Brizo 62710LF Manual

Wall mounted and deck mounted pot filler faucets
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Model/Modelo/Modèle
62710LF, 62720LF,
62810LF, 62820LF,
62725LF & 62825LF
Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
You may need / Usted puede necesitar / Articles dont vous pouvez avoir besoin:
For easy installation of your Delta
faucet you will need:
• To READ ALL the instructions completely
before beginning.
• To READ ALL warnings, care, and
maintenance information.
• To purchase the correct water supply hook-up.
Para instalación fácil de su llave
Delta usted necesitará:
• LEER TODAS las instrucciones completamente
antes de empezar.
• LEER TODOS los avisos, cuidados, e
información de mantenimiento.
• Comprar las conexiones correctas para el
suministro de agua.
Pour installer votre robinet Delta
facilement, vous devez:
• LIRE TOUTES les instructions avant de débuter;
• LIRE TOUS les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien;
• Acheter le bon nécessaire de raccordement.
www.brizo.com
WALL MOUNTED AND DECK MOUNTED POT FILLER FAUCETS
86523
LLAVES DE AGUA EXTENDIBLES PARA INSTALAR EN LA
PARED, O EN LOS ESTANTES DE COCINA, PARA LLENAR
OLLAS Y SIMILARES.
ROBINETS POUR REMPLISSAGE DE GROSSES MARMITES
MONTÉS AU MUR OU SUR UN PLAN DE TRAVAIL
62710LF
62810LF
Deck mounted
Wall mounted
86523
1
62720LF
62820LF
62725LF
62825LF
12/20/2016
Rev. C

Advertisement

loading
Need help?

Need help?

Do you have a question about the 62710LF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brizo 62710LF

Summary of Contents for Brizo 62710LF

  • Page 1 LLAVES DE AGUA EXTENDIBLES PARA INSTALAR EN LA PARED, O EN LOS ESTANTES DE COCINA, PARA LLENAR OLLAS Y SIMILARES. Model/Modelo/Modèle ROBINETS POUR REMPLISSAGE DE GROSSES MARMITES 62710LF, 62720LF, MONTÉS AU MUR OU SUR UN PLAN DE TRAVAIL 62810LF, 62820LF, 62725LF & 62825LF 62710LF...
  • Page 2 Hole size - 7/8" (22 mm) - 1 1/8” (29 mm) diameter. Tamaño del agujero - 7/8” (22 mm) - 1 1/8” (29 mm) de diámetro. Diamètre du trou – 7/8 po (22 mm) - 1 1/8 po (29 mm). 1/2"...
  • Page 3 1/2" (13 mm) 1/2 po (13 mm) WARNING: Connect to Cold Water Only. AVISO: Conecte Sólo al Agua Fría. AVERTISSEMENT : Ne raccordez qu’à la conduite d’alimentation d’eau froide seulement. Wall Mount Models Use of stringers is recommended for a secure mounting. WARNING: To prevent hot water burns make connection to Mark the screw holes (1) in the flange.
  • Page 4 Tighten set screw in flange (1). Slide flange trim (2) over the wall flange Wrap plumber tape (1) around pipe threads. Install the gasket (2) and and tighten set screw (3). the flange (3) using the 4 screws (and anchors if required) provided. Place flange trim (1) onto the faucet as shown.
  • Page 5 FlushYour System Notice Remove aerator (1) and turn faucet handles (2) to the full on position. Turn on cold water supplies (3) and flush water lines Property damage and water leak possible. Leaks and property damage may occur from incorrect installation. Follow all installation instructions before making for one minute.Important: This flushes away any debris that final connections and turning on the supplies.

  • Page 6: Maintenance

    Maintenance If faucet leaks out of spout or handle - Replace valve cartridge (1). If faucet exhibits very low flow - Remove and clean aerator (4). Pull off handle (2) or remove button, screw, handle and base (3). Unscrew and replace valve cartridge, 19 mm hex. Assemble in reverse order.
  • Page 7 62710LF, 62720LF & 62725LF Models / Modelos / Modeles RP61193▲ Traditional Handle Manija Tradicional Manette Traditional RP92296▲ RP61195▲ Artesso Handle Contemporary Handle RP61194▲ Manija contemporánea Manija contemporánea Handle Base with Insert Manette contemporain Manette contemporain Base para Manijas con Inserción Embase de Manette avec l’insertion...
  • Page 8 & Bath Company para todos los reclamos a menos que el comprador haya registrado el producto compra. No se garantizan las pilas. con Brizo Kitchen & Bath Company. Esta garantía le aplica sólo a las llaves de agua de Brizo ®...

This manual is also suitable for:

62720lf62820lf62810lf62825lf62725lf62710lf series ... Show all
