PBX-211User Manual
Please read this user manual carefully before use
Screen Description
1.
: When reading Memory Card and card reading, this symbol means pause;
Muting when Aux in or FM mode.
2. U/TF: Displays the letter " U/TF" when playing USB disk or TF card.
3.
: Displays the symbol when you select to repeat to a track.
4.MIC: Displays the symbol when insert wired or wireless microphone.
5.REC: In the mode of TF / USB, long press the key of RECORD when insert Microphone, display REC.
6.88:88:
Display "AUX" in the " Aux " Mode.
Digital display of current channel in the FM radio mode.
Displays the series number of music when playing TF Card and U disk.
7.
:The volume will drop to 30% when the display shown the battery symbol.
Panel Function
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for QFX PBX-211
Summary of Contents for QFX PBX-211
- Page 1 PBX-211User Manual Please read this user manual carefully before use Screen Description : When reading Memory Card and card reading, this symbol means pause; Muting when Aux in or FM mode. 2. U/TF: Displays the letter “ U/TF” when playing USB disk or TF card. : Displays the symbol when you select to repeat to a track.
- Page 2 1.Power switch 2.Light 3.Music/KARAOKA 4.Repeat 5.Record 6.Mode 7.Previous song 8.Play/Pause 9.Next song 10.MASTER VOL 11.MIC VOL 12.ECHO 13.TREBLE 14.BASS 15.MIC1 16.MIC2 17.USB port 18.AUX in port 19.TF card 20.Remote Control Receiver 21.DC input Function Description General Function description 1. Master Volume Control: Turning right or left to adjust master volume in any mode. 2.
- Page 3 1. Press mode button to enter Bluetooth mode, the display shows “BLUE” . Using the native controls on your Bluetooth device hit search to scan for available devices and select "QFX PBX-211" to connect. Speaker will call out "didi" once paired successfully.
- Page 4 Unit *1pcs User manual*1pcs Adapter*1pcs Remote control*1pcs Wired microphone*1pcs Caution ·The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. ·Minimum distances 20-30cm around the apparatus for sufficient ventilation. ·The ventilation should not be impeded by covering the ventilation openings with items, such as newspapers, table-cloths, curtains, etc.
