Operating Instructions
Mechanical Tank Contents Gauge with
Electronic Remote Indication
Type: Unimes E
Part no.: 52130
Read instructions before using device!
Observe all safety information!
Keep instructions for future use!
Version: 10.2007
Id. no.: 854.001.0422
Mess-, Regel- und
Überwachungsgeräte
für Haustechnik,
Industrie und Umweltschutz
Lindenstraße 20
DE-74363 Güglingen
Phone: +49(0)7135-102-0
Service: +49(0)7135-102-211
Telefax: +49(0)7135-102-147
E-Mail: info@afriso.de
Internet: www.afriso.de
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Afriso EURO-INDEX Unimes E
Summary of Contents for Afriso EURO-INDEX Unimes E
-
Page 1: Operating Instructions
Telefax: +49(0)7135-102-147 E-Mail: info@afriso.de Internet: www.afriso.de Operating Instructions Mechanical Tank Contents Gauge with Electronic Remote Indication Type: Unimes E Part no.: 52130 Read instructions before using device! Observe all safety information! Keep instructions for future use! Version: 10.2007 Id. no.: 854.001.0422... -
Page 2: Table Of Contents
Entering the tank data at the remote indicator ...........15 Mounting the direct indication gauge............16 Operation .......................16 Switching Unimes E on and off ..............16 Display formats of the remote indicator............17 Correcting the tank data of the remote indicator ........17 Subsequent zero point adjustment at the remote indicator......17 Maintenance ......................18... - Page 3 10 Shutting down, disposal ..................19 11 Spare parts and accessories ................19 12 Warranty........................ 20 13 Copyright....................... 20 14 Customer satisfaction ................... 20 15 Addresses ......................20 Unimes E...
-
Page 4: This Instruction Manual
Explanation of symbols and typeface Symbol Meaning Prerequisite for an activity Activity consisting of a single step Activity consisting of a several steps Result of an activity • Bulleted list Indication on display Text Highlighting Highlighting Unimes E... -
Page 5: Safety
Unimes E is not safety equipment. It does not replace the func- tion of a level sensor at the fuel oil tank. Unimes E may only be installed in unpressurised tanks. An ap- proved tank vent and a fully functional level sensor must be in- stalled. -
Page 6: Staff Qualification
The manufacturer or the sales company shall not be liable for any damage whatsoever resulting from any use other than the use explicitly permitted in this instruction manual. AFRISO-EURO-INDEX GmbH shall not be liable for misprints. Unimes E... -
Page 7: Product Description
• Direct indication gauge with float Direct indication gauge G2 thread G1½ thread Float • Remote indicator with battery and connection cable Display Programming keys PG cable gland Connection cable Function key • Wall bracket for remote indicator Unimes E... -
Page 8: Function
The display mode is se- lected by means of function key F. The two programming keys are used to enter the tank data. Application example Fig. 1: Application example Unimes E... -
Page 9: Technical Specifications
Cable length 10 m Housing material PA6 15 % glass loaded Supply 3.6 V lithium battery Service life of battery Max. 8 years (if F key is pressed once per month) Display 4-digit LC display Resolution 14 bits Unimes E... -
Page 10: Approvals, Tests, Conformities
According to EN 50082-1 Accuracy of the complete system*: < ± 5 % FSO, IEC 60770 * relating to indication of the liquid level in mm. Approvals, tests, conformities Unimes E complies with the EMC directive (89/336/EEC und 92/31/EEC). Transport and storage CAUTION Damage to the device due to improper transport. -
Page 11: Mounting And Commissioning
Mounting and commissioning Mounting and commissioning Determining the tank data Before Unimes E can be installed, you must determine the tank data. For safety reasons and to facilitate subsequent checks, you should document the tank data on this page. Tank shape Determine the tank shape code using the table below. -
Page 12: Mounting The Wall Bracket For The Remote Indicator
Mark the point, push the float up to the mark and press lead seal 3 together to fixate the float Adjusting the tank height at the direct indication gauge The direct indication gauge is factory-adjusted to the maximum height which corresponds to a tank height or diameter or 200 cm. Unimes E... -
Page 13: Connecting The Direct Indication Gauge And The Remote Indicator
Connecting the battery of the remote indicator When the direct indication gauge and the remote indicator are electrically connected, open the housing of the remote indicator by turning the upper part all the way to the stop and pulling it open. Unimes E... -
Page 14: Zero Point Adjustment At The Remote Indicator
0.00. In this state, zero calibration can be performed any number of times. Press the F key in order to terminate zero calibration. An arrow pointing to the unit "Litres" is displayed at the bottom of the display. Unimes E... -
Page 15: Entering The Tank Data At The Remote Indicator
The key allows you to change the selected digit within a range from 0 to 9. Press the F key to accept the setting and continue with the cur- rent level. Unimes E... -
Page 16: Mounting The Direct Indication Gauge
Mounting the direct indication gauge Slowly lower the float into the tank. Screw the direct indication gauge into the tank. Operation Switching Unimes E on and off Direct indication gauge The direct indication gauge is always on. Remote indicator Press the F key to switch on the display of the remote indicator. -
Page 17: Display Formats Of The Remote Indicator
The pointer of the direct indication gauge points to zero. Unplug the battery connector from the PCB. Proceed as described in chapter 6.6, page 13, to chapter 6.8, page 15. If you press the mini button when connecting the battery con- nector, all tank data is cleared. Unimes E... -
Page 18: Maintenance
Check the battery nector is not con- connector. nected to the printed. The display toggles Incorrect tank data Correct the tank between the dis- entered. data (refer to chap- played value and "--- ter 7.3, page 17). -". Unimes E... -
Page 19: Shutting Down, Disposal
11 Spare parts and accessories Part Part no. Direct indication gauge with float 06 15 07 Remote indicator 06 15 000010 3.6 V lithium battery 68309 Bracket for wall mounting 00 24 000111 Unimes E... -
Page 20: Warranty
INDEX GmbH.. Please get in touch with us if you have any ques- tions, suggestions or problems concerning your AFRISO product. 15 Addresses The addresses of our worldwide representations and offices can be found on the Internet at www.afriso.de. Unimes E...
