- Page 1 IP60D Manual...
-
Page 2: Product Overview
Product overview DECT SIP phone is the telephone that transmits voice over network based on IP protocol. IP60D is specially designed for top grade hotels’ telecommunication. It features digital signal processing technology and other patented technologies, which ensures clear sound, stable quality, powerful function and elegant outlook design, etc. - Page 3 Assembly, disassembly and installation 1. Install the handset cord Insert one end of the attached handset cord to jack on the handset, the other end to the jack of the base 2. Correctly install the battery 3. Connect the WAN port with the POE port of the PBX via internet cable 4.
- Page 4 Note: 1. Please install the phone in dry and clean environment and avoid effected with damp. 2. The telephone should avoid fire, water spray, shock, clean the surface dust by soft cloth; chemical solvent is prohibited to use. Diagrammatic drawing and function illustration. 1.
-
Page 5: Configuration With Web Browser
1. Service Button 2. ON button 3. REDIAL 4. Digital buttons 5. Indicator of low voltage 6. VOL 7. OFF button 8. MUTE 9. HOLD 10. Bracket 11. Adapter 13. Power Jack Configuration 1. Configuration with web browser When telephone and PC connected to network, double click logo on PC to open IE ；... - Page 6 be set up as 192.168.1.***(*** can be any number between 0 to 255 except for 171). 2. Web functional descriptions 1) Network setting Connection Type Choosing the way of telephone access to the IP, DHCP mode by default IP Address When using a static IP address, please enter the IP address is assigned Subnet Mask...
-
Page 7: Speed Dial Configuration
Hotline Number Configure the hot line number Note: Please choose YES for SIP Registration. 3) Voice Configuration Preferred Voice Configuration mode of voice CODEC Codec: dial Configure whether # speed dial function enabled immediately: The time wait to dial Set sending time after the dial out: pause Configure PAUSE time... - Page 8 successful upgrade, back to the initial login state Telephone Feature: 1.Placing Phone Call 1) Pick up the corded handset 2) Press button on the base 3) On- hook status, press (green) of the handset; press (green) again to enter the speaker mode. 2.
- Page 9 4) Press ON or SPKR of the cordless handset, then press the servicel button can send the stored numbers. 5. Answering calls 1) Pick up the corded handset or press Pick up the cordless handset when the handset is put into the charging base (green) button of the cordless handset when it isn’t 3) Press the...
- Page 10 ▲/▼ ——Press HOLD+*+HOLD+ , won’t back to default value. 9. Hot Line Function Please choose the "Use Hotline" option on "SIP PROXY-Advanced SIP Settings" through WEB, input the Hotline Number, then click "OK". SIP phone would automatically dial the hot line number once SIP phone off-hook, can not dial the other number, but can receive the incoming call normally.
-
Page 11: Warranty
If the cordless handset rings, it’s successful Simple failure diagnose and troubleshooting 1. No dialing tone of handset A Please check the telephone network, B Please check the connection of handset cord and straight line cord 2. No ringing or no continually ring Please check the telephone line or the quantity of parallel phone set 3. -
Page 12: Fcc Warning
attempted. 3) The product has never been used in a harsh or corrosive environment. 4) No damage in transit THIS LIMITED WARRANTY GIVES THE BUYER SPECIFIC LEGAL RIGHTS. THE BUYER MAY ALSO HAVE OTHER RIGHTS WHICH VARYFROM JURISDICTION TO JURISDICTION. This warranty is only valid for merchandise purchased directly from Bittel or dealers or distributors Bittel Co.
