Actel SoC Solutions Series Quick Start Manual

Trax
Swif
Step 5. Running the
Trax
On the PC start the Swif monitor by going to the
CD:\Actel_AGL\Preloaded Design\Software\SwifTrax
folder and double clicking on the SwifTrax.exe file.
Trax
The Swif monitor can now be used to read and write register and
memory locations on the pre-loaded design. The pre-loaded design is SoC
Solutions' PiP-EC02 platform. For more information, see PiP-EC02
documentation under the Available IP folder or contact SoC Solutions
support@socsolutions.com for details.
For additional information, please refer to the
Development Kit User's Guide
IGLOO
For support please contact SoC Solutions at
support@socsolutions.com .
For information on additional products for the IGLOO Development Kit,
please contact sales@socsolutions.com
Copyright 2007 ©. All rights reserved. All logos and trademarks are property of the respective companies.
monitor
.
IGLOO
Development Kit
Quick Start Guide
1Mbyte
SRAM
USB Connector
(Flash Pro3
Programmer)
USB / Serial
Connector
LEDs
Switches
AGL Development Board
In the box...
•
AGL Development Board
•
AGL Development Kit Install CD
•
Libero IDE (CD)
•
2 USB Cables
AGL-DEV-KIT-SCS
IGLOO FPGA
16Mbyte with example processor
Flash subsystem
Flash*Freeze
Switch
