Please read and follow all of the instructions & safety precautions detailed below prior to using this
product. Failure to do so may result in serious personal injury and / or property damage.
Do not expose this product to heat sources (including open flame or direct sunlight).
Do not expose this product to water or liquids. If liquid enters the product, immediately unplug the
product from any connected power sources or devices.
Do not disassemble or modify the product.
Avoid dropping this product (or any other heavy impact which might damage the internal circuit).
In the unlikely event of any abnormalities (such as strange odor, overheating, leaking, color
change, etc.), discontinue use immediately.
Avoid cleaning this product using liquids or chemical substances (use dry cloth only).
Only use attachments/accessories specified by the manufacturer.
Dispose of this item properly (do not dispose of it in trash receptacles and do not attempt to
incinerate it).
Do not leave this product unattended while it is being charged.
This product is not a toy: KEEP AWAY FROM CHILDREN.
Only re-charge this device using a USB port wall adapter (not included).
Do not re-charge via USB port on a computer.
Do not use this product while it is being charged.
When not being used for prolonged periods of time please charge every 3 months to avoid
damaging the battery.
It is recommended to fully recharge this item prior to initial use
The T253 is a wireless V4.1 speaker. Please read below product specifications & user guide.
T253 Specifications
Battery Type: Grade A Non-Recycled Lithium Polymer battery
Battery Duration/Lifespan (Charge/Discharge): 500 times
Battery Capacity: 400 mAh
Power Input & Current: DC 5V/0.6A
Sound Output: 3Watts (1 speaker & 1 passive subwoofer)
Sensitivity: 75dB
Frequency Response: 50Hz-22KHz
Wireless Version: Wireless V4.1
SD Card Reader: 32G Max.
Distortion Rate: <0.5%
Range of Wireless Communication: within 10 meters
Re-Charge Time (0-100%): up to 2 hours
Playback Time: up to 3 hours (played at 50% volume)
Included in the box:
1 T253 wireless speaker
1 Micro-USB/USB charging cable
1 AUX audio cable
1 user manual
Product Size: 3 ¾" x 2 ¾" x 2 1/8"
Net Weight: 189g
WARNING
Safety Precautions
T253 User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the T253 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Spector&Co T253

  • Page 1 It is recommended to fully recharge this item prior to initial use T253 User Manual The T253 is a wireless V4.1 speaker. Please read below product specifications & user guide. T253 Specifications Battery Type: Grade A Non-Recycled Lithium Polymer battery...
  • Page 2 4. OFF: press & hold multi-function button to power OFF Wireless Pairing 1. Once T253 has been turned on, it is automatically in WIRELESS mode (blue LED will flash quickly to indicate the speaker is ready for Wireless pairing) 2. Enable Bluetooth function on your electronic device.
  • Page 3: Fcc Statement

    FM Radio mode NOTE: Plug the 3.5mm AUX cable (included) into the T253 while in FM radio mode. The cable will act as an antenna and will improve the radio signal. 1. To activate FM radio, turn speaker ON & press the multi-function button quickly twice. When static noise can be heard, FM mode has been successfully activated.
  • Page 4 Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment...
  • Page 5 Il est recommandé de charger complètement ce produit avant de l’utiliser pour la première fois Manuel de l’utilisateur du T253 Le T253 est un haut-parleur sans fil V4.1. Ci-dessous les spécifications et le mode d’emploi du produit. Spécifications du T253 Type de batterie : Lithium polymère non recyclable grade A...
  • Page 6 4. ÉTEINDRE : Appuyer sur le bouton multifonctionnel et maintenir enfoncé Jumelage sans fil 1. Une fois le T253 allumé, il est automatiquement en mode SANS FIL (LED bleue clignotera rapidement pour signaler que le haut-parleur est prêt à s’apparier sans fil. Activer la fonction Bluetooth depuis le dispositif électronique.
  • Page 7: Déclaration De La Fcc

    6. Rejeter appel entrant peut se contrôler directement du dispositif audio Mode radio FM NOTE: Brancher le câble 3.5mm AUX (inclus) dans le T253 en mode radio FM. Le câble agira comme antenne pour améliorer la réception. 1. Pour activer le mode FM, allumer le haut-parleur et appuyer su le bouton multifonctionnel deux fois rapidement.
  • Page 8 télévision, ce qui se détermine en allumant et en éteignant l'appareil, on encourage l'utilisateur d'essayer de corriger ces interférences par l'un des moyens suivants :  Réorienter ou repositionner l'antenne de réception.  Augmenter l'espacement entre l'équipement et le récepteur. ...
  • Page 9  Se recomienda cargar completamente este producto antes de usarlo por primera vez Manual del usuario del T253 El T253 es un parlante inalámbrico V4.1. A continuación las especificaciones e instrucciones del producto. Especificaciones del T253 Tipo de batería: Polímero de litio no reciclable grado A Duración/Vida útil: (Carga/Descarga) 500 veces...
  • Page 10 Activar la función Bluetooth desde el dispositivo electrónico. 2. Buscar la señal Bluetooth Spector T253 y aparear el dispositivo. (LED azul parpadeará lentamente para señalar que el T253 se ha apareado).
  • Page 11 6. Oprimir tarjeta para hacerla eyectar Carga del T253 1. Insertar el cable de carga micro USB en el puerto de entrada del T253 mediante un adaptador de toma de corriente mural (no incluido). 2. LED roja fija (cerca del puerto micro-USB) señala que el dispositivo está cargando. (Para detener la carga, oprimir botón multifuncional y mantener oprimido;...
  • Page 12  Reorientar o reubicar la antena de recepción.  Aumentar la distancia entre el aparato y el receptor.  Conectar el aparato en un circuito diferente al del receptor.  Pedirle ayuda al concesionario o un técnico de radio/TV autorizado. Aviso: Toda transformación o modificación no autorizada explícitamente por la autoridad responsable podría anular el derecho a utilizar el equipo.
