Technical Data - iQOS 3 MULTI User Manual

Disposing waste equipment as unsorted municipal waste (e.g. by waste
incineration or land filling) can have negative effects on the environment
and human health.
For more information about where you can drop off your waste equipment for
recycling, please contact your local city office, your local household waste disposal
service or the shop where you purchased the product.
The local importer of the product will provide for the financing of the treatment
and recycling of waste equipment returned through these designated collection
points in accordance with local requirements.

TECHNICAL DATA

IQOS 3 Multi - Model: A1405
Battery type:
Li-ion rechargeable battery
Input: 5V 2A
Bluetooth® 4.1
USB Type C Cable
Battery removal instructions (for disposal and recycling)
Batteries must not be removed by the consumer. At end of product life, only an
authorized recycler may safely remove batteries by using the following steps.
IQOS 3 Multi (A1405):
Step 1. Check the voltage: The device should be fully discharged before
disassembling it.
Step 2. Rear housing removal (the use of a jig is recommended): Remove the
housing hooks, which are located on the lower side of the device (on the side,
close to the USB socket). The rear housing can now be removed.
Step 3. Sub-assembly removal: Enlarge both sides of the extruded chassis, then
remove the core sub-assembly.
Step 4. Battery removal: Gently pull the battery away from the adhesive backing.
Remove the screws which secure the PCB, then carefully remove the battery and
PCB from the casing. Disconnect the battery cable by using the relevant tool (AVX
06-9296-7001-01-000).
Step 5. Disposal: Recycle the battery, assembly and PCB according to local
regulations.
Hereby, Philip Morris Products S.A. declares that IQOS 3 Multi is in compliance with
the essential requirements and other relevant provisions of Directive 2014/53/EU.
The official Declaration of Conformity may be found at:
www.pmi.com/declarationofconformity
IQOS 3 Multi Model A1405 operates within 2.402 – 2.480GHz frequency band with
a maximum RF output power of 7.0dBm.
Designed and manufactured under the authority of Philip Morris Products S.A.,
Quai Jeanrenaud 3, 2000 Neuchâtel, Switzerland.
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth
SIG, Inc. and any use of such marks by Philip Morris Products S.A. and its affiliates is under
license. Other trademarks and trade names are those of their respective owners.
IQOS AC Power Adaptor
Model: S21A20.
Input: 100V-240V~ 50/60HZ 0.3A
Output: 5V 2A
