MESI ECGMD Quick Manual

12-lead ecg diagnostic module

Table of Contents

Download this manual

Quick Guide

MESI ECG MODULE

12-lead ECG diagnostic module

WHAT IS IN THE BOX?

ECG measurement unit

Model

ECGMD

Pack of 50 single usage electrodes

Before using the device for the first time, read the user manual carefully and follow

the recommendations here: www.mesimedical.com/support/mTABLET/IFU.

Patient cable for resting ECG -

snap connectors

Table of Contents

Do you have a question about the ECGMD and is the answer not in the manual?

Page 1 Quick Guide MESI ECG MODULE 12-lead ECG diagnostic module WHAT IS IN THE BOX? ECG measurement unit Patient cable for resting ECG - snap connectors Model ECGMD Pack of 50 single usage electrodes Before using the device for the first time, read the user manual carefully and follow...
Page 2 FIRST USE 1. Connect patient cable with module Use only accessories and other parts recommended or supplied by MESI. Use of other than recommended or supplied parts may result in injury, inaccurate information and/or damage to the unit. This product is not designed for sterile use.
Page 3 ECGSYS - 3/5 4. Choose the measurement After selecting the patient, please select the ECG measurement in the application menu. 5. Place the electrodes and start Place electrodes on the patient’s body according to the instructions on the screen. Press start to begin the recording process.
Page 4 ECGSYS - 4/5 7. Result Go to: previous/next result Send for consultation Navigation area Discard result Go to: Application screen Adjust ECG speed and sensitivity Heart rate Electrocardiogram Interpretation Parameters Patient’s recording history Comment Navigation area...
Page 5 (even if these are earthed). The MESI mTABLET ECG users must be adequately trained to use the device. Before the first use of the device, users must carefully read the entire instructions for use and follow the instructions for use of the connected equipment.
