- Page 1 ENLIGHTEN INSTALLATION GUIDE FTTH Fibre Outlet - TEN-FWO1 Installation Guide Rev. 1.00/11.2019...
-
Page 2: Table Of Contents
TEN-FWO1 Installation Guide Rev. 1.00/11.2019 Contents Getting Started..................................1 Introduction ..................................1 Package Contents .................................1 About the TEN-FWO1 Fibre Outlet ............................2 Product Specification ................................2 Mechanical Layout ................................2 Installation Instructions ...............................3 General Preparations and Precautions ..........................3 Preparation of the Incoming Optical Drop Cable .........................3 Installation Guidelines .................................3... -
Page 3: Getting Started
Package Contents Please unpack the TEN-FWO1 and verify that all items are at present, as shown in Figure 1. If any items are missing then please do not hesitate to contact your local seller for help. -
Page 4: About The Ten-Fwo1 Fibre Outlet
TEN-FWO1 Installation Guide Rev. 1.00/11.2019 About the TEN-FWO1 Fibre Outlet The TEN-FWO1 has been designed primarily for applications such as FTTH. The unit is very compact and easy to install along with convenient maintenance, it may be delivered empty or with adapters and pigtails in a suitable box according to customer needs. -
Page 5: Installation Instructions
ENLIGHTEN Optical Passives TEN-FWO1 Installation Guide Rev. 1.00/11.2019 Installation Thank you for purchasing this Teleste product. Please take a moment and carefully read these instructions through before installing the product. Instructions General Preparations and Precautions 1. Check the Fibre Outlet, cable items and all other components for any damages before installation. -
Page 6: Picture
ENLIGHTEN Optical Passives TEN-FWO1 Installation Guide Rev. 1.00/11.2019 3. For rear cable entry, bring the cable through the oval shaped hole in the rear of the backplate and secure with cable ties using the small cable tie studs saddles as needed. -
Page 7: Fibre Splicing. Splice The Drop Cable Fibres Directly With The Installed And Prepared Pigtails, See Picture
ENLIGHTEN Optical Passives TEN-FWO1 Installation Guide Rev. 1.00/11.2019 7. Install the 0.9 mm pigtails into the adapters and route the pigtails - from left to right - on the splice wheel, see Picture 4. Picture 4 8. Fibre Splicing. Splice the drop cable fibres directly with the installed and prepared pigtails, see Picture 5. -
Page 8: Picture
ENLIGHTEN Optical Passives TEN-FWO1 Installation Guide Rev. 1.00/11.2019 Picture 6 Picture 7 10. Remove the adapter protection caps, see Picture 8. Picture 8 Optical Fibre Outlet Series... -
Page 9: Picture
ENLIGHTEN Optical Passives TEN-FWO1 Installation Guide Rev. 1.00/11.2019 11. Install the fibre optical patch cords. Insert the connector into the adapter connector until a click is heard, see Picture 9. Picture 9 12. Complete the installation by sliding the protective cover forward. -
Page 10: Mounting Guidance
ENLIGHTEN Optical Passives TEN-FWO1 Installation Guide Rev. 1.00/11.2019 Mounting Guidance To carry out a wall mount installation: Drill two holes over the wall based on the size in mechanical layout drawing on page 2. Place the expansion plugs, place the box to match up the holes and use bolts to fasten. -
