SERVICE MANUAL
COLOR TELEVISION/
VIDEO CASSETTE RECORDER/
DVD VIDEO PLAYER
The above model is classified as a green product (*1), as indicated by the underlined serial number.
This Service Manual describes replacement parts for the green product. When repairing this green
product, use the part(s) described in this manual and lead-free solder (*2).
For (*1) and (*2), see the next page.
MW27H62
DOCUMENT CREATED IN JAPAN, April, 2006 GREEN
FILE NO. 810-200657GR
REV.01

Advertisement

Table of Contents
loading

Summary of Contents for Toshiba MW27H62

  • Page 1 COLOR TELEVISION/ VIDEO CASSETTE RECORDER/ DVD VIDEO PLAYER MW27H62 The above model is classified as a green product (*1), as indicated by the underlined serial number. This Service Manual describes replacement parts for the green product. When repairing this green product, use the part(s) described in this manual and lead-free solder (*2).
  • Page 2: Green Product Procurement

    Hazardous Substances. From July 1, 2006, the RoHS Directive will prohibit any marketing of new products containing the restricted substances. Increasing attention is given to issues related to the global environmental. Toshiba Corporation recognizes environmental protection as a key management tasks, and is doing its utmost to enhance and improve the quality and scope of its environmental activities.
  • Page 3: Caution

    All manuals and user guides at all-guides.com CAUTION THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM. TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ THIS SERVICE MANUAL CARE- FULLY AND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE, CONTACT AN AUTHORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE.
  • Page 4: Servicing Notices On Checking

    All manuals and user guides at all-guides.com SERVICING NOTICES ON CHECKING 1. KEEP THE NOTICES 6. AVOID AN X-RAY As for the places which need special attentions, Safety is secured against an X-ray by consider- they are indicated with the labels or seals on the ing about the cathode-ray tube and the high cabinet, chassis and parts.
  • Page 5: Important Safeguards

    All manuals and user guides at all-guides.com IMPORTANT SAFEGUARDS READ INSTRUCTIONS All the safety and operating instructions should be read before the unit is operated. RETAIN INSTRUCTIONS The safety and operating instructions should be retained for future reference. HEED WARNINGS All warnings on the unit and in the operating instructions should be adhered to.
  • Page 6 All manuals and user guides at all-guides.com IMPORTANT SAFEGUARDS (CONTINUED) OUTDOOR ANTENNA GROUNDING If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
  • Page 7 All manuals and user guides at all-guides.com IMPORTANT SAFEGUARDS (CONTINUED) EXAMPLE OF ANTENNA GROUNDING AS PER THE NATIONAL ELECTRICAL CODE ANTENNA LEAD IN WIRE GROUND CLAMP ANTENNA DISCHARGE UNIT (NEC SECTION 810-20) ELECTRIC SERVICE EQUIPMENT GROUNDING CONDUCTORS (NEC SECTION 810-21) GROUND CLAMPS POWER SERVICE GROUNDING NEC-NATIONAL ELECTRICAL CODE...
  • Page 8 All manuals and user guides at all-guides.com WHEN REPLACING DVD DECK [ When removing the DVD Deck ] Before removing Pick Up PCB and DVD PCB connector, the short circuit the position shown in Fig. 1 using a soldering iron. If you remove the DVD Deck with no soldering, the Laser may be damaged. [ When installing the DVD Deck ] Remove all the soldering on the short circuit position after the connection of Pick Up PCB and DVD PCB connector.
  • Page 9: Tape Removal Method At No Power Supply

    All manuals and user guides at all-guides.com TAPE REMOVAL METHOD AT NO POWER SUPPLY Remove the TV/DVD/VCR block from the main unit as shown in Fig. 1 below can be seen. (Refer to item 1 of the DISASSEMBLY INSTRUCTIONS.) Remove the screw 1 of the Deck Chassis and remove the Loading Motor. Rotate the Pinch Roller Cam in the direction of the arrow by hand to slacken the Video Tape.
  • Page 10: Parental Control Rating Level

    All manuals and user guides at all-guides.com PARENTAL CONTROL - RATING LEVEL 4 DIGIT PASSWORD CANCELLATION If the stored 4 digit password in the Rating Level menu needs to be cancelled, please follow the steps below. Turn Unit ON. Set the DVD Mode. Confirm that the 'No Disc' will be appeared on the screen.
  • Page 11: Table Of Contents

    All manuals and user guides at all-guides.com TABLE OF CONTENTS GREEN PRODUCT PROCUREMENT ..................A1-1 LEAD-FREE SOLDER ......................A1-1 CAUTION ..........................A1-2 SERVICING NOTICES ON CHECKING .................. A1-3 HOW TO ORDER PARTS ....................... A1-3 IMPORTANT SAFEGUARDS ....................A1-4~A1-6 WHEN PERLACING DVD DECK .................... A1-7 TAPE REMOVAL METHOD AT NO POWER SUPPLY ............
  • Page 12 All manuals and user guides at all-guides.com GENERAL SPECIFICATIONS CRT Size / Visual Size 27 inch / 676.6mmV System CRT Type Flat Magnetic Field BV/BH +0.45G / 0.18G Color System NTSC Speaker 2 Speaker Position Front Size 1.8 x 3.9 Inch Impedance 8 ohm Sound Output...
  • Page 13 All manuals and user guides at all-guides.com GENERAL SPECIFICATIONS Signal Video Signal Input Level 1 V p-p/75 ohm Output Level S/N Ratio (Weighted) at DVD Mode S/N Ratio (Weighted) at VCR Mode Horizontal Resolution at DVD Mode Horizontal Resolution at VCR(SP)Mode RGB Signal Output Level Audio Signal...
  • Page 14 All manuals and user guides at all-guides.com GENERAL SPECIFICATIONS G-12 Remote Unit RC-KH Control Glow in Dark Remocon Unit Remocon Format TOSHIBA Format TOSHIBA Custom Code 40-BFh, 44-BBh, 45-BAh Power Source Voltage(D.C) UM size x pcs UM-4 x 2 pcs Total Keys...
  • Page 15 All manuals and user guides at all-guides.com GENERAL SPECIFICATIONS G-13 Features Auto Head Cleaning (TV/VCR) VIDEO PLUS+(SHOWVIEW,G-CODE) Forward / Reverse Picture Search Index Search SQPB CM Skip(30sec x 6 Times) Zero Return End Call TV Monitor Program Extend Picture Brightness , Contrast , Color, Sharpness Tint Mode (Picture Preference) Color Temperature...
  • Page 16: Tray Lock

    All manuals and user guides at all-guides.com GENERAL SPECIFICATIONS Features Tray Lock (DVD) Auto Stop (Pause, and Resume Stop after 5min.) (Some USB devices may not be usable.) Card Slot Reading (Not secured Data) Video CD Playback SVCD Playback MP3 Playback WMA Playback JPEG Playback DivX Play back...
  • Page 17 Height (cm) 40(ORION SPEC:25) Container Stuffing(40' container) Sets G-19 Material Cabinet Front 94V0 DECABROM Rear 94V0 DECABROM Jack Panel Non-Halogen Demand Eyelet Demand G-20 Environment Environmental standard requirement (by buyer) Green procurement of TOSHIBA Pb-free Phase3(Phase3A) Measures for Whisker A3-6...
  • Page 18: Disassembly Instructions

    All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS 1-3: TV/DVD/VCR BLOCK (Refer to Fig. 1-3) 1. REMOVAL OF MECHANICAL PARTS Remove the 2 screws 1. AND P.C. BOARDS Disconnect the following connectors: 1-1: BACK CABINET (Refer to Fig. 1-1) (CP351, CP404, CP1704 and CP5902).
  • Page 19 All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS 1-5: VCR DECK (Refer to Fig. 1-5) 1-6: VCR PCB (Refer to Fig. 1-6) Remove the 6 screws 1. NOTE Remove the screw 2. Do not remove the cable at the FE Head section. The FE Remove the AV Jack Shield.
  • Page 20 All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS 1-8: DVD PCB/DVD DECK (Refer to Fig. 1-8) 1-9: DEFLECTION PCB (Refer to Fig. 1-9) Remove the 2 screws 1. Short circuit the position shown in Fig. 1-8 using a Remove the 3 screws 2. soldering iron.
  • Page 21: Removal Of Vcr Deck Parts

    All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS 2-3: LINK UNIT (Refer to Fig. 2-3) 2. REMOVAL OF VCR DECK PARTS Set the Link Unit to the Eject position. 2-1: TOP BRACKET (Refer to Fig. 2-1) Unlock the support 1. Extend the 2 supports 1.
  • Page 22 All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS 2-5: LOADING MOTOR/WORM (Refer to Fig. 2-5-A) 2-6: TENSION ASS’Y (Refer to Fig. 2-6-B) Remove the screw 1. Turn the Pinch Roller Cam clockwise so that the Tension Remove the Loading Motor. Holder hook is set to the position of Fig.
  • Page 23 All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS NOTE [OK] Tension Connect Take care not to damage the gears of the S Reel and T Reel. Tension Band The Polyslider Washer may on the back of the reel. Take care not to damage the shaft. [NG] Tension Connect Tension Band...
  • Page 24 All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS 2-9: CASSETTE OPENER/PINCH ROLLER BLOCK/P5 ARM ASS’Y (Refer to Fig. 2-9-A) Unlock the support 1 and remove the Cassette Opener. Remove the Pinch Roller Block and P5 Arm Ass’y. Cassette Opener Spring Position Fig.
  • Page 25 All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS 2-13: CAPSTAN DD UNIT (Refer to Fig. 2-13) NOTE 1. In case of the Pinch Roller Cam and Main Cam installa- Remove the Capstan Belt. Remove the screw 1. tion, install them as shown in the circled section of Fig. 2- 14-B so that the markers meet.
  • Page 26 All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS NOTE 2-17: CASSETTE GUIDE POST/INCLINED BASE S/T UNIT/P4 CAP/LED REFLECTOR 1. When you install the Loading Arm S Unit, Loading Arm T (Refer to Fig. 2-17-A) Unit and Main Loading Gear, align each marker. (Refer to Fig.
  • Page 27: Removal Of Dvd Deck Parts

    All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS 3. REMOVAL OF DVD DECK PARTS NOTE 1. Do not disassemble the DVD DECK PARTS except listed parts here. Minute adjustments are needed if the Main Frame Ass'y disassemble is done. If the repair is needed except listed parts, replace the DVD MECHA ASS'Y.
  • Page 28 All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS 3-3: LOADING MOTOR PCB ASS'Y/ LOADING BELT (Refer to Fig. 3-3-A) Pulley Gear Rack Loading Remove the Loading Belt. Remove the screw 1. Main Gear Remove the 2 screws 2. Remove the Loading Motor PCB Ass'y. Main Frame Ass’y Remove the Pulley Gear.
  • Page 29 All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS 3-6: TRAVERSE HOLDER/INSULATOR (F)/INSULATOR NOTE (R) (Refer to Fig. 3-6-A) When pushing the Rack Feed in the direction of the Remove the Traverse Holder. arrow, it should be restored to the original position by the Remove the 2 Insulator (F).
  • Page 30 All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS 3-8: FFC WIRE HANDLING When installing the FFC, fold it correctly and install it as shown from Fig. 3-8-A to Fig. 3-8-C. NOTE Do not make the folding lines except the specified positions for the FFC.
  • Page 31: Removal Of Anode Cap

    All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS 4. REMOVAL OF ANODE CAP 3. After one side is removed, pull in the opposite direction to remove the other. Read the following NOTED items before starting work. NOTE After turning the power off there might still be a potential Take care not to damage the Rubber Cap.
  • Page 32: Removal And Installation Of Flat Package Ic

    All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS 3. When IC starts moving back and forth easily after 5. REMOVAL AND INSTALLATION OF FLAT desoldering completely, pickup the corner of the IC using PACKAGE IC a tweezers and remove the IC by moving with the IC REMOVAL desoldering machine.
  • Page 33 All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS INSTALLATION 4. When bridge-soldering between terminals and/or the soldering amount are not enough, resolder using a Thin- 1. Take care of the polarity of new IC and then install the tip Soldering Iron. (Refer to Fig. 5-8.) new IC fitting on the printed circuit pattern.
  • Page 34: Key To Abbreviations

    All manuals and user guides at all-guides.com KEY TO ABBREVIATIONS Audio/Control H.P.F High Pass Filter Automatic Color Control H.SW Head Switch Audio Erase Hertz Automatic Frequency Control Integrated Circuit Automatic Fine Tuning Intermediate Frequency AFT DET Automatic Fine Tuning Detect Indicator Automatic Gain Control Inverter...
  • Page 35 All manuals and user guides at all-guides.com KEY TO ABBREVIATIONS Serial Strobe Switch SYNC Synchronization SYNC SEP Sync Separator, Separation Transistor TRAC Tracking TRICK PB Trick Playback Test Point UNREG Unregulated Volt Voltage Controlled Oscillator Video Intermediate Frequency Vertical Pulse, Voltage Display V.PB Video Playback Variable Resistor...
  • Page 36: Service Mode List

    All manuals and user guides at all-guides.com SERVICE MODE LIST This unit is provided with the following SERVICE MODES so you can repair, examine and adjust easily. To enter to the SERVICE MODE function, press and hold both buttons simultaneously on the main unit or on the main unit and on the remote control for more than the standard time (second).
  • Page 37: Preventive Checks And Service Intervals

    All manuals and user guides at all-guides.com PREVENTIVE CHECKS AND SERVICE INTERVALS The following standard table depends on environmental conditions and usage. Parts replacing time does not mean the life span for individual parts. Also, long term storage or misuse may cause transformation and aging of rubber parts. The following list means standard hours, so the checking hours depends on the conditions.
  • Page 38 All manuals and user guides at all-guides.com PREVENTIVE CHECKS AND SERVICE INTERVALS CLEANING NOTE 2. TAPE RUNNING SYSTEM After cleaning the heads with isopropyl alcohol, do not When cleaning the tape transport system, use the run a tape until the heads dry completely. If the heads gauze moistened with isopropyl alcohol.
  • Page 39: When Replacing Eeprom (Memory) Ic

    All manuals and user guides at all-guides.com WHEN REPLACING EEPROM (MEMORY) IC CONFIRMATION OF INITIAL DATA If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to ensure correct data settings while making reference to TABLE 1. Address C B C C CD CE...
  • Page 40: Servicing Fixtures And Tools

    All manuals and user guides at all-guides.com SERVICING FIXTURES AND TOOLS Alignment Tape Back tension cassette gauge Torque cassette gauge Taper nut driver (KT-300NR) ST-N5 ST-NF 70909103 70909199 70909228 VTR cleaning kit VTR lubrication kit Grease JG002B Adapter JG002E Dial Torque Gauge (10~90gf•cm) JG002F (60~600gf•cm)
  • Page 41: Mechanical Adjustments

    All manuals and user guides at all-guides.com MECHANICAL ADJUSTMENTS 1-2: CONFIRMATION AND ADJUSTMENT OF TENSION 1. CONFIRMATION AND ADJUSTMENT POST POSITION Read the following NOTES before starting work. Set to the PLAY mode. • Place an object which weighs between 450g~500g on the Adjust the adjusting section for the Tension Arm position Cassette Tape to keep it steady when you want to make so that the Tension Arm top is within the standard line of...
  • Page 42 All manuals and user guides at all-guides.com MECHANICAL ADJUSTMENTS 1-4: CONFIRMATION OF VSR TORQUE NOTE Install the Torque Gauge (JG002F) and Adapter (JG002B) If the torque is out of the range, replace the following parts. on the S Reel. Set to the Picture Search (Rewind) mode. Check item Replacement Part (Refer to Fig.1-4-B)
  • Page 43 All manuals and user guides at all-guides.com MECHANICAL ADJUSTMENTS 2-2: CONFIRMATION AND ADJUSTMENT OF AUDIO/ 2-3: TAPE RUNNING ADJUSTMENT CONTROL HEAD (X VALUE ADJUSTMENT) When the Tape Running Mechanism does not work well, Confirm and adjust the height of the Reel Disk. adjust the following items.
  • Page 44 All manuals and user guides at all-guides.com MECHANICAL ADJUSTMENTS 3. MECHANISM ADJUSTMENT PARTS LOCATION GUIDE 1. Tension Connect P4 Post 2. Tension Arm T Brake Spring 3. Guide Roller T Reel 4. Audio/Control Head S Reel 5. X value adjustment driver hole Adjusting section for the Tension Arm position D2-4...
  • Page 45: Electrical Adjustments

    All manuals and user guides at all-guides.com ELECTRICAL ADJUSTMENTS BEFORE MAKING ELECTRICAL FUNCTION NO. FUNCTION NO. FUNCTION ADJUSTMENTS G.BIAS(C) COL CENT OSD H OSD C B.BIAS(C) COL. MAX Read and perform these adjustments when repairing the R.DRV(C) COL. MIN H.POSI circuits or replacing electrical parts or PCB assemblies.
  • Page 46 All manuals and user guides at all-guides.com ELECTRICAL ADJUSTMENTS 2-7: HORIZONTAL SIZE (TV SECTION) Receive the monoscope pattern. 2-2: CONSTANT VOLTAGE Using the remote control, set the brightness and contrast Place the set in AV MODE without signal. to normal position. Using the remote control, set the brightness and contrast to Activate the adjustment mode display of Fig.
  • Page 47 All manuals and user guides at all-guides.com ELECTRICAL ADJUSTMENTS 2-11: TRAPEZIUM 2-16: BRIGHT CENTER Receive the crosshatch signal from the Pattern Generator. Receive the monoscope pattern. (RF Input) Using the remote control, set the brightness and contrast Using the remote control, set the brightness and contrast to normal position.
  • Page 48 All manuals and user guides at all-guides.com ELECTRICAL ADJUSTMENTS 2-18: COLOR CENTER 2-19: CONTRAST MAX Receive the color bar pattern. (RF Input) Activate the adjustment mode display of Fig. 1-1 and Using the remote control, set the brightness, contrast, press the channel button (33) on the remote control to color and tint to normal position.
  • Page 49 All manuals and user guides at all-guides.com ELECTRICAL ADJUSTMENTS 3-3: STATIC CONVERGENCE PURITY AND CONVERGENCE ADJUSTMENTS NOTE Adjust after performing adjustments in section 3-2. NOTE Receive the crosshatch pattern from the color bar Turn the unit on and let it warm up for at least 30 generator.
  • Page 50 All manuals and user guides at all-guides.com ELECTRICAL ADJUSTMENTS 4. ELECTRICAL ADJUSTMENT PARTS LOCATION GUIDE (WIRING CONNECTION) AC IN DEFLECTION PCB CD052 CP601 TP401 FB401 CP004 VCR DECK CD808 CD001 CP1704 CP604 CP404 CP851A RECGULATOR CP003 CD604 VCR DECK CP8001 CP1702 VR404 CP351...
  • Page 51: Mechanical Exploded Views

    All manuals and user guides at all-guides.com MECHANICAL EXPLODED VIEW 102B 102B 102A 102B PCB110 (CRT MT PCB ASS'Y) PCBD80 (VM COIL PCB ASS'Y) PCBDD0 (USB PCB ASS'Y) 101B 101K 101M 101C 101L 101G 101I 101M 101E 101M 101J 101N 101M 101D 101H...
  • Page 52 All manuals and user guides at all-guides.com MECHANICAL EXPLODED VIEW 103B 103A PCB130 PCB010 (DVD MT PCB ASS'Y) (VCR MT PCB ASS'Y) PCBF10 (REGULATOR PCB ASS'Y) PCBDH0 (DIGITAL PCB ASS'Y) PCB270 (OPERATION PCB ASS'Y) PCB080 (DEFLECTION PCB ASS'Y) I1-2...
  • Page 53 All manuals and user guides at all-guides.com MECHANICAL EXPLODED VIEW (PACKING DIAGRAM) 157, 158, 159, 160, 161, 162, BL001, TM101 I1-3...
  • Page 54: Chassis Exploded Views

    All manuals and user guides at all-guides.com CHASSIS EXPLODED VIEW (TOP VIEW) CD1501 M2003 UN4001 H5002 H5001 CD1502 M101 NOTE: Applying positions AA for the grease are displayed for this section. CLASS MARK Check if the correct grease is applied for each position. GREASE I2-1...
  • Page 55 All manuals and user guides at all-guides.com CHASSIS EXPLODED VIEW (BOTTOM VIEW) M2001 CD1501 CD1502 NOTE: Applying positions AA for the grease are displayed for this section. CLASS MARK Check if the correct grease is applied for each position. GREASE I2-2...
  • Page 56: Dvd Deck Exploded Views

    All manuals and user guides at all-guides.com DVD DECK EXPLODED VIEW Cannot supply separately. If the repair is needed, replace the LOADER SUB ASS'Y. M2603 PCB610 (LOADING MOTOR PCB ASS'Y) CD2302 CD2301 PCB640 CD2001 (SW PCB ASS'Y) Do not replace the parts. Because, minute adjustments are needed if this condition is disassembled further more.
  • Page 57: Mechanical Replacement Parts List

    All manuals and user guides at all-guides.com MECHANICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description 72783840 7A7010206A FRONT,CABI ASS'Y 101A 72783843 701WPJ1429 CABINET,FRONT 101B 72783847 712WPJ0960 FLAT,FLAP 101C 72799441 712WPJ0921 FLAP DVD 101D 72798522 713WPA0315 GLASS,LED 101E 72798523 713WPA0316 GUIDE,REMOCON...
  • Page 58 All manuals and user guides at all-guides.com MECHANICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description 72781978 8965TS1017 CUSHION 65TS10-10(17.5*20*14) 72783871 706WPA0017 COVER,CONNECTOR 75002837 752WSA0604 SHIELD USB 72799905 761WPA0322 HOLDER,FFC 72783724 761WPA0434 HOLDER,USB-1 72783726 761WPA0435 HOLDER,USB-2 72781304 8965TS0415 CUSHION 65TS4-2(15*50*16) 72783345 800WR00079...
  • Page 59: Chassis Replacement Parts List

    All manuals and user guides at all-guides.com CHASSIS REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description 72783890 A5T7016420A DECK ASSY A5T7016420A 72795710 85OA400245 PINCH ROLLER BLOCK VA2 72795711 85OA500026 AHC ASS'Y 72795712 85OP200290 BELT,CAPSTAN (S) 72795713 85OP600581 WORM 72795714 85OP500091 BASE,AC HEAD...
  • Page 60: Dvd Deck Replacement Parts List

    All manuals and user guides at all-guides.com DVD DECK REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description ! 600 72783201 A2I301H650 DVD MECHA ASS'Y A2I301H650 72795767 92P100109A HOLDER,TRAVERSE 72795768 92P100094A CLAMPER 72795769 92P100088A GEAR,MOTOR 72798813 92AAA0013A FEED RACK ASS'Y 72795771 92P200013A INSULATOR(F)
  • Page 61: Electrical Replacement Parts List

    All manuals and user guides at all-guides.com ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description RESISTORS ! R401 72781722 R4K1T4472F R,METAL 1 4.7K OHM 1/4W ! R403 72781717 R4K1T4183F R,METAL 18K OHM 1/4W ! R405 72783394 R4K1T4153F R,METAL 2 15K OHM 1/4W ! R406...
  • Page 62 All manuals and user guides at all-guides.com ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description DIODES D410 72794488 D2WT011E10 DIODE,SILICON 11E1-EIC D411 72794489 D97U05R61B DIODE,ZENER MTZJ5.6B T-77 ! D412 72794472 D2WTAU02A0 DIODE,SILICON AU02A-EIC D413 72794471 D97U03001B DIODE,ZENER MTZJ30B T-77 D414 72794471...
  • Page 63 All manuals and user guides at all-guides.com ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description DIODES D3002 72794489 D97U05R61B DIODE,ZENER MTZJ5.6B T-77 D3003 72783209 D2MXN40020 DIODE,FAST RECOVERY 1N4002-PAN D3004 72795627 D2WXSB1400 DIODE,SCHOTTKY SB140-EIC D3005 72795087 D28TEQS040 DIODE,SCHOTTKY 11EQS04TA1B2 D3006 72794488...
  • Page 64 All manuals and user guides at all-guides.com ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description TRANSISTORS Q014 72794567 TNAAC05002 COMPOUND TRANSISTOR KRC103SRTK Q050 72794578 TAATA12660 TRANSISTOR,SILICON KTA1266-AT(Y,GR) ! Q401 72794561 TCAT03227Y TRANSISTOR,SILICON KTC3227_Y-AT Q402 72794563 TC30041590 TRANSISTOR,SILICON 2SC4159(D,E) ! Q403 72794562...
  • Page 65 All manuals and user guides at all-guides.com ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description TRANSISTORS Q4511 72795481 T6RA015300 TRANSISTOR,SILICON 2SA1530A-T1 Q8001 72796427 TNRAB05004 COMPOUND TRANSISTOR RT1N141C-T112-1 ! Q8002 72796092 TAAT01281Y TRANSISTOR,SILICON KTA1281_Y COILS &TRANSFORMERS L001 72794526 02167F220J COIL L002...
  • Page 66 All manuals and user guides at all-guides.com ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description SWITCHES SW2207 72794688 0504101T34 SWITCH,TACT EVQ21505R SW2251 72794688 0504101T34 SWITCH,TACT EVQ21505R SW2252 72794688 0504101T34 SWITCH,TACT EVQ21505R SW2253 72794688 0504101T34 SWITCH,TACT EVQ21505R SW2254 72794688 0504101T34 SWITCH,TACT...
  • Page 67 All manuals and user guides at all-guides.com ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description MISCELLANEOUS B4016 72795787 0246C51024 CORE,BEADS MMZ1608R102CT B4017 72795787 0246C51024 CORE,BEADS MMZ1608R102CT B4019 72795787 0246C51024 CORE,BEADS MMZ1608R102CT B4022 72795787 0246C51024 CORE,BEADS MMZ1608R102CT B4201 72794355 024HT03563 CORE,BEADS...
  • Page 68 All manuals and user guides at all-guides.com ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description MISCELLANEOUS ! FB401 72796673 043227017F TRANSFORMER,FLYBACK FSU27A004_M FH1701 72794496 06710T0009 HOLDER,FUSE EYF-52BCY FH1702 72794496 06710T0009 HOLDER,FUSE EYF-52BCY NR2401 72783385 110P4220M6 R,NETWORK 4D02WGJ0220TCE NR2402 72783385 110P4220M6...
  • Page 69 All manuals and user guides at all-guides.com TOSHIBA CORPORATION 1-1, SHIBAURA 1-CHOME, MINATO-KU, TOKYO 105-8001, JAPAN...
