Aiwa HS-TA380 Service Manual
Aiwa HS-TA380 Service Manual

Aiwa HS-TA380 Service Manual

Cassetter player, stereo radio
Hide thumbs Also See for HS-TA380:

Advertisement

Quick Links

All manuals and user guides at all-guides.com
SERVICE MANUAL
STEREO RADIO
CASSETTE PLAYER
Frequency range:
Maximum output:
Power source:
Battery life:
Maximum dimensions:
Weight
• Design and specifications are subject to change without notice.
HS-TA380
BASIC TAPE MECHANISM : 3ZM-1 P4N
SPECIFICATIONS
FM: 87.5 – 108 MHz
AM: 530 – 1605kHz
20 mW + 20 mW (EIAJ/16Ω)
Battery DC 3V, R6 (size AA) X2
Domestic AC power using the optional AC adaptor:
AIWA AC – 620 / AC – 302
Manganese batteries (R6P,AA) Approx. 6 hours (EIAJ,1mW output,
playback mode)
Alkaline batteries (LR6, AA) Approx. 18 hours using (EIAJ,1mW output,
playback mode)
119 (W) x 90 (H) x 38.2 (D) mm (4
Approx.171.5g (6oz) (excluding batteries)
S/M Code No. 09-986-280-0FP
3
/
x 3
5
/
x 1
9
/
in.)
4
8
16
YH

Advertisement

loading

Summary of Contents for Aiwa HS-TA380

  • Page 1 20 mW + 20 mW (EIAJ/16Ω) Power source: Battery DC 3V, R6 (size AA) X2 Domestic AC power using the optional AC adaptor: AIWA AC – 620 / AC – 302 Battery life: Manganese batteries (R6P,AA) Approx. 6 hours (EIAJ,1mW output, playback mode) Alkaline batteries (LR6, AA) Approx.
  • Page 2 All manuals and user guides at all-guides.com DISASSEMBLY INSTRUCTIONS • REMOVAL OF REAR CABINET 1. Remove 2 screws. 2. Romove 2 switch knobs. 3. Press on Rear Cabinet indicated by arrows 1 and 2 to release the catches. 4. Remove the Rear Cabinet in the direction or arrow 3 . •...
  • Page 3 All manuals and user guides at all-guides.com • REASSEMBLY OF THE CASSETTE LID SPRING Cassette lid (T-SPRING) Frame 1. Insert A into the hole on the cassette foot. center 2. Fix B onto the Frame center indicated by arrow. 3. Fix C as shown in the diagram. 4.
  • Page 4 All manuals and user guides at all-guides.com FRONT C.B. 1. To reassemble the Lid, window, slide all knobs on the Lid, window and all switches on the FRONT C.B to the MAX position. 3 switches 2. Slide the Lid, window in the direction of the arrows A into at max the Lid cassette, followed by the rest of the hooks.
  • Page 5 All manuals and user guides at all-guides.com CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code Value of resistor Chip resistor Dimensions Wattage Symbol Type Tolerance Resistor Form 1/16W 1608 0.45 2125 1/10W 1.25 0.45 3216 1/8W 0.55...
  • Page 6 All manuals and user guides at all-guides.com...
  • Page 7 All manuals and user guides at all-guides.com...
  • Page 8 All manuals and user guides at all-guides.com VOLUME L102 PVC1 TC101 TC104 L103 TC102 TC103 L105 L104 PHONES L101 BAR ANT...
  • Page 9 All manuals and user guides at all-guides.com CUSHION LED 3ZM-1 P4N MAIN C.B...
  • Page 10 All manuals and user guides at all-guides.com EW 1/1...
  • Page 11: Tape Mechanism Parts List

    All manuals and user guides at all-guides.com TAPE MECHANISM PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 83-ZM1-201-919 CHAS,MAIN 26 83-ZM1-237-21K PULLEY,MOTOR 2 83-ZM1-273-019 LVR,AUTO 2 27 83-ZM1-233-119 GEAR,R 3 83-ZM1-232-119 GEAR,FR 28 83-ZM1-267-119 LVR,DEF AUTO...
  • Page 12: Spring Application Position

    All manuals and user guides at all-guides.com SPRING APPLICATION POSITION 83-ZM1-230-010 SPR-C,SLIP 83-ZM1-246-010 83-ZM1-241-010 83-ZM1-265-010 SPR-T,R L SPR-C,PLAY SPR-C,AUTO 83-ZM1-245-010 SPR-T,DIR 83-ZM1-264-010 83-ZM1-248-010 83-ZM1-247-010 SPR-T,LOCK SPR-T,AUTO SPR-T,FF REW 83-ZM1-240-010 83-ZM1-269-010 SPR-C,BT R SPR-C,BT L 83-ZM1-281-010 SPR-T,PLAY P 83-ZM1-252-010 83-ZM1-244-010 SPR-T,PINCH JR SPR-T,PINCH L...
  • Page 13: Accessories / Package List

    All manuals and user guides at all-guides.com ACCESSORIES / PACKAGE LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION...
  • Page 14 All manuals and user guides at all-guides.com 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 Printed in Singapore 9630472 750038...
