  • Page 60 http://www.xiaoyu163.com 6ZG-1 English 3 7 63 1515 0 SERVICE MANUAL L 13942296513 CD MECHANISM BASIC CD MECHANISM :3ZG-2 E2NM TYPE ZZRNDM YZZRNDM ZZRNIM YZZRNDCM u163 S/M Code No. 09-001-338-7N8 http://www.xiaoyu163.com...
  • Page 61 http://www.xiaoyu163.com PROTECTION OF EYES FROM LASER BEAM DURING SERVICING 3 7 63 1515 0 This set employs laser. Therefore, be sure to follow carefully the CAUTION instructions below when servicing. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous WARNING! radiation exposure.
  • Page 62 http://www.xiaoyu163.com Precaution to replace Optical block (KSS-213F) 3 7 63 1515 0 Body or clothes electrostatic potential could ruin laser diode in the optical block. Be sure ground body and workbench, and use care the clothes do not touch the diode. 1) After the connection, remove solder shown in the right figure.
  • Page 63 http://www.xiaoyu163.com DISASSEMBLY INSTRUCTIONS-1/3 3 7 63 1515 0 1. How to replace PICK UP. PICKUP Open the TRAY. Push the stopper to arrow direction and release half of the SHAFT SLED. Turn GEAR MAIN CAM to the counterclockwise (arrow “a”) direction, and lift up CD mechanism. (Fig-1) Remove SHAFT SLED.
  • Page 64 http://www.xiaoyu163.com DISASSEMBLY INSTRUCTIONS-2/3 3 7 63 1515 0 3. The disassemble and reassemble the TRAY 3-1. Disassembling procedure. Push the PLATE GEAR’S Boss at the bottom part of CHAS MECHA strongly to the outside (arrow “b” direction). (Fig-3) (Confirm that TRAY appears a little in the front.) Draw TRAY to the open position.
  • Page 65 http://www.xiaoyu163.com DISASSEMBLY INSTRUCTIONS-3/3 3 7 63 1515 0 4. How to reassemble the TURN TABLE. (Fig-7) Push LEVER TT in the direction of “C”, and put in the TURN TABLE 5CD. (Fig-7) After reassembly, one of the TURN TABLE DISC TRAY (can be either one of the five disc trays) must be aligned with TURN TABLE 5CD.
  • Page 66 http://www.xiaoyu163.com ELECTRICAL MAIN PARTS LIST-1/2 3 7 63 1515 0 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C158 87-A11-132-080 CAP,TC U 0.01-50 K B<ZZRNIM> C160 87-010-405-040 CAP,E 10-50 87-A21-821-130 C-IC,LC78645NE C201 87-010-759-080 C-CAP,U, 0.1-25F 87-001-982-010 IC,TA7291S C202 87-010-382-040...
  • Page 67 http://www.xiaoyu163.com ELECTRICAL MAIN PARTS LIST-2/2 3 7 63 1515 0 • Regarding connectors, they are not stocked as they are not the initial order items. The connectors are available after they are supplied from connector manufacturers upon the order is received. CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure...
  • Page 68 http://www.xiaoyu163.com TRANSISTOR ILLUSTRATION-1/1 3 7 63 1515 0 E C B E C B 2SC1815 2SA1235 2SC2001 PT380F KTA1266 2SD2172 2SC3052 CSA952K DTC143TK RT1N141C L 13942296513 u163 http://www.xiaoyu163.com...
  • Page 69 http://www.xiaoyu163.com IC BLOCK DIAGRAM-1/1 IC, BA6998FP 3 7 63 1515 0 IC, TA7291S L 13942296513 PROTECTOR CIRCUIT (TSD) STOP u163 BRAKE : HI IMPEDANCE NOTE : INPUT “H” ACTIVE -10- http://www.xiaoyu163.com...
  • Page 70 http://www.xiaoyu163.com BLOCK DIAGRAM-1/1 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 PS401 w w w u 1 6 3 -11- http://www.xiaoyu163.com...
  • Page 71 http://www.xiaoyu163.com WIRING-1/2 (5CD) 3 7 6 3 1 5 1 5 0 CN202 CN501 C111 C160 C158 C140 C110 C143 C116 C117 Q201 1 3 9 4 2 2 9 6 5 1 3 C221 D301 D202 FB204 C361 L101 FB203 C362 Q352...
  • Page 72 http://www.xiaoyu163.com SCHEMATIC DIAGRAM-1/1 3 7 6 3 1 5 1 5 0 1 3 9 4 2 2 9 6 5 1 3 w w w u 1 6 3 SG-240 -13- http://www.xiaoyu163.com...
  • Page 73 http://www.xiaoyu163.com WIRING-2/2 (T-T/CD MOTOR) 3 7 63 1515 0 TO 5CD C.B CN301 TO 5 C D C. B C N 5 0 1 L 13942296513 u163 -14- http://www.xiaoyu163.com...
  • Page 74 http://www.xiaoyu163.com WAVE FORM-1/1 3 7 63 1515 0 CN301 Pin 4 (PH2) VOLT/DIV: 5V Between IC501 VOLT/DIV: 1V TIME/DIV: 2S Pin ! (SLED+) and @ (SLED–) TIME/DIV: 2S CN301 Pin 6 (PH1) VOLT/DIV: 10V (Shutter Close) TIME/DIV: 2S CN202 Pin 8 (DISH. SENS) VOLT/DIV: 2V TIME/DIV: 2S (NO DISC)
  • Page 75 http://www.xiaoyu163.com IC DESCRIPTION-1/1 (LC78645NE)-1/2 3 7 63 1515 0 Pin No. Pin Name Description SLCO Control output. SLCIST SLCO output current adjustment resistor connection pin. EFMIN RF signal input pin. RF monitor pin. RFVDD — RF power supply pin. RFVSS —...
  • Page 76 http://www.xiaoyu163.com IC DESCRIPTION-1/1 (LC78645NE)-2/2 3 7 63 1515 0 Pin No. Pin Name Description LCHO L channel output pin. LVSS — L channel ground pin. Must be connected to 0V. RVSS — R channel ground pin. Must be connected to 0V. RCHO R channel output pin.
  • Page 77 http://www.xiaoyu163.com MECHANICAL EXPLODED VIEW-1/1 3 7 63 1515 0 L 13942296513 (AZF-H) 3ZG-2 E2 CUSH CD A u163 -18- http://www.xiaoyu163.com...
  • Page 78 http://www.xiaoyu163.com MECHANICAL PARTS LIST-1/1 3 7 63 1515 0 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 86-ZG1-001-410 TRAY,5CD 31 86-ZG1-215-110 HLDR,CHUCK 2 84-ZG1-267-010 PULLEY,LOAD MO 8 32 86-ZG1-238-010 HLDR,MAGNET 6ZG N 3 87-A90-036-010 MOT ASSY,RF-300CA-11 33 86-ZG1-225-010 BELT,SQ1.2-32.9 4 86-ZG1-228-110...
  • Page 79 http://www.xiaoyu163.com 3 7 63 1515 0 COLOR NAME TABLE Basic color symbol Color Basic color symbol Color Basic color symbol Color Black Cream Orange Green Gray Blue Transparent Blue Gold Pink Silver Titan Silver Brown Violet White Transparent White Yellow Transparent Yellow Metallic Blue Light Blue...
  • Page 80 http://www.xiaoyu163.com CD MECHANISM EXPLODED VIEW 1/1 (3ZG-2 E2) 3 7 63 1515 0 L 13942296513 u163 -21- http://www.xiaoyu163.com...
  • Page 81 http://www.xiaoyu163.com CD MECHANISM MAIN PARTS LIST 1/1 (3ZG-2 E2) 3 7 63 1515 0 REF. NO PART NO. KANRI DESCRIPTION 1 83-ZG2-261-010 CHAS ASSY, E2 2 87-A90-836-010 PICKUP,KSS-213F(E2) 3 83-ZG2-235-010 GEAR,A3(E2) 4 83-ZG2-205-210 GEAR,B(E2) 5 83-ZG2-236-010 GEAR,MOTOR 3(E2) 6 83-ZG2-253-110 SHAFT,SLIDE 5(E2) 7 87-045-356-010 MOT,RF-310TA 30(E2)
  • Page 82 http://www.xiaoyu163.com 3 7 63 1515 0 L 13942296513 u163 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111 Printed in Singapore 0251431 http://www.xiaoyu163.com...
