service of manifold
•
The charging hoses must be checked and free of oil residue before each use. A visible inspection is also neces
sary to ensure that the hoses and the connection are undamaged and tight.
•
The seals and gaskets of the manifold are parts of use and must be replaced from time to time. The manifold is to
be tested regularly to ensure the valves are still tight.
•
If a manifold shows to be leaking the pistons of the valves can easily be replaced and are available as a spare
part. Please refer to the manifold accessory section of the REFCO catalog.
•
If the sight glass is leaking a replacement kit is available. To change the sight glass a special tool is necessary
(M4-6-11-T) which is available from REFCO. Replace and tighten the new sight glass carefully in order to prevent
damage to the glass.
•
After installing spare parts to the manifold it is necessary to test the manifold for leaks before the next use.
auto shut-off
Approximately 10 minutes after the last measurement or keypress the DIGIMON shuts off itself.
disposal of manifold
Dispose of the manifold according to the rules and regulations of the country of use.
spare parts for dIGIMon manifold
description
Handwheel red
Handwheel blue
Complete valve set
Piston incl. gaskets
Sight glass set
External temperature sensor
Battery compartment cover
Tool for sight glass
Tool for valve core
Plastic case
designation
M2-7-SET-R
M2-7-SET-B
M2-10-95-R/10
M4-6-04-PA/10
M4-6-11
DIGIMON-EXTERNALSENSOR
DIGIMON-BATTERYCOVER
M4-6-11-T
A-32000
DIGIMON-CASE
English
Part number
3080-4677826
3080-4677834
3080-4662607
3080-4662624
3080-4493169
3080-4677647
3080-4676374
3080-4493169
3080-9880890
3080-4676497
