Adapter Socket RS232 DB9 Socket (Printer, PC, Remote Display)
-
Page 6: Operation
User’’s Guide | TS-700 MS Operation KEYS AND THEIR FUNCTIONS KEY OPERATION / FUNCTION On/Off Press and hold for 2+ seconds to operate. Hold To Hold Weight on Scale (manual hold): With weight on scale, press Hold key. To Hold Peak Weight of Multiple Weighings (auto hold)*: To enable, press Hold key before loading scale. - Page 7 User’’s Guide | TS-700 MS In settings mode: Return Key - Previous - Pressed with other key(s) for functions. Total To Add Weights: With weight on scale, press the Total key to place weight and count in memory. Remove weight, place next item on scale, press Total to add weight to total weight and total count.
- Page 8 User’’s Guide | TS-700 MS Gross For use after a TARE weight has been stored in the indicator. Press key to toggle view between gross and net weight. PLEASE NOTE that there may be a momentary pause in the display when going from gross to tare weight.
-
Page 9: Load Cell Connections
User’’s Guide | TS-700 MS Load Cell Connections The indicator can connect with a maximum of eight (8) 350 load cells, 4 wire or 6 wire configurations. Excitation voltage for the load cell is 5VDC, the maximum output current is 120mA. -
Page 10: Serial Port Connections
User’’s Guide | TS-700 MS Serial Port Connection RS232 CONNECTOR The serial port connector is for attaching a peripheral device such as a printer or remote display, or for connecting the indicator to a PC. NOTE: PC interface requires specific software to be installed on the PC. -
Page 11: Parameters And Settings
Several parameters can be accessed that, if altered, will change your indicator’’s operations. TO ACCESS AND ADJUST THE TS-700 MS PARAMETERS: Press the PRINT and HOLD keys. ““C”” will display. Release the keys. ““C08”” will display, with the 8 flashing. - Page 12 User’’s Guide | TS-700 MS Use the right arrow key to move the active digit from the 1 to the 8 (the 8 will flash). Use the down arrow key to reduce the 8 to 6 (C16 will display). Press the PRINT ( ) key.
- Page 13 User’’s Guide | TS-700 MS Hold function 0 = no hold function 1 = hold peak weight 2 = hold weight on scale 3 = hold animal weight 4 = reserved Note: hold peak weight shows the max. load of multiple weighings.
-
Page 14: C24 Overload Range
User’’s Guide | TS-700 MS Zero range 0 = disable manual zero CAUTION: (amount that setting Changing can be zeroed 1 = ±1% max capacity these out with the 2 = ±2% max capacity parameters will Zero key) 4 = ±4% max capacity affect the 10 = ±10% max capacity... -
Page 15: C26 Standstill Time
User’’s Guide | TS-700 MS Negative display 0 = -9d 10 = 10% max. capacity 20 = 20% max. capacity 50 = 50% max. capacity 100 = 100% max. capacity Standstill time 0 = quick CAUTION: 1 = medium Changing... -
Page 16: C33 Relay Output Setting
User’’s Guide | TS-700 MS RESERVED ------- Relay output 0 = Close relay output setting 1 = Open relay output (optional) function 1 2 = Open relay output function 2 3 = Reserved menu ------- RESERVED RESERVED -------- Gravity of C36 = 9.7000 -- 9.9999... -
Page 17: Data Output Formats
User’’s Guide | TS-700 MS Data Output Formats REMOTE DISPLAY FORMAT State A Bits: 0,1,2 Decimal point position XXXXXX0 XXXXXXX XXXXX-X XXXX-XX XXX-XXX Bits: 3,4 Division State B BITS FUNCTION Bits0 Gross = 0, net=1 Bits1 Symbol: positive = 0,negative =1... - Page 18 User’’s Guide | TS-700 MS State C Bit1 Bit0 unit Bit2 Kg or lb Bit 3 printing=1 Extend Bit 4 display=1 Constant Bit 5 Constant Bit 6 PC COMPUTER CONTINUOUS SENDING FORMAT Data Weight status: ST = standstill US = not standstill...
- Page 19 User’’s Guide | TS-700 MS SERIAL INTERFACE RECEPTION COMMAND RS232COM serial interface can receive simple ASCII command. Command word and role as follows: Command Name Function TARE Save and clear tare ZERO Zero gross weight PRINT Print the weight G.W/N.W...
-
Page 20: Using A Receipt Printer
User’’s Guide | TS-700 MS Using A Receipt Printer Print Key Typical receipt Cable to Weighing Platform Printer Connector To print receipts with an optional printer: With power off, attach the printer cable to the connector socket on the underside of the indicator. -
Page 21: Error Codes
User’’s Guide | TS-700 MS Error Codes ERROR CAUSE SOLUTION 1. Overloaded condition. 1. Reduce the weight. 2. Wrong connection at 2. Check load cell load cell. connection uuuuuu 3. Load cell has quality 3. Inspect load cell. problem. Check the input and output. -
Page 22: Factory Default Settings
User’’s Guide | TS-700 MS Factory Default Settings PARAMETER INSTRUCTION DEFAULT Calibration Decimal digits Resolution Max. capacity 10000 Empty calibration Capacity calibration Restore default Warning tone Power-off automatically Power saving mode Hold function Disable kg/lb conversion Upper limit alarm 000000... - Page 23 User’’s Guide | TS-700 MS Zero tracking time Overload range Negative range Standstill time Standstill range Dynamic filter Noise filter Print format Analog signal options 4~20mA testing Relay output setting Reserved Reserved Calibration location gravity 9.7936 Destination gravity 9.7936 Version No. check...
- Page 24 Triner Scale & Manufacturing Co. Inc. 8411 Hacks Cross Road Olive Branch, MS 38654 (800) 238-0152 www.trinerscale.com...
