Bresser TENDENCE WSX Instruction Manual

Wetterstation • Weather station
TENDENCE WSX
Art. No. 7006405
Instruction Manual
GB
OVERVIEW
MAIN UNIT
1
3 4 5
1. LCD display
2. [ SNOOZE / LIGHT ] key
- When alarm is sounding, press to stop the current alarm and enter snooze.
- When alarm is sounding, press and hold for 2 seconds to stop the current alarm, the
clock will sound again in the next day.
3. [ HISTORY ] key
- In normal mode, press to display the past 24 hour pressure records.
4. [ MEM ] key
- In normal mode, press to check maximum and minimum thermo-hygro reading, or
press and hold for 3 seconds to delete both records.
5. [ 12/24 / ] key
- In normal mode, press to switch between 12 or 24 hour format of time display, or
press and hold for 3 seconds to activate wireless sensor pairing mode.
- In setting mode, press to decrease the setting values.
6. [ CH / ] key
- In normal mode, press to switch between CH 1~3 of outdoor sensor's weather
display, or press and hold for 2 seconds to enter auto-cycle mode.
- In setting mode, press to increase the setting values.
7. [ TIME ] key
- In normal mode, press to switch between alarm 1 and alarm 2, or press and hold for
2 seconds to enter time setting mode.
- In time setting mode, press to step the setting.
8. [ ALARM ] key
- In normal mode, press to turn on/off alarm1 and alarm 2, or press and hold for 2
seconds to enter alarm setting mode.
- In alarm setting mode, press to step the setting.
9. [ °C / °F ] key
- In normal mode, press to switch between Celsius and Fahrenheit, or press and hold
for 3 seconds to receive the RC signal once.
10. [ BARO ] key
- In normal mode, press to switch between hPa (mb) and inHg, or press and hold for 3
seconds to enter the "rel" and "abs" switch mode.
11. [ RESET ] key
- In case of malfunction, press to reset the main unit.
12. Battery compartment
LCD DISPLAY
1. Ch. 1-3 temperature & humidity
reading
2. Indoor temperature & humidity
reading
3. Weather forecast, Baro pressure
& moon phase section
4. Time and calendar section
2
6 7 8 9
12
1
2
WIRELESS THERMO-HYGRO SENSOR
1. LED indicator
- Flashes when the remote unit is
transmitting.
2. LCD display
- to show the detected temperature or
humidity of the sensor.
3. Wall mounting holder
4. [ RESET ] key
- Press to restart the sensor.
5. [ CHANNEL ] slide switch
- Assign the transmitter to Channel
from 1 to 3.
6. Battery compartment
- Accommodates 2 x AA size batteries.
GETTING STARTED
WIRELESS SENSOR
1. Remove the battery door.
2. Insert 2 x AA size batteries into the battery compartment. Make sure you insert
them the right way according to the polarity information marked on the battery
compartment.
3. Replace the battery door.
The sensor will now start transmitting signals, and LED indicator flashes.
NOTE:
- Once the channel is assigned to a sensor, you can only change it by removing the
batteries or resetting the sensor, you also need to press and hold [ 12/24 /
3 seconds on main unit to pair this sensor.
- After replacing the batteries of the wireless sensor or the unit fails to receive wireless
sensor signal of a specified channel, you need to press and hold [ 12/24 /
seconds on main unit to pair this sensor again.
- Avoid placing the transmitter in direct sunlight, rain or snow.
- The building material and the position of the receiver and transmitter affect the
effective range. So try various locations to obtain the best result.
- Place the units away from metal objects and electrical appliances to minimize the
interference. Position the receiver and transmitter within the effective transmission
range: 30m in usual circumstances.
MAIN UNIT
1. Remove the battery door and insert 2 x AA batteries into the battery compartment,
according to the polarity mark on the battery compartment.
2. After the batteries are installed, all LCD segment will be shown.
3. Press the [ RESET ] key of main unit first.
4. Replace the battery door.
5. After 5 minutes channel searching, it will turn to RC signal reception automatically.
6. Radio Controlled function, the current time & date automatically synchronized with
the time signal transmitted from Germany (DCF77) or UK (MSF).
10 11
NOTE:
- If no display appears on the LCD after installing the batteries, press the [ RESET ] key
by using a metal wire.
- You may not receive the RCC and wireless sensor(s) signal immediately. Due to the
atmospheric disturbance, the best reception often occurs during night time.
VIEW MULTIPLE WIRELESS SENOR CHANNELS
1. In normal mode, press [ CH /
2. In normal mode, press and hold [ CH /
mode, After a "bi" sounds, it will alternately displays the CH 1~3 at 4 second intervals.
3. During auto-cycle mode, press [ CH /
display the current channel.
RECEPTION OF RADIO CONTROLLED SIGNAL
The time and date are radio-controlled. The current time and date are automatically
synchronized with the time signal transmitted from Germany (DCF77) or UK (MSF).
When used for the first time (after inserting the batteries or pressing the [ RESET ]
key), the clock will start to receive the RC signal after 5 minutes with the signal strength
indicator flashing. You can also press and hold [ °C / °F ] key with 3 seconds to receive
the RC signal once.
RCC SIGNAL INDICATOR
The signal indicator shows signal receive status. The signal receiving status could be
classified into 2 types:
No RCC signal received
NOTE:
- Every day the wireless sensor will automatically search for the time signal at 2:00 ,
3:00, 4:00 and 17:00.
- Always place the unit away from interfering sources such as TV set, computer, etc.
- Avoid placing the unit on or next to metal plate.
- Closed area such as airport basement, tower block or factory is not recommended.
- Do not start reception on a moving article such as vehicle or train.
- User can permanent disable or enable the RC function by press and hold the
[SNOOZE/LIGHT] key for 8 seconds, once the setting complete, the ON or OFF icon
will show on the LCD.
DAYLIGHT SAVING TIME (DST)
This clock has been programmed to automatically switch when the daylight saving time is
in effect. User can disable the DST function in time and calendar setting mode.
NOTE:
3
DST AUTO/OFF setting only available when RCC function is ON.
TIME AND CALENDAR SETTING
1. In normal mode, press and hold [ TIME ] key for 2 seconds to enter date and time
setting mode.
2. Press [ CH /
3. Press [ TIME ] key to enter the next setting.
4. The setting sequence: year
hour
5. Press [ TIME ] key or leave the unit for 30 seconds to complete the setting and return
to normal mode.
4
6. Weekday language GB
] key to switch the display between CH 1~3.
] key for 2 seconds to enter auto-cycle
] key again to stop auto-cycle mode and
Receiving RCC signal
] or [ 12/24 / ] key to adjust the setting.
DM / MD month
minute second weekday language
FR DE ES
] key for
] key for 3
Received RCC signal
day DST AUTO / OFF
± 23 Hour offset.
IT
