Veriton L670G
Product End-of-Life Disassembly Guide
I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VERITON L670G and is the answer not in the manual?

Questions and answers

Summary of Contents for Acer VERITON L670G

  • Page 1 All manuals and user guides at all-guides.com Veriton L670G Product End-of-Life Disassembly Guide...
  • Page 2: Machine Disassembly And Replacement

    All manuals and user guides at all-guides.com Machine Disassembly and Replacement To disassemble the computer, you need the following tools: Wrist grounding strap and conductive mat for preventing electrostatic discharge. Wire cutter. Phillips screwdriver (may require different size). NOTE: The screws for the different components vary in size. During the disassembly process, group the screws with the corresponding components to avoid mismatches when putting back the components.
  • Page 3 All manuals and user guides at all-guides.com General Information Before You Begin Before proceeding with the disassembly procedure, make sure that you do the following: Turn off the power to the system and all peripherals. Unplug the AC adapter and all power and signal cables from the system.
  • Page 4: Disassembly Procedure

    All manuals and user guides at all-guides.com Disassembly Procedure This section tells you how to disassemble the system when you need to perform system service. CAUTION: Before you proceed, make sure you have turned off the system and all peripherals connected to it.
  • Page 5: Standard Disassembly Process

    All manuals and user guides at all-guides.com Standard Disassembly Process 1. Opening the computer: 1.1 Remove the screw fixed in the cover_stand 1.2 Remove the screw fixed in the cover_top. 1.3 Drag the rearward removal. cover_top...
  • Page 6: Removing The Memory

    All manuals and user guides at all-guides.com 2. Removing the CPU Release the four screws fixed in the thermal_module Remove the 3. Removing the Memory Release the two latches shown bellow then remove the Memory.
  • Page 7: Removing The Hdd

    All manuals and user guides at all-guides.com 4. Removing the HDD Remove the two screws fixed in the chassis Remove the 5. Removing the WLAN mini pci-e card Remove the screw fixed in the cover_bottom...
  • Page 8 All manuals and user guides at all-guides.com Drag the rearward removal. cover_bottom Remove the two screws fixed in the WLAN mini PCI-E card. Disconnect the main & aux antenna cable from the WLAN mini PCI-E card...
  • Page 9 All manuals and user guides at all-guides.com 6. Removing the Serial port cable Disconnect the serial port cable. Remove the six screws fixed in the chassis 7. Removing the ODD Remove the one screw fixed in the chassis...
  • Page 10: Removing The Main Board

    All manuals and user guides at all-guides.com Remove t h e f o u r Latches. cover Front IO Remov e the 8. Removing the Main Board Remove the three screws fixed in the Bracket_Front_IO...
  • Page 11 All manuals and user guides at all-guides.com Release the Bracket_Front_IO Remove the five screws fastening the main board to the chassis Disconnect the two cables.
  • Page 12 All manuals and user guides at all-guides.com Remove the M/B and RTC Battery. 9. Removing the FAN Remove the eight screws fixed in the chassis...
