- Page 1 ESCALE MIRROR 1000MM INSTALLATION INSTRUCTIONS 23264IN-NF PRODUCT DIMENSIONS 1 11/16” (4.3cm) 1 3/4”(4.5cm) 39 3/8”(100cm) All dimensions are in Inch(cm). 1325222-IN2-A...
- Page 2 INSTALLATION INSTRUCTION Locate the marking and drill the holes for mounting mirror on wall. 2 5/8” 2 5/8” (6.7cm) (6.7cm) 12 13/16” (32.5cm) Cable type H05 V V-F 2 x 1 mm² 220~240V Make electrical connection as shown in image and mount mirror on the specified screws.
- Page 3 Try to open the door and windows of the bathroom and maintain good ventilation. 3. Kohler mirrored cabinet are dealt with strict procedures for damp-proof. whose good damp-proof function ensures good performance even in bathroom of huge humidity. Yet do not splash and pour water directly on the mirrored cabinet.
- Page 4 Website: www.kohler.co.in All information is based on the latest product information available at the time of publication. Kohler Co. reserves the right to make changes in product characteristics, packaging or availability at any time without notice. © Kohler Co.2017 1325222-IN2-A...
