Paradox SR150 Quick Start Manual

SR150: Wireless Siren w/Built-In Strobe Light
Description
The SR150 is a weatherproof, stand-alone, and fully supervised wireless siren
with built-in strobe light and wireless transceiver.
The SR150 operates using 3 size "D" alkaline batteries. With normal use, the
SR150 will function up to 3 years without the need to replace the batteries
(battery life can be extended by using an optional AC or DC power supply).
The SR150 uses 2-way wireless communication, which provides continuous
supervision between the panel and siren with fast response to alarm signals
of up to 4 seconds.
With its tough weatherproof construction, the SR150 will operate reliably
from -30ºC to 50ºC (-22ºF to 122ºF) when using alkaline batteries or power
supply.
Overview
1
2
3
4
5
SR150-EI11 12/2012
Lenses
Red
Blue
Amber
Clear
B
C
D
E
Included Items:
• 1 strobe lens (available in red, blue, amber, or clear)
• 3 type "D" alkaline batteries
Required/Optional Items:
• Mounting hardware
• 8-16Vac, or 9-20Vdc external power supply (optional)
Compatibility:
• MG/SP series V4.0 (except SP4000)
• MG6130/MG6160 V3.0
• RTX3 V1.5
• K32LCD V1.3
• WinLoad V4.7 (with In-Field Upgrade Software V2.3)
• For latest updates visit paradox.com
Features
• Internal protective plastic cover (see A below)
• Built-in transceiver
• 100db wireless siren (see 1 below)
• Integrated strobe light (see E below)
• Weather-resistant design using a PC/ABS enclosure with UV protection
and a silicone coated PCB
• Fast alarm response time (4 seconds)
• 2.5 hour alarm display (strobe flashes every 4 seconds after bell cut-off )
• Siren presence supervised by control panel
• Dual tamper protection for cover removal and removal from wall (see 5
below)
• Assign up to 4 sirens per control panel
• Firmware upgradable via 307USB (see 4 below)
• Siren test mode
1) 100dB siren
2) Battery pack (3 size "D" alkaline batteries) with gold plated battery
connections, or optional 3.6Vdc
3) Power supply input (8-16Vac / 9-20Vdc)
4) In-field firmware upgrade connector
A
5) Dual-action tamper switch (detects when cover is removed and when
unit is removed from wall)
A) Internal protective plastic cover
B) Test switch
C) Status and Signal Strength LEDs. Refer to LED Feedback on reverse for
more information.
D) Antenna (can be extended using an RG6 or RG59 coaxial cable with
standard male F connectors. Attach the antenna using a female/female
F adaptor.)
E) Strobe lights
SR150 V2.1 PARADOX.COM
