- Page 2 Contents Quick Installation Guide x 1 Power Adapter x 1 USB Mouse x 1 CD Disk x 1 SATA Cable x 1 Foot Pad x 4 RS485 Connector x 1 SATA Power Cable x 1 Screw Kit x 1 SATA cable and SATA power cable are included in the HDVR...
-
Page 3: Hard Disk Installation
Hard Disk Installation Before installing the HDD, please make sure there is no pre-configured partition in this HDD. If yes, please delete all the partitions before the installation. Caution Step 1: Remove the upper case. Step 2: Plug the HDD power cable and SATA cable into the slot of the PCBA board and the HDD, respectively, making sure the connections are well done. - Page 4 Step 3: Please align the screw holes on the HDD with those on the HDVR case and secure them with the given screws. Step 4: After the HDD is secured, it should look like the one in the pictures (front and back) below:...
-
Page 5: Hardware Connection
Hardware Connection HDVR-430 HDVR-830 HDVR-1630 Name Description V1-V16 Composite video broadcast signal (CVBS) input interface. A1-A4 The input interface of the audio signal. A-OUT The output interface of the audio signal. The network interface of RJ45. HDMI The output interface of the HDMI video signal. - Page 6 Searching and Login Please install the utility from the CD and launch it to search the HDVR. After clicking the IP Search, you can see the HDVR online. The HDVR should be located and its IP address should be displayed. If the HDVR is not displayed after the search, you could try to click the Add Device button to enter the IP address to search it.
- Page 7 Web UI Login Window To enter the main menu and set up the HDVR, the default IP address is 192.168.0.20. And both the default User Name and Password are "admin". For more detailed information, please refer to the user’s manual on the CD. Note...
