Partilink VP-QV41 User Manual

Multiview video processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Usermanual
Multiview Video Processor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VP-QV41 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Partilink VP-QV41

Summary of Contents for Partilink VP-QV41

  • Page 1 Usermanual Multiview Video Processor...

  • Page 2: Table Of Contents

    Contents 1. Overview ....................1 2. Features ....................1 3. Specifications ..................2 4. Hardware Descriptions ................. 3 Product Appearance ..............3 Front Panel ................... 4 Rear Panel ..................6 IR Remote Control ..............7 5. Installation ..................... 10 Wiring Diagram ................10 Rack Mount Installation ............

  • Page 3: Overview

    1. Overview The Multiview Video Processor is a simple, cost-effective video scaler designed to enable a true 4K@60Hz UHD, HD, SD video display device, virtually handling any input resolution up to 4K@60Hz. It provides 4 HDMI inputs, 1 VGA input, 1 DisplayPort input, 1 analog audio input, 1 HDMI output and 1 DP loop out.

  • Page 4: Specifications

    3. Specifications MODEL NO. Multiview Video Processor 4 x HDMI 2.0 with locking 1 x DP 1.2 INPUT 1 x VGA Audio R/L 1 x HDMI 2.0 with locking OUTPUT 1 x DP 1.2 Audio R/L Front panel buttons IR remote control CONTROL RS232/TELNET Web UI...

  • Page 5: Hardware Descriptions

    4. Hardware Descriptions 4.1 Product Appearance MULTIVIEW VIDEO PROCESSOR MULTIVIEW VIDEO PROCESSOR 4K@60Hz 4K@60Hz STANBY HDMI4 HDMI1 HDMI2 HDMI3 INPUT PANEL LAYOUT SWAP LOCK INPUT Feature Description Attach the bracket to the left side of the system Attach the bracket to the left side of the system Rack Mount Bracket * chassis for rack mount installation chassis for rack mount installation...

  • Page 6: Front Panel

    4.2 Front Panel MULTIVIEW VIDEO PROCESSOR 4K @ 60Hz INPUT INPUT PANEL HDMI4 STANBY HDMI1 HDMI2 HDMI3 SWAP SWAP LOCK INPUT LAYOUT Feature Description Receives signals from the remote control Receives signals from the remote control IR Receiver transmitter Press to select the HDMI 1 input Press to select the HDMI 1 input in full screen HDMI1 Press to select HDMI 1 audio in m...
  • Page 7 Feature Description LAYOUT* Press to select Layout F Toggle the input source in Layout B, C, Toggle the input source in Layout B, C, D, E and INPUT SWAP F mode PANEL LOCK Press to lock or unlock the front panel buttons Press to lock or unlock the front panel buttons Press to put the system into standby mode or ndby mode or...

  • Page 8: Rear Panel

    4.3 Rear Panel OUTPUT INPUT 12V DC HDMI HDMI3 HDMI4 RS232 POWER HDMI1 HDMI2 AUDIO ETHERNET AUDIO ON/OFF Feature Description Connect to the DP display device device, video fellow window A. OUTPUT Connect to the HDMI display device device, connector on HDMI rear panel with locking Connect to the HDMI source, connector on...

  • Page 9: Ir Remote Control

    4.4 IR Remote Control...
  • Page 10 Feature Description Press to set system into standby mode or wake Press to set system into standby mode or wake Standby up the system Lock Press to Lock or unlock the front panel buttons Press to Lock or unlock the front panel buttons Select HDMI 1 in full screen mode 1 in full screen mode Select HDMI 1 audio in multiview...
  • Page 11 Feature Description Rotate the video display / L90 in full Rotate* screen mode Flip Flip display screen in full screen mode Select the custom screen layout 1 Select the custom screen layout 2 Select the custom screen layout 3 Custom Layout* Select the custom screen layout 4 Select the custom screen layout 5...

  • Page 12: Installation

    5. Installation 5.1 Wiring Diagram Do the following steps for device connections. Connect a HDMI source to the HDMI 1 input connector. Connect a HDMI source to the HDMI 2 input connector. Connect a HDMI source to the HDMI 3 input connector. Connect a HDMI source to the HDMI 4 input connector.

  • Page 13: Rack Mount Installation

    5.2 Rack Mount Installation Take the following steps to attach the two brackets to the system chassis and install into rack. Remove all cables and power supply before mount the Multiview Video Processor in the rack Place the system chassis on a sturdy surface Attach bracket to the left side of the system chassis by using the screw driver and four screws Attach the other bracket to the right side of the system chassis by...

  • Page 14: Configurations

    6. Configurations 6.1 Front Panel Buttons Please see the section 4.2. 6.2 Front Panel Buttons Please see the section 4.4 6.3 Web UI You can connect the Ethernet directly from PC to Multiview Video Process. Please follow below steps to configure your PC Ethernet setting. 6.3.1 Directly Connect to PC via Ethernet Cable Click Start >...

  • Page 15: Ethernet Hub Or Router

    After doing the steps from a. to h. successfully, you can click into Web UI by typing the 192.168.1.202 IP address in IE or Chrome. 6.3.2 Ethernet Hub or Router At first, please follow section 6.3.1 and open web browser then follow 6.3.3 to set the Ethernet type to DHCP.

  • Page 16: System Setting Page In Web Ui

    6.3.3 System Setting Page in Web UI Settings System Multi F/W version: 1.A6.A3 View Reboot Load Default Network Ethernet Type MANUAL ▼ Mask Gateway Cancel Confirm Cancel Confirm Feature Description FW version System firmware version System Reboot Reboot Multiview Video Processor Change the network type to Static IP or DHCP Ethernet...

  • Page 17: Multi View Page In Web Ui

    6.3.4 Multi View Page in Web UI Settings Output Setting Color Setting Brightness Resolution 3840x2160@30Hz Multi ▼ View Audio Source Window A ▼ Contrast Load Cancel Confirm Default Full Screen Setting Saturation Flip Resolution Cancel Confirm Cancel Confirm...
  • Page 18 Feature Description Select output resolution 1: Auto (default) 2: 3840x2160@60Hz 3: 3840x2160@50Hz 4: 3840x2160@30Hz Resolution 5: 1920x1080@60Hz 6: 1280x720@60Hz 7: 480p@60Hz Press “Confirm” after setting has finished or press “Cancel” to ignore the modification. Output Setting Select audio output source 1: Window A (default) 2: HDMI1 3: HDMI2...
  • Page 19 Please see Appendix 1 Layout Setting Pre-defined Layout A Layout B Layout C Layout D Layout E Layout F Custom Custom 1 Custom 2 Custom 3 Custom 4 Custom 5 Custom 6 Custom 7 Custom 8 Window A HDMI1 Cancel Confirm...
  • Page 20 Feature Description Select display layout type on monitor 1: Layout A (default, full screen) 2: Layout B 3: Layout C 4: Layout D Pre-defined* 5: Layout E 6: Layout F Press “Confirm” after setting has finished or press “Cancel” to ignore the modification.
  • Page 21 Layout Setting Pre-defined Layout A Layout B Layout C Layout D Layout E Layout F Custom Custom 1 Custom 2 Custom 3 Custom 4 Custom 5 Custom 6 Custom 7 Custom 8 Bottom Window A HDMI1 Window B HDMI2 Layer3 Window C HDMI3 Layer2...
  • Page 22 Feature Description Select display custom layout type on Layout monitor Setting Custom * Press “Confirm” after setting has finished or press “Cancel” to ignore the modification. Window Information in upper left side of the window. 1. Window name: Window A, B, C and D 2.
  • Page 23 6.3.5 Load Default in Web UI Settings Output Setting Multi Resolution 3840x2160@30Hz ▼ View Audio Source Window A ▼ Load Default Cancel Confirm Full Screen Setting Flip Resolution ▼ Cancel Confirm Press to load default setting in Web UI.

  • Page 24: Rs232/Telnet

    6.4 RS232/TELNET 6.4.1 Serial Port Settings Apply the following settings to set up the serial port communication. Baud rate: 115200 Data bits: 8 Stop bits: 1 Parity: None Flow control: None 6.4.2 Commands Command Description Parameter SPOW 0/1 SET THE UNIT POWER ON/OFF 0=OFF,1=ON RPOW SHOW CURRENT POWER STATE...
  • Page 25 Command Description Parameter N=0~100, SHUE N SET HUE VALUE FOR OUTPUT Default 50 RHUE SHOW HUE CURRENT VALUE 0 = ALL, BRIGHTNESS+CONTRAS T+SATURATION+HUE 1=BRIGHTNESS, RESET COLOR SETTING VALUE TO SIMRE 0~4 DEFAULT 2=CONTRAST, 3=SATURATION, 4=HUE, WINDOW N=1~4, 1: A, 2: B, 3: C, 4: D INPUT SOURCE M=1~6, SIN2CH N M SET INPUT SOURCE M TO WINDOW N...
  • Page 26 Command Description Parameter SHOW WINDOW VERTICAL POSITION CURRENT VALUE RVPOS WINDOW A~D=WINDOW 1~4 VERTICAL SIZE 0~59 WINDOW N=1~4, 1: A, 2: B, 3: C, 4: D SWIN N M SET OUTPUT WINDOW ON/OFF M=0/OFF, 1/ON WINDOW N=0~4, RWIN N SHOW OUTPUT WINDOW 1: A, 2: B, 3: C, 4: D 0: ALL WINDOW N=1~4,...
  • Page 27 Command Description Parameter RIPADD SHOW STATIC CURRENT IP ADDRESS N=0~255, M=0~255, SMAADD N M X Y SET STATIC SUBNET ADDRESS X=0~255, Y=0~255 SHOW STATIC CURRENT SUBNET RMAADD ADDRESS N=0~255, M=0~255, SGAADD N M X Y SET STATIC GATEWAY ADDRESS X=0~255, Y=0~255 SHOW STATIC CURRENT GATEWAY RGAADD ADDRESS...

  • Page 28: Package Contents

    7. Package Contents 1 x Multiview Video Processor 1 x Remote Control 1 x DC 12V/2A output power adapter 2 x Rack Mount Bracket 4 x Rubber Pad 1 x Screws bag 1 x User manual...

  • Page 29: Appendix 1: Function Na List

    A. Appendix 1: Function NA list Input Custom Layout A Layout B Layout C Layout D Layout E Layout F Resolution Layout Rotate NA Rotate NA Rotate NA Rotate NA Rotate NA Rotate NA Rotate NA 4K60 INPUT SWAP Flip NA Flip NA Flip NA Flip NA...

  • Page 30: Appendix 2: Front Panel Screen Layout Indicator

    B. Appendix 2: Front Panel Screen Layout Indicator Layout A Layout B Layout C Layout D Layout E Layout F Screen Layout Indicator Indicator Indicator Indicator Indicator Indicator Layout A Layout B Layout C Layout D Layout E Layout F Custom Layout...
