- Page 1 INSTALLATION SERVICE MANUAL WHOLE HOUSE WATER CONDITIONER with Triton Electronic Control Valve IAPMO R&T certified to NSF/ANSI Standards 42 and 44 for meeting or exceeding industry standards of aesthetic chlorine reduction and softening efficiency.
-
Page 2: Plumbing Connections
Installation Guide IMPORTANT: Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system. PLUMBING CONNECTIONS In virtually all circumstances, the Reionator Pro Ultra water system is at- IMPORTANT: Ensure that water entering the Reionator Pro Ultra ™... -
Page 3: Installation
Installation SALT SETTING PLACEMENT OF THE REIONATOR PRO ULTRA WATER SYSTEM ™ Refer to the tables on the previous page to determine the correct setting for the size system you are installing. This Install the Reionator Pro Ultra system into the existing cold water ™... -
Page 4: Before Cutting
Installation MOVING THE REIONATOR PRO Figure 4a. Drain Elbow Drain Line Connection ULTRA INTO POSITION ™ PolyTube Insert Keep the Reionator Pro Ultra™ resin tank upright and move it into position. (The resin tank should always Drain Elbow Cap be upright, even during storage and while being Drain Line transported to the site.) Level the system with shims. - Page 5 Installation Figure 5. raw water to Plumbing Connection outside faucets water check local codes for minimum run between Reionator Pro Important: Brass or Plastic yoke assembly (not shown) unit and water heater is required to connect piping to the bypass valve and is available in either NPT or solvent.
- Page 6 Installation OVERFLOW CONNECTION BRINE LINE CONNECTIONS Install 1/2” I.D. tubing (not provided) to the brine tank overflow fitting located on the side of the tank and run it to the drain. The brine On all units, 3/8” O.D. x 1/4” I.D. brine line tubing must be overflow is provided in case a situation should arise causing too assembled at both the system control valve and the brine valve as much water to be added to the brine tank.
- Page 7 Installation Figure 7. Air Check Valve Adjustment salt grating check valve positioning mark aircheck brine well valve body Position mark on air check valve aircheck at same level as surface of salt grating. brine line over ow elbow brine tank brine well drain...
-
Page 8: Setting The Clock
Setting The Clock From the main TIME screen, press and release the “Set Time” button. The screen should change to the “Set Time” screen and the hour should flash. Figure 8a Press and release either the buttons until the desired hour of the day is reached. AM or PM will be indicated on the right side of the display. - Page 9 Press and release the “Set Time” button to move to the minute selection screen. The hours should stop flashing and the minutes should begin flashing. Figure 9a Press either the buttons to change the minutes as shown in Figure 9b. Figure 9b When you’ve finished setting the time, press and release the “Set Time”...
- Page 10 Triton Control Valve FUNCTION AND CYCLES OF OPERATION This glass-filled Noryl fully automatic control valve is designed as the primary control center to direct and regulate all cycles of a water softener or filter. When the Triton is set up as a softener, the Triton can be set to perform down flow or up flow regeneration.
-
Page 11: Bypass Valve Operation
Bypass Valve Operation... -
Page 12: Starting Up The System
Starting Up The System FLUSHING, CONDITIONING AND SANITIZATION Figure 12a. Bypass Operation Did you connect the drain line securely to the STOP Triton’s drain elbow? Did you connect the brine line securely to the Triton’s brine elbow? Step 1. Make sure the system is in the “Bypass” position before turning the main water back on (see figure 12a above). Make sure the drain line is connected securely to the control valve and is properly located over a drain. - Page 13 Step 3: To ensure sanitary conditions in the mineral and brine tanks, place 1.5 ounces common household bleach into the brine tank. Press and hold the REGEN button for 3 seconds to move the control valve into “1st Backwash” position. Once the motor stops, press and hold the REGEN button to move the control valve to the “Brine Dn”...
- Page 14 Setting Up The Triton Valve SETTING HARDNESS, REGENERATION DAY AND REGENERATION TIME The Triton control valve on your Reionator Pro Ultra comes pre-set from the factory to perform as a typical softener ™ valve. However, there are certain settings that are specific to the customer’s water situation that cannot be set at the factory.
- Page 15 IMPORTANT: This screen is used to set the day override to force regeneration on the specified number of days since last regeneration regardless of water usage. Changing this setting is usually not necessary. Step 2. From the “Set HARDNESS” screen, press the NEXT button. You should now see the “Set REGEN DAY” screen (shown above).
-
Page 16: Troubleshooting
Troubleshooting PROBLEM CAUSE CORRECTION 1. Reionator Pro Ultra ™ fails to regenerate. A. Bypass Valve in “Bypass” position. A. Move bypass to “Normal” position. B. Valve may be disconnected B. Make sure power is supplied to the from power. transformer power pack and that the transformer power pack is securely connected to the PC Board of the Triton. - Page 17 PROBLEM CAUSE CORRECTION 7A. Excessive water in brine tank. A. Plugged drain line flow control. A. Clean flow control. 7B. Salt water in service line. B. Plugged injector system. B. Clean injector and replace screen. C. Plugged or kinked drain line. C.
-
Page 18: Specifications
Specifications WaterTech recommends the use of Potassium Chloride (KCl) as a regenerant salt. Model Softening Efficiency @ Softening Capacity @ Maximum Recom- Maximum Recommend- Maximum Flow to @PSID Total Bed mended Hardness Drain During Stated Salt Setting Stated Salt Setting... -
Page 19: Replacements Parts List
Replacements Parts List Model RXU13 PRODUCT DESCRIPTION PART NUMBER Resin Tank 13” x 54” 09-03-1354BLK-Xmid Brine Tank 09-04-1833BKC Brine Grid 18” 09-04-119 Brine Well Assembly 3.5” X 30” 09-04-240 Brine Overflow Elbow 07-05-004 Triton Control Valve 13-V1CCDM... - Page 20 800 FREEPORT PARKWAY, #150, COPPELL, TX 75019 | 888.254.8412 www.watertech.com 06-01-020 10-03-2017...
