- Page 1 All manuals and user guides at all-guides.com HS-JX989 AH,YH SERVICE MANUAL STEREO RADIO BASIC TAPE MECHANISM : 7ZM-1 R1NF CASSETTE RECORDER S/M Code No. 09-008-434-6N1...
-
Page 2: Specifications
All manuals and user guides at all-guides.com SPECIFICATIONS Frequency range: Reception area EU AM 531 – 1,602 kHz (9 kHz steps) FM1, FM2 87.5 – 108 MHz (50 kHz steps) Reception area USA AM 530 – 1,710 kHz (10 kHz steps) FM1, FM2 87.5 –... -
Page 3: Electrical Main Parts List
All manuals and user guides at all-guides.com ELECTRICAL MAIN PARTS LIST REF. PART KANRI DESCRIPTION REF. PART KANRI DESCRIPTION C122 87-A10-704-080 C-CAP,TN 100-2.5 M B2 C123 87-A10-561-080 C-CAP,V 0.01U-16 K B 87-A21-179-040 C-IC,TA2123AF C124 87-A10-561-080 C-CAP,V 0.01U-16 K B 87-A21-651-030 C-IC,LA3235W C125 87-A10-565-080... - Page 4 All manuals and user guides at all-guides.com REF. PART KANRI DESCRIPTION REF. PART KANRI DESCRIPTION C601 87-012-286-080 CAP, U 0.01-25 C958 87-A10-561-080 C-CAP,V 0.01U-16 K B C602 87-012-282-080 CAP, U 4700P-50 C959 87-016-296-080 C-CAP,TN 22-4SV(A) C603 87-010-787-080 C-CAP, U 0.22-25 KB C960 87-A10-565-080 C-CAP,V 0.1U-16 Z F...
-
Page 5: Chip Resistor Part Code
All manuals and user guides at all-guides.com CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code Value of resistor Chip resistor Dimensions (mm) Symbol Wattage Type Tolerance Resistor Code Form 1/16W 1005 0.35 1/16W 1608 0.45 1/10W 2125 1.25 0.45 1/8W... -
Page 6: Ic Block Diagram
All manuals and user guides at all-guides.com LCD DIAGRAM IC BLOCK DIAGRAM LCD, AIW4223 GRID ASSIGNMENT ANODE CONNECTION – 6 –... - Page 7 All manuals and user guides at all-guides.com – 7 –...
- Page 8 All manuals and user guides at all-guides.com WIRING - 8 -...
-
Page 9: Schematic Diagram
All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM – 9 –... - Page 10 All manuals and user guides at all-guides.com IC DESCRIPTION IC, TC9327AF-507 Pin No. Pin Name Description Pin No. Pin Name Description 1 ~ 4 COM1 ~ COM4 LCD driver common output. TEST – Connected to ground. 5 ~ 24 SEG1 ~ SEG20 LCD driver output.
- Page 11 All manuals and user guides at all-guides.com ADJUSTMENT <TUNER SECTION> <TAPE SECTION> 1. AM IF Adjustment 8. Tape Speed Adjustment IFT801 ..............450 kHz Settings : • Test tape : TTA–100 • Test point : Phones Jack (J101) 2. FM IF Adjustment •...
-
Page 12: Mechanical Exploded View
All manuals and user guides at all-guides.com MECHANICAL EXPLODED VIEW 1 / 1 MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 8A-HJ2-024-010... -
Page 13: Tape Mechanism Exploded View
All manuals and user guides at all-guides.com TAPE MECHANISM EXPLODED VIEW 1 / 1 TAPE MECHANISM PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. -
Page 14: Accessories / Package List
All manuals and user guides at all-guides.com ACCESSORIES / PACKAGE LIST REF. PART KANRI DESCRIPTION 1 8A-HJ2-920-010 IB,AH(CK)S989<AH> 1 8A-HJ2-912-010 IB,AH(ECK)S989<AH> 1 8A-HJ2-913-010 IB,YHS(ECH)S989<YH> 2 87-B30-298-010 BAT,NB-5G(S) 3 8Z-HK4-090-010 BOX,BAT ASSY SIL 4 82-HK3-951-010 CARRYING,CASE 5 87-B30-341-110 CHARGER,RB-107 H (L) 6 87-B30-405-010 HEADPHONE,HP-M041(T2) 7 87-041-083-110... - Page 15 All manuals and user guides at all-guides.com 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9630472 0251431 Printed in Singapore...
