ascobloc ASCOLINE 700 Series Operating Instructions Manual

Lava stone grill
Hide thumbs Also See for ASCOLINE 700 Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Instructions Manual
English Language Version
Operating Instructions
for
ASCOLINE 700
AGL 2xx, 4xx, 6xx
Lava Stone Grill
Quality and Competence in
Stainless Steel

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASCOLINE 700 Series and is the answer not in the manual?

Questions and answers

Related Manuals for ascobloc ASCOLINE 700 Series

Summary of Contents for ascobloc ASCOLINE 700 Series

  • Page 1 English Language Version Operating Instructions ASCOLINE 700 AGL 2xx, 4xx, 6xx Lava Stone Grill Quality and Competence in Stainless Steel...

  • Page 2: Table Of Contents

    Non-observance of the safety instructions means danger to persons (injury) or damage to the equipment Hot surfaces. Contact can lead to burns. Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany ascobloc Tel.: +49 351 4533-0 Fax +49 351 4533-433 E-mail: service@ascobloc.de Version: 07/07/2015...

  • Page 3: Details Of The Appliance

    Open windows, check whether there is a leak. If the cause cannot be identified or remedied, immediately inform a gas installation firm or the gas supply utility! Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany ascobloc Tel.: +49 351 4533-0 Fax +49 351 4533-433 E-mail: service@ascobloc.de...

  • Page 4: Instructions For Transport

    If the appliance is to be shut down: First put all gas valves to "Off" and then close the gas supply valve within the customer's extent of supply. This applies also in the case of repair work. 3.3 Instructions for transport Transport ascobloc appliances only in the original packaging. This avoids unnecessary damage and expense. Check the appliance for damage.
  • Page 5 Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany ascobloc Tel.: +49 351 4533-0 Fax +49 351 4533-433 E-mail: service@ascobloc.de...

  • Page 6: Proper Use Of The Appliance

    Knob at the "Zero" position extinguishes the burner and the pilot flame of the cooking zone. Operating the gas setting control (see Figure 4). Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany ascobloc Tel.: +49 351 4533-0 Fax +49 351 4533-433 E-mail: service@ascobloc.de...

  • Page 7: Cleaning

    If the appliance is to be taken out of operation, first set all knobs to "Zero" and then close the gas supply valve within the customer's supply. Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany ascobloc Tel.: +49 351 4533-0 Fax +49 351 4533-433 E-mail: service@ascobloc.de...

  • Page 8: Faults And Their Rectification

    A repair may only be performed by trained, qualified specialists. Please give us the appliance number and the type designation that are on the appliance type plate. The plate is located on the front cover A of the appliance (see connection diagram). 7.2 Customer service ascobloc Customer Service: Tel. +49 351 4533–384 +49 351 4533–379 E-Mail kundendienst@ascobloc.de...

  • Page 9: Spare Parts

    Piezo igniter 10/1216 Ignition cable x = replacement or repair only by authorised specialist company Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany ascobloc Tel.: +49 351 4533-0 Fax +49 351 4533-433 E-mail: service@ascobloc.de Version: 07/07/2015 Subject to change without notice!

  • Page 10: Gas Conversion

    Low flame nozzle Gas valve PEL 21S Nozzle holder Main nozzle 1 Conversion guide Figure Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany ascobloc Tel.: +49 351 4533-0 Fax +49 351 4533-433 E-mail: service@ascobloc.de Version: 07/07/2015 Subject to change without notice!

  • Page 11: Illustrations

    AGL 400 AGL 208 AGL 408 Figure 2 View of AGL 20x, 40x operating elements Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany ascobloc Tel.: +49 351 4533-0 Fax +49 351 4533-433 E-mail: service@ascobloc.de Version: 07/07/2015 Subject to change without notice!
  • Page 12 Drip pan Fettauffangschieber AGL 600 1100 AGL 608 View of AGL 60x operating Figure 3 Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany ascobloc Tel.: +49 351 4533-0 Fax +49 351 4533-433 E-mail: service@ascobloc.de Version: 07/07/2015 Subject to change without notice!
  • Page 13 Knebel leicht drücken und in Aus- Stellung bringen press the knob and put it in the off position Figure 4 Operating the gas setting control Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany ascobloc Tel.: +49 351 4533-0 Fax +49 351 4533-433 E-mail: service@ascobloc.de Version: 07/07/2015...

  • Page 14: Declaration Of Conformity

    Equipment for commercial kitchens - Frying and grilling appliances - Requirements and testing Dresden, 07/07/2015 p.p. R. Ziegler Technical Director Gastro-Gerätebau GmbH 01156 Dresden, Grüner Weg 29 Germany ascobloc Tel.: +49 351 4533-0 Fax +49 351 4533-433 E-mail: service@ascobloc.de Version: 07/07/2015 Subject to change without notice!
