2
Replacing a wireless thermostat
You can watch this installation at:
http://netatmo.com/video2
or installing your first thermostat
You can watch this installation at:
http://netatmo.com/video3

Advertisement

loading
Need help?

Need help?

Do you have a question about the NETATMO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Starck NETATMO

Summary of Contents for Starck NETATMO

  • Page 1 Replacing a wireless thermostat You can watch this installation at: http://netatmo.com/video2 or installing your first thermostat You can watch this installation at: http://netatmo.com/video3...
  • Page 2 Warning! • Read these instructions carefully before starting the installation. • The Netatmo Thermostat must be installed according to applicable standards. • Before any intervention, make sure power is turned off. • The Netatmo Thermostat cannot control electric converters.
  • Page 3 In the box Thermostat Mobile stand Relay Boiler adapter (Mounting Plate)* (Trim plate)* Color Adhesives (Power Plug)* Tape 3 AAA batteries 4 screws 4 screw anchors * not used or optional in this setup...
  • Page 4 No polarity Note : Some thermostats are connected to different terminals from those on the diagram’s list (for example, eBus, EMS…). In this case, you will have to identify the right thermostat terminals to connect the Relay of the Netatmo Thermostat.
  • Page 5 (P/N or L/N). Our forum can help you P / N identify where to plug the wires L / N in, at forum.netatmo.com. In doubt, please send a picture of your wiring to: photo@netatmo.com and our support team will help you identify the right terminals.

  • Page 6: Setting The Relay

    Setting the Relay The boiler adapter should be placed as far as possible from metallic items 30 cm (wiring, pipes, electrical grid…). The boiler adapter can be affixed to the wall with the double-sided tape or the screws provided.
  • Page 7 Testing the Relay Connect the Relay into the boiler adapter. Switch the power supply back The Relay will blink white. Note : If the Relay does not blink after turning the power back on, it is not power supplied. Please check how the blue and brown wires are wired. Do not forget to switch off the power supply before any intervention.
  • Page 8 Testing the Relay The Relay will light up white Push the Relay button. and switch on the boiler. Push the Relay The Relay light will turn off to button again. indicate the boiler is off. Note: If the boiler doesn’t switch on when the white light is on, the Relay can be incorrectly wired to the boiler.
  • Page 9 Thermostat The Thermostat will display the Insert the batteries into start screen and search for the Relay. the Thermostat. Desired temperature Measured temperature If the Thermostat has found the If the Thermostat hasn’t found the Relay, it will display the setpoint and Relay, it will display the «!»...
  • Page 10 Customization You can choose to customize your Thermostat by using one of the colour adhesives. Take off the outer frame of the adhesive. Stick it on the back of your Thermostat.
  • Page 11 Location Clip the Thermostat on its mobile Set the Thermostat on the stand and place it on a shelf in the mounting plate. living room. 1,5 m More than 1 m from the A 1,5 m high Away from any cold openings or heat source...
  • Page 12 Test clic Tap the top of the Thermostat until the screen shows « MAX ». The Thermostat will switch on the boiler. Tap the bottom of the Thermostat until it displays « OFF ». The Thermostat will switch off the boiler.
  • Page 13 To use your Thermostat from your smartphone or tablet, visit: http://therm.netatmo.com Smartphone / Tablettes...

  • Page 14: Specifications

    Thermostat: 83 x 83 x 22 mm Wi-Fi 802.11 b/g/n compatible (2.4GHz). Supported security: Open/WEP/WPA/ DESIGN WPA2-personal (TKIP and AES). Designed by Starck. Wireless connection between thermostat and Translucent minimalist plexiglass cube. relay: 5 interchangeable colours in the box. radio long range up to 100 m.
