PTZ Optics PT20X-NDI-GY Quick Start Manual

Broadcast Quality Made Affordable
PTZOPTICS
Broadcast & Conference Camera
The PTZOptics 20X-NDI is a 1080p camera with 20X optical zoom for capturing HD images at long
distances. With support for NDI|HX, 3G-SDI, HDMI, and IP streaming (H.264, H.265, & MJPEG), this
camera is ideal for broadcasting high definition video signals for broadcast, recording, or video
conferencing applications.

KEY FEATURES

•
60.7 degree wide-angle lens.
•
High performance in low light scenarios with Wide Dynamic Range.
•
Full 1920x1080p HD Resolutions up to 60 frames per second.
•
2D and 3D noise reduction with our latest "low noise CMOS sensor".
•
NDI, RS232 & RS485 (Serial), and IP (LAN/WAN) control
•
H.264, H.265, & MJPEG streaming over RJ-45 LAN port
•
HDMI, 3G-SDI, & NDI or IP streaming (3 simultaneously)
•
PoE (Power over Ethernet) or 12VDC
•
RTMP, RTSP, and NDI|HX
•
Photobooth capable
Camera & Lens
Video Sensor
Frame Rates
Frame Rates (CVBS)
Focal Length
Lens Zoom
Field of View
Min Lux
Shutter Speed
SNR
Vertical Flip & Mirror
Horizontal Angle of View
Vertical Angle of View
Working Environment
Pan & Tilt Movement
Pan Movement
Tilt Rotation
Presets
Please check PTZOPTICS.com for the most up to date version of this document
1/2.7" CMOS, 2.12 Mega Pixels
1080p-60/50/30/25, 1080i-60/50,
720p-60/50/30/25
576i-30, 480i-30
20x, F4.42mm-88.5mm, F1.8-F2.8
20x
60.7°
0.5 Lux at F1.8, AGC ON
1/30s - 1/10000s
≥55dB
Supported
3.36° (tele) to 60.7° (wide)
1.89° (tele) to 34.1°(wide)
Indoor
±170°
Up: 90°, Down: 30°
10 via IR (255 via Serial or IP)
®

Rear Board Connectors

Video Output NDI | HX, HDMI, 3G-SDI, IP, CVBS
Interface
Network Interface RJ45
Audio Interface Line In, 3.5mm (NDI, HDMI & IP Stream)
Communication RS-232, RS485, PELCO-D/P, NDI
Interface
Baud Rate 2400/4800/9600 bits
Power Supply JEITA type Power Adapter (DC IN 12V)
Interface
BNC – 75 Ohm, Female
3G-SDI Interface
USB 2.0 Interface Future Use
Electrical Index
Power Supply 12W (Max)
Input Voltage 12V DC (10.8 - 13.0V DC) or PoE 802.3af
Physical Specifications
Dimension (in.) 5.6W x 6.5H x 6.7D (7.8H max w/ Tilt)
Dimensions (mm) 142W x 164H x 169D (198H max w/ Tilt)
9" x 9" x 10" | 229mm x 254mm x 229mm
Box Dimensions
Camera Weight 3.10 lbs. (1.41 kg)
Boxed Weight 5.4 lbs. (2.45 kg)
Model Number:
PT20X-NDI-GY (gray)
PT20X-NDI-WH (white)
http://ptzoptics.com/ndi/
WHAT'S IN THE BOX
20X Zoom NDI|HX Camera
Power Adapter + Cord
IR Remote Control
RS-232C Cable
User Manual
Rev. 1.2 7/19
