User Manual

32X8050
43X8050
Please read this manual before use and retain it for future reference.
www.aoc.com
©2019 AOC. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 32X8050 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AOC 32X8050

  • Page 1: User Manual

    User Manual 32X8050 43X8050 Please read this manual before use and retain it for future reference. www.aoc.com ©2019 AOC. All Rights Reserved.
  • Page 2: Safety Instructions

    Safety Instructions TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE Warnings and Precautions THIS APPLIANCE TO RAIN OR KNOW THESE SAFETY SYMBOLS MOISTURE. The Socket-outlet should be installed near the apparatus and be easily accessible.
  • Page 3: Important Safety Instructions

    • To avoid the risk of shock or does not fit into your outlet, consult permanent damage to the set do an electrician for replacement of the not expose the display to rain or obsolete outlet. excessive moisture. 10. Protect the power cord from being •...
  • Page 4 WARNING: TO REDUCE THE WARNING RISK OF FIRE OR Never place a television set in an ELECTRIC SHOCK, unstable location. A television set may DO NOT EXPOSE THIS fall, causing serious personal injury APPARATUS TO RAIN or death. Many injuries, particularly OR MOISTURE.
  • Page 5 CAUTION: Excessive sound pressure from earphones and headphones can cause hearing loss. Adjustment of the equalizer to maximum increases the earphone and headphone output voltage and the sound pressure level. Therefore, to protect your hearing, adjust the equalizer to an appropriate level.
  • Page 6: Table Of Contents

    Media Player introduction: .. 11 4.2. PDF reader play ....13 4.3. Cloud CMS Software introduction ......15 4.4. AOC cloud CMS and launcher interface switch instructions 16 4.5. U player Autoplay instructions ......18 4.6. U disk files playback and copy instructions ......
  • Page 7: Unpacking And Installation

    This manual is for reference only, please refer to the actual machine. Unpacking and Installation 1.1. Unpacking • This product is packed in a carton, together with the standard accessories. • Any other optional accessories will be packed separately. • Move the display by at least two (2) adults.
  • Page 8: Mounting On A Wall

    Product warranty does not cover damage caused by improper installation. 4. For the wall-mounting kit, use M4(32X8050)/M6(43X8050) mounting screws (having a length 10 mm longer than the thickness of the mounting bracket) and tighten them securely.
  • Page 9: Ventilation Requirements For Enclosure Locating

    Caution: To prevent the display from falling: • For wall or ceiling installation, we recommend installing the display with metal brackets which are commercially available. For detailed installation instructions, refer to the guide received with the respective bracket. • To lessen the probability of injury and damage resulting from fall of the display in case of earthquake or other natural disaster, be sure to consult the bracket manufacturer for installation location.
  • Page 10: Parts And Functions

    Move to the left item when OSD 2.1. Control Panel menu is off. • Decrease the adjustment while OSD 32X8050 menu is on. ] button Move the highlight bar up to adjust the selected item while OSD menu is on. ] button Move the highlight bar down to adjust the selected item while OSD menu is on.
  • Page 11: Input/Output Terminals

    2.2. Input/Output Terminals VGA IN (D-Sub) VGA video input. 32X8050 HDMI2 IN / HDMI1 IN Connect to a source device via an HDMI cable. RS232 Receive command signals from the external RS232 device. USB PORT Connect to a USB storage device.
  • Page 12: Remote Control

    2.3. Remote Control ] FORMAT button Reserved 2.3.1. General functions ] HOME button Go to Android Launcher first widgets. FUNCTION button Reserved ] COLOR buttons Reserved ] Source Button FORMAT FUNCTION Choose input source. SOURCE ] Settings Button Access the OSD menu. [ ] [ ] [ ] [ ]NAVIGATION buttons Up, down, left and right operation key.
  • Page 13: Inserting The Batteries In The Remote Control

    2.3.2. Inserting the batteries in the remote control The remote control is powered by two 1.5V AAA batteries. To install or replace the batteries: 1. Press and then slide the cover to open 2. Insert the batteries with the correct polarity (+) and (–).
  • Page 14: Connecting External Equipment

    Connecting External Equipment 3.1. Connecting External Equipment (DVD/VCR/VCD) 3.1.1. Using HDMI video input DVD / VCR / VCD HDMI out RS232 HDMI 2 HDMI 1 [HDMI IN] 3.2. Connecting a PC 3.2.1. Using HDMI input RS232 HDMI out HDMI 2 HDMI 1 [HDMI IN] 3.2.2.
  • Page 15: Display Control Connection

    3.2.3. Display control connection RS232 HEADPHONE HDMI 2 HDMI 1 D-SUB LINE IN [RS232] [RS232] 3.2.4. Using network interface HEADPHONE LINE IN WiFi INTERNET 3.2.5. Connecting an external audio device RS232 AUDIO AUDIO HDMI 2 HDMI 1 D-SUB HDMI 2 [Audio Out]...
  • Page 16: Connect Usb

    3.3. Connect USB...
  • Page 17: Operation

    Operation 4. If you select the empty playlist, the application will guide you to choose media sources. 4.1. Media Player All media files should be located in the introduction: root directory. For example: - Video at /root/movies/ 1. The front page of the media player, - Photos /root/pictures/ this page contains three items: “Play”, - Music /root/music/...
  • Page 18 7. After you start editing the playlist, you will 10. In choosing the desired file and press the see the following screen. play button, you can directly play media Source - storage device files. files. Playlist - playlist file. There are 4 corresponding to the remote control button icon.
  • Page 19: Pdf Reader Play

    4.2. PDF reader play 4. If an empty playlist is chosen, the app will guide you to select the media source. 1. Home page of Pdf app, this page has All media files should be placed in root three items: “Play”, “Compose” and directory.
  • Page 20 7. Once you start to edit a playlist, you will 9. Select “Settings” on home page, this see below screen. page has two parts, “Repeat Mode” and “Effect Duration”. Source - files in storage. Repeat Mode : play mode. Playlist – files in playlist. Effect Duration : photo effect duration.
  • Page 21: Cloud Cms Software Introduction

    4.3. Cloud CMS Software introduction 1. The following figure is the main function interface of CMS software, used to match the cloud server to achieve program playback. Please contact the dealer for cloud function, so that the software can be used normally. 2.
  • Page 22: Aoc Cloud Cms And Launcher Interface Switch Instructions

    1. Press the remote control [ ] right button to select App. 6. Choose AOC Cloud CMS application. 7. Press the [OK] button. 2. Press the [OK] button to enter the ALL App. 8. Take effect after unplugging the power supply and connect it again.
  • Page 23 11. Press the number key on the remote control: 2018 or 9102 password to exit the cloud CMS setting. 12. Select item Home to set to the native interface.
  • Page 24: U Player Autoplay Instructions

    4.5. U player Autoplay 6. Press [ ] down button to select UPlayer instructions setting, press [OK] to enter UPlayer setting. 1. U disk, the format must be FAT32, and only one partition can not be partitioned, the capacity can not exceed 32G. 2.
  • Page 25: U Disk Files Playback And Copy Instructions

    4.6. U disk files playback and copy instructions 1. U disk, the format must be FAT32, and only one partition can not be partitioned, the capacity can not exceed 32G. 2. Connect your USB device to the USB port on the display. 7.
  • Page 26: Osd Menu

    OSD Menu 5.1.2. Navigating the OSD menu using the display’s control An overview of the On-Screen Display (OSD) buttons structure is shown below. You can use it as a reference for further adjustment of your 1. Press [MENU] button to display the OSD display.
  • Page 27: Operation On The Osd Menu

    5.2. Operation on the OSD menu: Column 2, 3 or Column 1 Column 2 Column 1, 3 Remarks Column 2, 2 Airport and train station Hotel and convenient store Dining and clothing Mode Security control and monitoring Picture Office Mode Outdoor Customize Black Level...
  • Page 28 Key Lock Default password: 0000 [type password] Switch Key Lock On: Step 1: Lock the remote control, button and mouse Current Password operation functions after 5s if there is no operation. New Password Step 2: After the functions Lock are locked, press the “Set”...
  • Page 29 English Language 中文(中国) HDMI1.4 HDMI Available only 43X8050 Version HDMI2.0 Power On Power On Standby Mode Last Status Switch On/Off 1. When SCHEDULE is set with startup time, but the startup time has not HDMI1/ HDMI2/ arrived yet, boot the device PDF/ Media/ Cloud according to the signal Boot On Source...
  • Page 30 1.When Uplayer Setting switch on, Boot On Source is grayed, the setting is unavailable. 2.Supported file name: SuperU 3. To play content in UPlayer, the system will cut the signal source to Switch On/Off USB, and stay at the USB source when plugging and unplugging the USB flash Uplayer...
  • Page 31: Compatibility Of The Usb Device

    Compatibility of the USB device Format of the USB multi-media coder-decoder Video decoding Video Type coder- Container Decoding Coding Channel Remarks decoder Supported size in a range from 48x48 pixels 1920X1080 pixels File format: MPEG1/2 MPEG1/2 Max. frame rate:30fps Max. bit rate: 80Mbps Audio coder-decoder: MP2, MP3 Supported picture size in...
  • Page 32 Supported picture size: from 48x48 pixels to 1920x1080 pixels File format: Max. frame rate:30fps H.264 H.264 MKV, MP4, Max. bit rate: 57.2Mbps 3GP, Audio coder-decoder: MP2, MP3, AAC, (1) Not support MBAFF Supported picture size: frame 48x48 pixels to 1920x1088 pixels File format: Max.
  • Page 33 File format: Supported max. picture size: 4096x4096 pixels File format: No limit in resolution ratio File format: No limit in resolution ratio Notes: • If the standard bite rate/frame rate of the contents is higher than the compatible frames/ second listed in the above table, audio or video may not work. •...
  • Page 34: Input Mode

    Input mode Computer mode (32X8050/43X8050), HDMI computer mode (32X8050) Available resolution ratio Standard Refresh Pixel rate Aspect ratio Horizontal Perpendicular resolution ratio rate pixel line 60 Hz 25.175 MHz 75 Hz 31.5 MHz WVGA 70 Hz 28.32 MHz SVGA 60 Hz...
  • Page 35 HDMI video mode (32X8050) Available resolution ratio Standard resolution Refresh rate Pixel rate Aspect ratio Horizontal Perpendicular ratio pixel line 1080 P 59.94/60 Hz 1920 1080 60 Hz 148.5 MHz 16:9 1080 P 50 Hz 1920 1080 50 Hz 148.5 MHz 16:9 1080 P 29.97/30 Hz...
  • Page 36: Cleaning And Troubleshooting

    Cleaning and Troubleshooting 8.1. Cleaning Caution When Using the Display • Do not bring your hands, face or objects close to the ventilation holes of the display. The top of the display is usually very hot due to the high temperature of exhaust air being released through the ventilation holes.
  • Page 37: Troubleshooting

    8.2. Troubleshooting Symptom Possible Cause Remedy No picture is displayed 1. The power cord is 1. Plug in the power cord. disconnected. 2. Make sure that the power switch is 2. The main power switched on. switch on the back 3.
  • Page 38 After-Images can still be A still picture is displayed Do not allow a still image to be seen on the display after for an over extended displayed for an extended period of the display is powered period of time time as this can cause a permanent off.
  • Page 39: Technical Specifications

    Technical Specifications Display: Specifications Item 32X8050 43X8050 Screen Size (Active Area) 31.5 inches/801mm 42.5 inches/1080mm Aspect Ratio 16:9 16:9 Number of pixels 1920 (H) x 1080 (V) 3840 (H) x 2160 (V) Pixel pitch 0.36375 (H) x 0.36375 (V) 0.2451 (H) x 0.2451 (V) [mm]...
  • Page 40 Internal Speaker: Specifications Item 32X8050 43X8050 Number of Speakers Input 5 W X 2 8 W X 2 Impedance 8 Ω 8 Ω Frequency Response 160 Hz ~ 13 KHz 160 Hz ~ 13 KHz...
  • Page 41 2019 © All rights reserved. Specifications are subject to change without notice.
