Summary of Contents for Work Pro SCAN 812 DMX

  • Page 2 T h a n k s f o r y o u r r e l i a b i l i t y o n u s h a v i n g a c q u i r e d a p r o d u c t W O R K . We hope it provides you a long and reliable service. SCAN 812 DMX. Console for scanners control with protocol of comunication USITT DMX 512.

  • Page 3: Program Enable

    Program Enable When the power is turned on, this unit enters Manual mode automatically. Press the Program button for three seconds to activate Program mode, a fast blinking light in the Segment Display next to PROG. Indicates its selection. Programming Scenes 1 .

  • Page 4: Scanner Copy

    Scene Editing 5 . Once you've made your changes, tap the MIDI/Rec button MIDI / REC 6 . Tap the Scene button that corresponds to the scene you're editing. This will overwrite the exited scene. SCENE NOTE: Be sure to select the same scene in steps 3 and 6, otherwise you may accidentally record over an exited scene.

  • Page 5: Delete All Scenes

    Delete all Scenes This function will reset all DMX channel to 0 output. PROGRAM 1 . With the power off, press and hold down the Program and BANK Bank Down buttons at a time. 2 . Apply power again, all scenes should be cleared. Bank Copy 1 .
  • Page 6 Add a Step 1 . Program enable. 2 . Select the chase you wish to add a step to. 3 . Tap the Tap Sync/Display button causing a highlight next to STEP, the firt digit in the Segment Display shows the chase and the next three digits shows its step.

  • Page 7: Running Scenes

    Delete all Chases AUTO/DEL 1 . With the power off, press and hold down the Auto/Del and Bank Down buttons same time. BANK 2 . Apply the power again. Running Scenes Manual Mode SCENE 1 . When the power is turned on, this unit enters Manual mode automatically. 2 .

  • Page 8: Running Chases

    Running Chases You must program scenes before you can run chases. Manual Mode 1 . When the power is turned on, this unit enter Manual mode automatically. 2 . Select your desired chase by tapping one of the six Chase buttons. A second tap of this button will deactivate this function.

  • Page 9: Technical Specifications

    Implementation This unit receives Note On signals, which enables to run 15 bank (01-15) of scenes and 6 chases of scenes. In addition, blackout function can be activated by MIDI signal. BANK NOTE Nº FUNCTION Bank 1 00 to 07 Turn on or off Scenes 1-8 of Bank 1 Bank 2 08 to 15...
  • Page 10 US N C ONNE C T I ON A B L E F R OM 2 0 0 6 V E R S I ON...
  • Page 11 Press the scene buttons to load or stored your scenes. There are maximum of Scene Buttons 240 programable scenes. Segment Display Shows the currnt activity or programming state. Press the Up/Down buttons to select a bank 30 banks. Bank Buttons(Up/Down) Used to select your programmed chase consisting a maximum of 240 scenes.
